10.3 Specifications
Electrical Connections
Power Requirements
Approvals
Physical Dimensions
Weight
Operating Temperature
Humidity
"This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
•
This device may not cause harmful interference
•
This device must accept any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his expense.
Modifications not expressly approved by FieldServer could void the user's authority to operate the equipment under FCC
rules."
NOTE: Specifications subject to change without notice.
One 3-pin Phoenix connector with: RS-485/RS-232 (Tx+ / Rx- / gnd)
One 3-pin Phoenix connector with: RS-485 (+ / - / gnd)
One 3-pin Phoenix connector with: Power port (+ / - / Frame-gnd)
Two Ethernet 10/100 BaseT port
Input Voltage: 9-30VDC or 24VAC
Max Power: 3 Watts
CE and FCC Part 15 C, UL 62368-1 and CAN/CSA C22.2, DNP 3.0 and Modbus
conformance tested, WEEE compliant, RoHS3 compliant, REACH compliant,
UKCA compliant
4 x 1.1 x 2.7 in (10.16 x 2.8 x 6.8 cm)
0.4 lbs (0.2 Kg)
-20°C to 70°C (-4°F to158°F)
10-95% RH non-condensing
QuickServer FS-QS-3X10-F Start-up Guide
FS-QS-3X10-F
Current draw: 24VAC 0.125A
9-30VDC 0.25A @12VDC
41
