Eller CR250HV Instruction Manual

TIME OF USE

Retractable type fall arrester can be used without time limit on condition periodic inspections are carried out timely.

PERIODIC INSPECTIONS

]After each 12 months of usage the retractable type fall arrester should be withdrawn from use and subject to a detailed periodic inspection. The
device can be subject to inspection only by the manufacturer or his authorized representative. During periodic inspection period of use of the device
date of the next inspection should be arranged. All information regarding the periodic inspection must be recorded in the Identity Card.

WITHDRAWAL FROM USE

Retractable type fall arrester must be withdrawn from use immediately, if there are any doubts in regard of its correct condition and function. The
device must not be used until the equipment manufacturer or his authorized representative carries out a detailed inspection and gives his written
consent to use the equipment again. Retractable type fall arrester must be withdrawn from use immediately and sent to the manufacturer or his
authorized representative to carry out a detailed inspection, if it has been used to arrest a fall.
Any repair or service works can performed only by the device manufacturer or his authorized representative.
Notified body responsible for controlling the production phase of the device:
APAVE SUDEUROPE SAS
8 rue Jean-Jacques Vernazza – ZAC. Saumaty-Séon – BP 193
13322 MARSEILLE CEDEX 16
FRANCE - No. 0082
Notified body responsible for EU type test certification in accordance with Regulation 2016/425:
PRS – No.1463
Polski Rejestr Statków S.A.
al. gen. Józefa Hallera 126 80-416 Gdańsk, Poland
Tel.: (+48) 58 75 11 301, Fax: (+48) 58 34 60 392
E-mail: mailbox@prs.pl, http://www.prs.pl/
IDENTITY CARD
It is the responsibility of the user organisation to provide the identity card and to fill in the details required. The identity card should be filled in before the
first use by a competent person, responsible inthe user organization for protective equipment. Any information about the equipment like periodic
inspections, repairs, reasons of equipment's withdrawal from use shall be noted into the identity card by a competent person in the user organization. The
identity card should be stored during a whole period of equipment utilization. Do not use the equipment without the identity card.
MODEL AND TYPE OF EQUIPMENT
SERIAL/BATCH NUMBER
REFERENCE NUMBER
USER NAME
PERIODIC INSPECTION AND REPAIR HISTORY CARD
DATE OF REASON FOR DEFECTS,
INSPECTION INSPECTION CONDITION NOTED
OR REPAIR REPAIRS CARRIED OUT
Louis Reyners BV, Symon Spiersweg 13a, 1506 RZ, Zaandam, The Netherlands, tel. +31 (0)756504750, fax +31 (0)756504760, www.lr.nl
DATE OF MANUFACURE
DATE OF PURCHASE
DATE OF FIRST USE
NEXT
NAME AND SIGNATURE
OF COMPETENT INSPECTION
PERSON DATE
INSTRUCTION MANUAL
Carefully read the manual before
using the equipment.
RETRACTABLE
0082
TYPE FALL ARRESTER
EN 360:2002
Retractable type fall arrester CR250HV is a component of personal
fall protection equipment compliant with EN 360:2002.
Retractable type fall arrester CR250HV provides protection for one
user.
Permissible user's weight is 120kg.
Available lengths of work cable:
- CR250HV 06 - 6 metres
- CR250HV 08 - 8 metres
- CR250HV 11 - 11 metres
Galvanized steel
work cable
DEVICE MARKING:
Before each
use check
function of the
locking gear.
Range of
device usage
temperatures
Store in rooms,
protect from direct
sunlight, moisture
and other aggressive
substances
Read the
manual before
use
Inspect the
device before
each use
Do not use
the device
with damaged
cable
CR250HV
Cable retractor with
brake and energy
absorber in plastic
housing
5mm
Ø
Permissible
inclination of
work line from
the vertical line Identity label
RETRACTABLE TYPE FALL ARRESTER
REF. CR 250 HV
Permissible
user's weight
Serial number: 00000000
Date of manufacture:: mm yyyy
Number of European standard
EN 360:2002
Use full body
CE mark and number of the notified
harness
body controlling production of the
compliant with
equipment
EN 361 only
0082
Do not release
Device's manufacturer or distributor mark
the device
cable suddenly
when extended
Snap hook with
2019
Do not repair
swivel (choice of
the device on alternative snap
your own hooks with optional
fall indicator)
Attach the device
Do not attach the
to a structural
device to a
anchor point
structural anchor
(anchor point) point (anchor point)
using handle for
using rotary holder
device
transportation
Upper rotary holder
(CR250V) used to
attach the device to
anchor point
Handle for device
transportation
Cable length:: ... m
Month and year of next
manufacturer's inspection. Do not
use the device after this date.
Note: Before first use mark the date
of the manufacturer's inspection
(date of first use + 12 months, e.g.
first use 01.2019 – mark inspection
01.2020)
The device is
suitable for
horizontal
operation
