7.2
Routing Settings
The Routing settings make it possible to set up the IP routing rules for the FieldServer's internet and network connections.
NOTE: The default connection is ETH1.
•
as either ETH 1 or ETH 2
•
Click the Add Rule button to add a new row and set a new Destination Network, Netmask and Gateway IP Address as
needed.
•
Set the Priority for each connection (1-255 with 1 as the highest priority and 255 as the lowest).
•
Click the Save button to activate the new settings.
20
QuickServer FS-QS-3X10-F Start-up Guide
