Sauder Credenza Soft Modern 414986 Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
Credenza
Soft Modern Collection | 414986
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Your holder for all
things awesome.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-21
Français pg 22-24
Español pg 25-27
Lot # 387321
01/07/16
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading

Related Manuals for Sauder Credenza Soft Modern 414986

Summary of Contents for Sauder Credenza Soft Modern 414986

  • Page 1 Soft Modern Collection | 414986 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR Prefer the phone? Call 1-800-523-3987. FUTURE REFERENCE.
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 135 pounds. Never use with a TV that weighs more.
  • Page 3 TOP (1) MOLDING (9) BOTTOM (1) DRAWER BRACE (3) SHELF (1) RIGHT DRAWER SIDE (3) BACK (1) LEFT DRAWER SIDE (3) BRACE (1) D115 DRAWER BACK (3) DRAWER FRONT (1) D723 DRAWER BOTTOM (3) D115 D723 www.sauder.com/services 414986 Page 3...
  • Page 4 BLACK 9/16" LARGE HEAD SCREW - 38 BLACK 1-7/8" FLAT HEAD SCREW - 8 GOLD 5/16" FLAT HEAD SCREW - 26 BROWN 1" FLAT HEAD SCREW - 36 30S BLACK 1-9/16" FLAT HEAD SCREW - 15 Page 4 414986 www.sauder.com/services...
  • Page 5 å To begin assembly, push a SAUDER TWIST-LOCK® FASTENER (10F) into the large holes in the ENDS (A and B). Repeat this step for the SHELF (G). Some assembly (and snacks) required.
  • Page 6 CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow (15 used) (15 used) Arrow Arrow Insert the metal end of the CAM DOWEL into the HIDDEN CAM. Page 6 414986 www.sauder.com/services...
  • Page 7 CABINET LEFT (35GB) to the LEFT END (B). Use four GOLD 5/16” FLAT HEAD SCREWS (3S) through holes #1 and #3. Roller end GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Roller end www.sauder.com/services 414986 Page 7...
  • Page 8 LEFTS (35GB) to the LOWER UPRIGHTS (D). Use eight GOLD 5/16” FLAT HEAD SCREWS (3S) through holes #1 and #3. Roller end Finished edge Roller end Roller end Finished edge GOLD 5/16" FLAT HEAD SCREW (8 used in this step) Roller end Page 8 414986 www.sauder.com/services...
  • Page 9 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To completely tighten: Minimum 190 degrees www.sauder.com/services 414986 Page 9...
  • Page 10 Step Step 6 å Fasten the SHELF (G) to the UPRIGHTS (C). Use four BLACK 1-7/8” FLAT HEAD SCREWS (2S). BLACK 1-7/8" FLAT HEAD SCREW (4 used in this step) Finished edge Page 10 414986 www.sauder.com/services...
  • Page 11 H I D D E N i t h S u r f a c H I D D E N i t h Maximum Arrow 210 degrees Finished edge Minimum 190 degrees www.sauder.com/services 414986 Page 11...
  • Page 12 Step Step 8 å Fasten the ENDS (A and B) to the TOP (E), How to use the SAUDER TWIST-LOCK ® FASTENER BOTTOM (F), and SHELF (G). Tighten eight 1. Insert the dowel end of the FASTENER into the hole of the TWIST-LOCK®...
  • Page 13 BASE (M). Use four BLACK 9/16” LARGE HEAD SCREWS (1S). å NOTE: Be sure the BRACKETS are even with the edges of the BRACE and BASE. BLACK 9/16" LARGE HEAD SCREW (12 used in this step) www.sauder.com/services 414986 Page 13...
  • Page 14 BOTTOM. å Fasten the SIDE BASES (N) to the CORNER BRACKETS on the BRACE (I) and BASE (M). Use eight BLACK 9/16” LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW (20 used in this step) Page 14 414986 www.sauder.com/services...
  • Page 15 Fasten the BACK (H) to your unit using the NAILS (1N). å NOTE: Be sure to tap NAILS into the holes that line up over the LOWER UPRIGHTS (D). These holes must line up over the LOWER UPRIGHTS (D). NAIL (42 used in this step) www.sauder.com/services 414986 Page 15...
  • Page 16 NOTE: Be sure to position the MOLDINGS exactly as BROWN 1" FLAT HEAD SCREW shown in the enlarged diagram. (36 used in this step) å Repeat this step for the other DRAWER FRONTS (J and L). Page 16 414986 www.sauder.com/services...
