CONTACT US FIRST
CONTACT US FIRST
sauder.com
sauder.com
sauder.com
BEFORE MAKING ANY RETURNS TO THE STORE.
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com/service
Visit
Prefer the phone? Give us a ring at
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Twin Platform Bed
with Headboard
Parklane Collection | Model 414129
Share your journey!
to order replacement parts, view video assembly tips, or chat with a live rep.
1-800-523-3987
.
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-20
Français pg 21-23
Español pg 24-26
Lot # 530074
05/28/19
Purchased: __________________
Advertisement
Related Manuals for Sauder 414129
Summary of Contents for Sauder 414129
- Page 1 Twin Platform Bed NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. with Headboard PLEASE READ AND KEEP FOR FUTURE REFERENCE. Parklane Collection | Model 414129 English pg 1-20 Français pg 21-23 Español pg 24-26 Share your journey! Lot # 530074 05/28/19...
- Page 2 Table of Contents Assembly Tools Required Part Identifi cation Hardware Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Assembly Steps 5-20 Français 21-23 Español 24-26 Skip the power trip. This time. Warranty Page 2 414129 www.sauder.com/service...
- Page 3 SMALL SUPPORT (4) E3 HEADBOARD TOP (1) HEADBOARD (1) LARGE SUPPORT (2) SLAT (2) LEFT HEADBOARD RAIL (1) CENTER BACK (1) N2 LEFT FOOTBOARD RAIL (1) RIGHT HEADBOARD RAIL (1) O2 RIGHT FOOTBOARD RAIL (1) LEFT/RIGHT BACK (2) www.sauder.com/service 414129 Page 3...
- Page 4 FELT DISC CARD - 2 METAL PIN - 8 12S BROWN 1" FLAT HEAD SCREW - 52 BLACK 9/16" LARGE HEAD SCREW - 36 101S BLACK 1-1/2" FLAT HEAD SCREW - 16 113S BLACK 1-15/16" FLAT HEAD SCREW - 20 Page 4 414129 www.sauder.com/service...
- Page 5 fl oor. Push four HIDDEN CAMS (1F) into the RAILS (N2, O2, T, and U). å Arrow Arrow Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. www.sauder.com/service 414129 Page 5...
- Page 6 NOTE: Start each SCREW a few turns before å tightening any of them. BROWN 1" FLAT HEAD SCREW (12 used in this step) Finished edge These holes must be here. These holes must be here. The HIDDEN CAM must be here. Page 6 414129 www.sauder.com/service...
- Page 7 LARGE SUPPORTS (Y). NOTE: Start each SCREW a few turns before tightening å any of them. BROWN 1" FLAT HEAD SCREW (20 used in this step) Unfi nished edge Unfi nished edge www.sauder.com/service 414129 Page 7...
- Page 8 NOTE: Start each SCREW a few turns before tightening any å of them. BROWN 1" FLAT HEAD SCREW (8 used in this step) Surface with more holes Curved edge The HIDDEN CAM must be here. Curved edge The HIDDEN CAM must be here. Page 8 414129 www.sauder.com/service...
- Page 9 FLAT HEAD SCREWS (12S). NOTE: Start each SCREW a few turns before tightening å any of them. BROWN 1" FLAT HEAD SCREW (12 used in this step) These holes must be here. These holes must be here. www.sauder.com/service 414129 Page 9...
- Page 10 Step 6 Peel the FELT DISCS from the FELT DISC CARDS (1M) å and stick them onto the edges of the ENDS (A3 and B3), LARGE SUPPORTS (Y), and FOOTBOARD (R) as shown. Long fi nished edge Page 10 414129 www.sauder.com/service...
- Page 11 RAILS (N2 and O2). Use four BLACK 1-15/16" FLAT HEAD SCREWS (113S). NOTE: Start each SCREW a few turns before å tightening any of them. 113S BLACK 1-15/16" FLAT HEAD SCREW (4 used in this step) Long fi nished edge Finished edge Finished edge www.sauder.com/service 414129 Page 11...
- Page 12 Use four BLACK 1-15/16" FLAT HEAD SCREWS (113S). NOTE: The LARGE SUPPORT (Y) should be off the ground and å facing toward the FOOTBOARD (R). 113S BLACK 1-15/16" FLAT HEAD SCREW (4 used in this step) Page 12 414129 www.sauder.com/service...
- Page 13 Fasten the HEADBOARD (S) to the LEFT HEADBOARD RAIL (T). å Use two BLACK 1-15/16" FLAT HEAD SCREWS (113S). Finished edge with holes The LARGE SUPPORT (Y) should be here. 113S BLACK 1-15/16" FLAT HEAD SCREW (4 used in this step) www.sauder.com/service 414129 Page 13...
