10.3 Specifications

Electrical Connections
Power Requirements
Approvals
Physical Dimensions
Weight
Operating Temperature
Humidity
NOTE: Specifications subject to change without notice.

10.4 Warnings

FCC Class B
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
41
One 3-pin Phoenix connector with: RS-485/RS-232 (Tx+ / Rx- / gnd)
One 3-pin Phoenix connector with: RS-485 (+ / - / gnd)
One 3-pin Phoenix connector with: Power port (+ / - / Frame-gnd)
Two Ethernet 10/100 BaseT port
Input Voltage: 9-30VDC or 24VAC
Max Power: 3 Watts
FCC Part 15 C, UL 62368-1, CAN/CSA C22.2 No. 62368-1, EN IEC 62368-1, DNP 3.0 and
Modbus conformance tested, BTL Marked, WEEE compliant, RoHS compliant, REACH
compliant, UKCA and CE compliant, ODVA conformant, CAN ICES-003(B) / NMB-003(B)
4 x 1.1 x 2.7 in (10.16 x 2.8 x 6.8 cm)
0.4 lbs (0.2 Kg)
-20°C to 70°C (-4°F to158°F)
10-95% RH non-condensing
QuickServer Start-up Guide
FS-QS-3XX0-F
Current draw: 24VAC 0.125A
9-30VDC 0.25A @12VDC
