Eller CR250V Instruction Manual

TIME OF USE
Retractable type fall arrester can be used without time limit on condition periodic inspections are carried out timely.
PERIODIC INSPECTIONS
After each 12 months of usage the retractable type fall arrester should be withdrawn from use and subject to a detailed periodic inspection. The
device can be subject to inspection only by the manufacturer or his authorized representative. During periodic inspection period of use of the device
date of the next inspection should be arranged. All information regarding the periodic inspection must be recorded in the Identity Card.
WITHDRAWAL FROM USE
Retractable type fall arrester must be withdrawn from use immediately, if there are any doubts in regard of its correct condition and function. The
device must not be used until the equipment manufacturer or his authorized representative carries out a detailed inspection and gives his written
consent to use the equipment again. Retractable type fall arrester must be withdrawn from use immediately and sent to the manufacturer or his
authorized representative to carry out a detailed inspection, if it has been used to arrest a fall.
Any repair or service works can performed only by the device manufacturer or his authorized representative.
Notified body responsible for controlling the production phase of the device:
APAVE SUDEUROPE SAS
8 rue Jean-Jacques Vernazza – ZAC. Saumaty-Séon – BP 193
13322 MARSEILLE CEDEX 16
FRANCE - No. 0082
Notified body responsible for EU type test certification in accordance with Regulation 2016/425:
CIOP PIB - No.1437
CENTRALNY INSTYTUT OCHRONY PRACY - PAŃSTWOWY INSTYTUT BADAWCZY
ul. Czerniakowska 16, 00-701 Warszawa
IDENTITY CARD
It is the responsibility of the user organisation to provide the identity card and to fill in the details required. The identity card should be filled in before the
first use by a competent person, responsible inthe user organization for protective equipment. Any information about the equipment like periodic
inspections, repairs, reasons of equipment's withdrawal from use shall be noted into the identity card by a competent person in the user organization. The
identity card should be stored during a whole period of equipment utilization. Do not use the equipment without the identity card.
MODEL AND TYPE OF EQUIPMENT
SERIAL/BATCH NUMBER
REFERENCE NUMBER
USER NAME
PERIODIC INSPECTION AND REPAIR HISTORY CARD
DATE OF REASON FOR DEFECTS,
INSPECTION INSPECTION CONDITION NOTED
OR REPAIR REPAIRS CARRIED OUT
Louis Reyners BV, Symon Spiersweg 13a, 1506 RZ, Zaandam, The Netherlands, tel. +31 (0)756504750, fax +31 (0)756504760, www.lr.nl
DATE OF MANUFACURE
DATE OF PURCHASE
DATE OF FIRST USE
NAME AND SIGNATURE NEXT
OF COMPETENT INSPECTION
PERSON DATE
INSTRUCTION MANUAL
Carefully read the manual before
using the equipment.
RETRACTABLE
0082
TYPE FALL ARRESTER
EN 360:2002
Retractable type fall arrester is a component of personal fall
protection equipment compliant with EN 360:2002.
Retractable type fall arrester provides protection for one user.
Permissible user's weight is 140kg.
Available lengths of work cable:
- CR250V 06 / CR251V 06 - 6 meters
- CR250V 10 / CR251V 10 - 10 meters
- CR250V 12 / CR251V 12 - 12 meters
- CR250V 15 / CR251V 15 - 15 meters
Galvanized steel
work cable
DEVICE MARKING:
Before each
Permissible
use check
inclination of
function of the
work line from
locking gear.
the vertical line
Range of
Permissible
device usage
user's weight
temperatures
Store in rooms,
Use full body
protect from direct
harness
sunlight, moisture
and other aggressive compliant with
substances
EN 361 only
Do not release
Read the
the device
manual before
cable suddenly
use
when extended
Inspect the
Do not repair
device before
the device on
each use
your own
Attach the device
Do not use
to a structural
the device
anchor point
with damaged
(anchor point)
cable
using rotary holder
CR250V/CR251V
Upper rotary holder
(CR250V) or
connector (CR251V)
Cable retractor with
used to attach the
brake and energy
device to anchor point
absorber in plastic
housing
4mm
Ø
Identity label
RETRACTABLE TYPE FALL ARRESTER
REF. CR 250 V
Cable length:: ... m
Serial number: 00000000
Date of manufacture:: mm yyyy
Number of European standard
EN 360:2002
CE mark and number of the notified
body controlling production of the
equipment
0082
Device's manufacturer or distributor mark
Snap hook with
Month and year of next
swivel (choice of manufacturer's inspection. Do not
use the device after this date.
alternative snap
2019
Note: Before first use mark the
hooks with optional
date of the manufacturer's
fall indicator) inspection (date of first use + 12
months, e.g. first use 01.2019 –
mark inspection 01.2020)
Do not attach the
device to a
structural anchor
point (anchor point)
using handle for
device
transportation
Handle for device
transportation
