TANGO55/ & TANGO56/
I
8 HOW TO UPDATE THE NEW FIRMWARE INTO THE
TANGO55/56 MODEMS
In order to allow users of TANGO55/56 to utilize newly released firmware, a program
has to be available to update the on-board Flash-Memory. The update program
with the new firmware will be distributed electronically via Internet or CD.
The update procedure of a new firmware erases the whole internal
flash memory and the presettings stored on it will be absolutely erased,
too.
In order to update a new TANGO55/56 firmware, please, follow step-by-step the
instructions described below:
• Point your web browser to www.falcom.de, go to
firmware
or wswup_mc56_x.exe
• Connect the serial port of the TANGO55/56 to one of the available COM ports
on your PC (e.g. COM1).
• If TANGO55/56 is still powered on power it down. Make sure that the V+ and
IGN lines are disconnected from the external power source.
• Start "wswup_mc55_01.06.exe" Update program. The Dialog Window shown
below appears.
• Please, refer to the figure above for the following points. Select the Skip radio
button near the Pre-Check progress bar.
• Click on the "Serial Config" button, and in the "Com" settings box select the
COM port where your TANGO55/56 is connected (i.e COM1) and in the
"Baud" settings box select the Baud rate to 115200.
This confidential document is the property of FALCOM GmbH and may not be copied or circulated without permission.
I
TANGO55 or TANGO56
Update program, respectively.
support
and download the "wswup_mc55_x.exe"
V 1.03
ERSION
drivers &
Page 42