- Page 14 Use two BLACK 1-15/16" FLAT HEAD SCREWS (113S). Fasten the SUPPORT (Q) to the SMALL SUPPORT (X) on the å RIGHT HEADBOARD RAIL (U). Use two BLACK 1-15/16" FLAT HEAD SCREWS (113S). 113S BLACK 1-15/16" FLAT HEAD SCREW (4 used in this step) Page 14 414129 www.sauder.com/service...
- Page 15 å Fasten the FOOTBOARD RAILS (N2 and O2) to the HEADBOARD RAILS (T and U). å Tighten two HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the HEADBOARD RAILS insert into the å FOOTBOARD RAILS. www.sauder.com/service 414129 Page 15...
- Page 16 Use eight BLACK 9/16" LARGE HEAD SCREWS (1S). NOTE: The Z-PLATES will wrap around the bottom edges of å the RAILS (N2, O2, T, and U). BLACK 9/16" LARGE HEAD SCREW (8 used in this step) Page 16 414129 www.sauder.com/service...
- Page 17 HEADBOARD (S). Place the SLATS (I3) onto the METAL PINS (1R) in å the HEADBOARD (S). Insert four METAL PINS (1R) into the holes in the top å edges of the SLATS (I3). Finished surface www.sauder.com/service 414129 Page 17...
- Page 18 NOTE: Be sure the METAL PINS in the SLATS (I3) insert into å the HEADBOARD TOP. 113S BLACK 1-15/16" FLAT HEAD SCREW (4 used in this step) Edge without holes 113S F i n i s h e u r f a Page 18 414129 www.sauder.com/service...
- Page 19 BACKS (V). of the BACKS (V) last using fi rm Please do not remove. pressure. The two smaller holes in the edges of the BACKS (V) must line up over the ENDS (A3 and B3). www.sauder.com/service 414129 Page 19...
- Page 20 BLACK 1-1/2" FLAT HEAD SCREW (16 used in this step) These holes are closer together and must be here. NOTE: Do not put SCREWS into these two holes. These holes are closer together and must be here. Page 20 414129 www.sauder.com/service...
- Page 21 Lit plateforme à une Modèle 414129 place avec tête de lit Utilisez les instructions d’ a ssemblage en français avec les NOUS SOMMES LA POUR VOUS AIDER! schémas étape par étape du manuel d’instruction en anglais. Nous faisons de notre mieux pour nous assurer que votre meuble Chaque étape en français correspond à...
- Page 22 REMARQUE : Il est préférable de donner quelques tours de REMARQUE : Le GRAND SUPPORT (Y) doit être hors du sol et tournevis à chaque VIS avant de les serrer toutes à bloc. dirigé vers le PIED DE LIT (R). Page 22 414129 www.sauder.com/service...
- Page 23 Fixer les PLAQUES EN Z (75G) aux TRAVERSES (N2, O2, T et U). Utiliser huit VIS TÊTE LARGE 14 mm NOIRES (1S). REMARQUE : Les PLAQUES EN Z seront enrobées les chants inférieurs des TRAVERSES (N2, O2, T et U). www.sauder.com/service 414129 Page 23...
- Page 24 EXTREMO IZQUIERDO ..........1 15F PASADOR DE MADERA .........2 necesita ponerse en PANEL SUPERIOR DE CABECERA ....1 25F PASADOR DE DOS LEVAS ........2 contacto con Sauder en LISTÓN ................2 75G PLACA-Z ................2 cuanto a esta unidad, refi érase al número RIEL IZQUIERDO DEL PIE DE CAMA ..1 TARJETA CON TOPES DE FIELTRO .....2...
- Page 25 NOTA: Comience a atornillar cada TORNILLO unas vueltas antes CABEZA PERDIDA de 49 mm (113S). de apretar cualquier tornillo fi rmemente. NOTA: El SOPORTE GRANDE (Y) debe estar fuera del suelo y orientado hacia el PIE DE CAMA (R). www.sauder.com/service 414129 Page 25...
- Page 26 Fije las PLACAS-Z (75G) a los RIELES (N2, O2, T y U). Utilice ocho TORNILLOS NEGROS DE CABEZA GRANDE de 14 mm (1S). NOTA: Las PLACAS-Z no deben extenderse más allá de los bordes inferiores de los RIELES (N2, O2, T y U). Page 26 414129 www.sauder.com/service...
- Page 27 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
- Page 28 Walmart.com in the product detail page. General Conformity Certifi cate 1. This certifi cate applies to the Sauder Woodworking Product identifi ed by this Instruction Book. 2. This certifi cate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
