Specifications; Warnings - MSA fieldserver QuickServer FS-QS-2XX0-F Operating Manual

11.4 Specifications

Electrical Connections
Power Requirements
Approvals
Capacity Options
Physical Dimensions
Weight
Operating Temperature
Humidity
NOTE: Specifications subject to change without notice.

11.5 Warnings

FCC Class B
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
One 3-pin Phoenix connector with: RS-485/RS-232 (Tx+ / Rx- / gnd)
One 3-pin Phoenix connector with: RS-485 (+ / - / gnd)
One 3-pin Phoenix connector with: Power port (+ / - / Frame-gnd)
One Ethernet 10/100 BaseT port
Input Voltage: 9-30VDC or 24VAC
Max Power: 3 Watts
FCC Part 15 B & C, UL 60950-1, EN IEC 62368-1, WEEE compliant, RoHS compliant, DNP
3.0 and Modbus conformance tested, BTL marked, REACH compliant, UKCA and CE
compliant, ODVA conformant, CAN ICES-003(B) / NMB-003(B)
FS-QS-20X0: 250 data points
FS-QS-22X0: 500 data points
FS-QS-21X0: 1,000 data points
4 x 1.1 x 2.7 in (10.16 x 2.8 x 6.8 cm)
0.4 lbs (0.2 Kg)
-20°C to 70°C (-4°F to158°F)
10-95% RH non-condensing
QuickServer Start-up Guide
FS-QS-2XX0-F
Current draw: 24VAC 0.125A
9-30VDC 0.25A @12VDC
FS-QS-23X0: 3,000 data points
FS-QS-24X0: 5,000 data points
