MV PUSH EU Owner's Manual
Push Multi-Vac Owner's Manual
CASTER KIT
Use on hard surface
For vacuuming hard
for maneuverability.
P/N 840129
IMPORTANT- READ CAREFULLY BEFORE USE AND KEEP FOR FUTURE REFERENCE.
Part No 840506
MV601EU
Accessories
HOSE KIT
BAG LINER KIT
To collect leaves,
to reach areas.
thatch, and grass.
P/N 840116
P/N 840134
Original Instructions
FELT BAG KIT
Use on all dusty
conditions.
P/N 840194
1
LINER KIT
Interior housing liner
to decrease housing
wear.
P/N 840201
840506_A_HI
Advertisement
Related Manuals for Billy Goat MV VACUUM PUSH EU MV601EU
Summary of Contents for Billy Goat MV VACUUM PUSH EU MV601EU
- Page 1 MV PUSH EU Owner’s Manual Push Multi-Vac Owner’s Manual MV601EU Accessories CASTER KIT HOSE KIT BAG LINER KIT FELT BAG KIT LINER KIT Use on hard surface For vacuuming hard To collect leaves, Use on all dusty Interior housing liner for maneuverability.
-
Page 2: Table Of Contents
MV PUSH EU Owner’s Manual CONTENTS SPECIFICATIONS INSTRUCTION LABELS ASSEMBLY INSTRUCTIONS OPERATION 9-11 MAINTENANCE AND TROUBLESHOOTING 11-13 ILLUSTRATED PARTS LIST 14-20 Part No 840506 840506_A_HI... -
Page 3: Specifications
MV PUSH EU Owner’s Manual SPECIFICATIONS MV601EU Engine Type Briggs and Stratton 850E Series Horsepower 5.5 (4.10 kW) Fuel Capacity 1.06 qt. (1.00 L) Oil Capacity 0.625 qt. (0.59 L) Engine Weight 10 kg (22 lb) Unit Weight 157 lbs (71.2 kg) Shipping Weight 180 lbs (81.7 kg) Overall Dimensions... -
Page 4: Instruction Labels
MV PUSH EU Owner’s Manual INSTRUCTION LABELS The labels shown below were installed on your BILLY GOAT ® MV Vacuum. If any labels are damaged or missing, replace them before operating this equipment. For your convenience in ordering replacement labels, part numbers are included in the Illustrated Parts List. -
Page 5: Assembly Instructions
MV PUSH EU Owner’s Manual ASSEMBLY INSTRUCTIONS Your BILLY GOAT ® MV Vacuum was shipped in one carton, completely assembled except for the Hood/Upper Handle Assembly. Mounting hardware for the Hood/Upper Handle Assembly is temporarily installed on the lower handle and the Housing Assembly. - Page 6 MV PUSH EU Owner’s Manual Fig. 3 Fig. 4 HERE HERE Fig. 6 Fig. 5 Fig. 7 Part No 840506 840506_A_HI...
- Page 7 MV PUSH EU Owner’s Manual NOZZLE DOOR LEVER UPPER HANDLE BRACE LOWER HANDLE NOZZLE DOOR MV Vacuum Assembly Drawing Part No 840506 840506_A_HI...
- Page 8 MV PUSH EU Owner’s Manual PARTS BAG PARTS LIST ITEM NO. PART NO. DESCRIPTON 840061 ROD LIFT NOZZLE DOOR 900407 TY- WRAP 8171003 WASHER 5/16" FLAT ZP 8160002 NUT LOCK 5/16"-18 8041006 SCREWCAP 1/4"-20 X 1" ZP 8041031 SCREWCAP 5/16" X 1 3/4" ZP 8171004 WASHER 3/8 FLAT 8172007...
-
Page 9: Operation
MV PUSH EU Owner’s Manual OPERATION OPERATOR CONTROLS The operator’s position is at the rear of the machine between the handlebars. The operator should STAND in a position to allow both handlebars to be grasped firmly, which allows sufficient leverage to steer the machine. Operator’s controls are shown below. - Page 10 MV PUSH EU Owner’s Manual VACUUM NOZZLE HEIGHT ADJUST For maximum pickup: Adjust nozzle height as close to debris as possible, but without blocking airflow into the nozzle. NOTE: Never bury nozzle into debris. The vacuum nozzle is raised and lowered by turning the crank handle clockwise and counter-clockwise.
