User Manual
Rocstor 20W Smart USB-C Power Adapter
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
Introduction
This Rocstor 20W Smart USB-C Power Adapter is a high-performance and fashionable
design wall charger. It is equipped with one USB-C connectors for power. This wall
charger is specially designed for Type-C supported devices. This wall charger can
provide total 20W output. The unique design makes your life simpler and easier!
How to Use
1. Plug the travel charger into socket and the indicator light turns blue.
2. Plug the USB connector of the USB cable into the travel charger's output interface,
then plug the other end of the USB cable into the electronic device (such as mobile
phone, MP3, camera series).
3. Please unplug the travel charger after the electronic device is fully charged.
Note:
• For optimum performance, please use the travel charger according to the user
manual.
• Please unplug the travel charger after using.
(Our products have protection functions and the two tips above are suggestions
just for safety)
Package Contents
Before attempting to use this unit, please check the packaging and make sure
the following items are contained in the Packaging:
• 1 x Main Unit
• User Manual
Y10A256-W1
®
Features
Input:
100-240 VAC 50/60Hz
Output:
USB Type-C Connector
5V/3A,9V/2.22A,12V/1.67A
Features
• Allows 100-240V AC of input voltage.
• USB-C output: 5V/3A.9V/2.22A,12/1.67A.
• Accurate limited current output.
• Over current protection with Auto-recovery.
• Overload protection and over voltage protection.
• Short circuit protection with Auto-recovery.
• Over temperature protection with Auto-recovery.
• Select precision electrical components, re line version, and
imported re plastic.
• Portable and convenient to use.
Speci cation
Input / Output
Input
Output
Protection(for charger port)
Over Current Protection
Over Voltage Protection
Over Load Protection
Short Circuit Protection
Over Temperature Protection
Mechanical
Size (HxDxW)
Weight
Warranty
Limited Warranty
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Regulatory Approvals
Certi cations
Accessories
User Manual
100-240 VAC 50/60Hz
5V/3A,9V/2.22A,12V/1.67A
Yes
Yes
Yes
Yes
Yes
39.8 x 45.6 x 23 mm - 1.56 x 1.79 x 0.90 in
42 gr - 1.48 oz
2 Year
0~25°C
-20 ~ 85°C
20% ~ 90% RH
5% ~ 95%
CE,FCC,UL,ERP,DOE
English Version
