Description of the HOMELINE
The LA10 system consists of one or more Linear Actuators LA10, a Bluetooth
a charging point� The solution is designed for adjustable recliner chairs and meets user requirements for
reduced number of cables in the system� The LA10 actuator is intelligent and automatically detects its
position when connected in serial into a system� A Bluetooth
control unit, which is a wireless control placed in a bracket� To complete the design, the charging point is
available in different versions� The entire system is designed to meet user preferences and to fit the elegant
design of modern living-room furniture� In the newest system, the Battery BA002 offers a powerful solution
without a permanent cable to the application�
An LA10 system consists of:
• LA10 linear actuator
• BLE2DC Bluetooth
®
• BP11, BP12, or BP13 control unit
• Bracket for control unit
• Charging Point CP001, CP002, or CP003
• Battery Box BA002
• Switch Mode Power Supply SMPS001 or SMPS006
Configuration
The LA10 actuator can be configured via the LA10 configurator� A number of parameters can be adjusted
such as speed and stroke length�
Settings that are not default values, such as increased speed, will have influence on the product
lifetime, push force etc�
Changes made in the configurator are not tested and we cannot guarantee that the specifications
in the data sheet are met�

Maintenance

Clean dust and dirt from the outside of the system at appropriate intervals and inspect for damage and
breaks� Inspect the connections, cables, and plugs, and check for correct functioning as well as fixing points�
The cleaners and disinfectants must not be highly alkaline or acidic (pH value must be 6 to 8).
LA10 system
®
dongle
dongle, a control unit, and
®
dongle ensures the wireless connection to the
®