-
Page 11: Maintenance And Troubleshooting
MV PUSH EU Owner’s Manual DEBRIS BAG Debris bags are normal replaceable wear items. Bag liners are available for use in various conditions where debris will be vacuumed. (See Bag Liner Accessories on page DO NOT place bag on or near hot surface, such as engine. Be sure engine has come to a complete stop before removing or emptying bag! *****TIPS***** Frequently empty debris to prevent bag overloading with more weight than you can lift. - Page 12 MV PUSH EU Owner’s Manual IMPELLER REMOVAL READ all safety instructions before servicing unit. DISCONNECT spark plug wire before servicing unit. 1. Wait for engine to cool and disconnect spark plug. 2. Drain fuel and oil from the engine. 3. Remove engine, impeller and mounting plate by removing bolts around outside of housing. 4.
- Page 13 MV PUSH EU Owner’s Manual TROUBLESHOOTING Problem Possible Cause Solution Will not vacuum or has poor Dirty or full debris bag or filter. Clean debris bag and filter. Shake bag clean vacuum performance. or wash. Nozzle height set too high or too low. Adjust nozzle height (see page 10).
-
Page 14: Illustrated Parts List
MV PUSH EU Owner’s Manual MV PUSH EU NOZZLE PARTS DRAWING Nozzle Assembly Part No 840506 840506_A_HI... - Page 15 MV PUSH EU Owner’s Manual MV PUSH EU NOZZLE PARTS LIST 350127 YOKE 1/2 - 20 350128 PIN YOKE 1/2" 840243 SCREWCAP BUTTON HEAD 3/8"-16 X 1 1/4" PL 8172009 WASHER 3/8" SAE ZP 8161042 NUT LOCK 3/8-16 LT WT THIN ZP 8041038 SCREWCAP 5/16 -18 x 3 1/2 8160002 NYLON INSERT LOCKNUT 5/16-18 UNC 8172020 WASHER FLAT FENDER 5/16...
- Page 16 MV PUSH EU Owner’s Manual MV PUSH EU ENGINE PARTS DRAWING Engine Assembly Part No 840506 840506_A_HI...
- Page 17 MV PUSH EU Owner’s Manual MV PUSH EU ENGINE PARTS LIST ITEM PART QTY. NUMBER DESCRIPTION 891221 ENGINE B&S 850E SERIES 840100 IMPELLER 12.75 WA SP VAC 840111 PLATE TOP WA PUSH VAC 840003 HOUSING PLASTIC 440153 WASHER 1.5 OD X .453 ID X .25 THK 9201087 SQ KEY 2.125 X .87 840220 BRACKET COVER TOP PLATE VAC...
- Page 18 MV PUSH EU Owner’s Manual MV PUSH EU HOOD PARTS DRAWING Hood Assembly Part No 840506 840506_A_HI...
- Page 19 MV PUSH EU Owner’s Manual MV PUSH EU HOOD PARTS LIST ITEM PART QTY. NUMBER DESCRIPTION 440013 CONTROL THROTTLE 840141 HOOD ASSY W/ LABEL MV VAC 840153 BRACKET BAG CHANNEL RH W/SEAL MV VAC 840196 SEAL BAG MV VAC 840037 TUBE HANDLE BRACE RH MV VAC 840038 TUBE HANDLE BRACE LH MV VAC...
- Page 20 MV PUSH EU Owner’s Manual MV PUSH EU REAR AXLE PARTS DRAWING Rear Axle Assembly MV PUSH EU REAR AXLE PARTS LIST ITEM PART QTY. NUMBER DESCRIPTION 8172011 WASHER FLAT 1/2" SAE 8024046 BOLT CARRIAGE 5/16-18X2 1/2 8171002 WASHER 1/4" FC ZP 8160002 NYLON INSERT LOCKNUT 5/16-18 UNC 8161044 NYLON INSERT LOCKNUT 1/2-13 UNC THIN 840091 SHAFT REAR AXLE PUSH VAC...