  • Page 17 Fasten the DRAWER BRACE (M67) to the DRAWER å SIDES (D12 and D13) and DRAWER BRACE (M67). Use five FRONT (K). Tighten one HIDDEN CAM. BLACK 1-9/16” FLAT HEAD SCREWS (30S). Repeat this step for the other DRAWERS (J and L). www.sauder.com/services 414986 Page 17...
  • Page 18 Repeat this step for the other drawers. Roller end Screw head - turn CAM to line up holes in SLIDES with holes in DRAWER SIDES. Roller end GOLD 5/16" FLAT HEAD SCREW (12 used in this step) Page 18 414986 www.sauder.com/services...
  • Page 19 å Peel a BUMPER from the BUMPER CARD (29M) and stick it on the PULL (84K) as shown. å Repeat this step for the other drawers. BLACK 9/16" LARGE HEAD SCREW (six used in this step) www.sauder.com/services 414986 Page 19...
  • Page 20 Severe injury or death can occur. The TV and furniture will be unstable and may tip. - The TV must weigh less than 135 lbs. - The base of the TV must be able to sit completely on this shelf. Page 20 414986 www.sauder.com/services...
  • Page 21 #3. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. www.sauder.com/services 414986 Page 21...
  • Page 22 EXTRÉMITÉ DROITE ............. 1 10A EXCENTRIQUE DE COULISSE ......6 et conserver le livret pour future référence. EXTRÉMITÉ GAUCHE ............1 EXCENTRIQUE ESCAMOTABLE ....15 Pour contacter Sauder MONTANT..................2 CHEVILLE D’EXCENTRIQUE......15 en ce qui concerne cet MONTANT INFÉRIEUR ............2 10F FIXATION TWIST-LOCK® ........8 élément, faire référence...
  • Page 23 Pour commencer l’ a ssemblage, enfoncer une FIXATION TWIST-LOCK® Utilisation de la FIXATION TWIST-LOCK® SAUDER SAUDER (10F) dans les gros trous des EXTRÉMITÉS (A et B). Répéter 1. Insérer l’extrémité fi letée de la FIXATION dans le trou de la pièce cette étape pour la TABLETTE (G).
  • Page 24 Utiliser quatre VIS TÊTE PLATE 8 mm DORÉES (3S) à travers les trous nº 1 et nº 3. REMARQUE : La tête de vis dans l’EXCENTRIQUE doit être visible à travers le trou fendu dans la COULISSE. Répéter cette étape pour les autres tiroirs. Page 24 414986 www.sauder.com/services...
  • Page 25 10A EXCÉNTRICO DE CORREDERA .......6 et conserver le livret pour future référence. EXTREMO IZQUIERDO ............1 EXCÉNTRICO ESCONDIDO ......15 Pour contacter Sauder PARAL .....................2 PASADOR DE EXCÉNTRICO ......15 en ce qui concerne cet PARAL INFERIOR ..............2 10F SUJETADOR TWIST-LOCK® ........8 élément, faire référence...
  • Page 26 EXCÉNTRICOS ESCONDIDOS que no se aprieten • Cette unité Sauder est conçue pour les téléviseurs pesant moins completamente se afl ojarán y las partes pueden separarse. Para de 61 kg. Ne jamais utiliser avec des téléviseurs plus lourds.
  • Page 27 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. www.sauder.com/services 414986 Page 27...
  • Page 28 • Physical injury. Furniture can be very • Do not push furniture, especially on a heavy. carpeted fl oor. Have a friend help you lift the item and set it in place. Page 28 414986 www.sauder.com/services...
  • Page 29 équipé. • Blessure physique. Le mobilier peut être mobilier. très lourd. • Ne pas pousser le mobilier, surtout sur la moquette. Se faire aider par une autre personne pour soulever l’élément et le mettre en place. www.sauder.com/services 414986 Page 29...
  • Page 30 • Lesión física. El mobiliario puede ser • No empuje la unidad, especialmente muy pesado. sobre un piso alfombrado. Pide la ayuda de otra persona en levantar la unidad y colocarla en lugar. Page 30 414986 www.sauder.com/services...
  • Page 31 GARANTIE LIMITÉE DE 5 ANS 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période de cinq ans à...
  • Page 32 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
