The actual state of modems is displayed by two LED's at the connector on the top of
interface C of the unit.
600 ms On / 600 ms Off
Green LED (GSM)
Yellow LED
On

4.2.1 Ignition line

The Ignition Line on Interface A uses an internal processor to control the timing of the
"TURN-ON" procedure of the internal GSM modem.
To switch the modem ON the Ignition Line has to be connected to a high voltage
level of (10,8V ... 31,2V). The green LED on interface C shows the progress of the
"TURN-ON" procedure (green indicator light). Enter PIN number of the inserted SIM
card (if required). After a few seconds it will go flashing slowly (that means the
registration into the network is successfully). To switch the modem off the commands
AT+CPOF or AT+CFUN=0 (see AT commands manual) has to be issued. To switch the
modem on again see above.

4.2.2 Serial handling

The GSM/GPRS modem TANGO55/56 allows control of the GSM/GPRS modem over
the interface B or Interface C. The interface B is a implementation of a serial
interface corresponding to EIA-RS232-C.
See table below for details:
CCITT V24 Pin
102 5
103 3
104 2
105 7
106 8
107 6
108 4
109 1
125 9
Table 12: R232 9-pin description
