2
OPTIONAL ACCESSORIES
CASTER KIT
P/N 430291
To improve maneuverability
on hard paved surfaces.
HOLD DOWN KIT
P/N 430299
For use on truck or trailer to
provide quick hold down for your
QB. (not available for QB554HC)
Operator Owner's Manual
3
Engine: HP
5.0 HP (3.73 kW) 8.0 HP (5.97 kW)
Engine:Type
HONDA OHC
Engine: Fuel cap.
2.1 qt. (2.0 L)
Engine: Oil Cap.
0.63 qt. (0.6 L)
Weight: Unit
98 # (44.5 Kg)
Weight: Shipping
120 # (54.5 Kq)
OVERALL LENGTH: 51.75"(1.31m) OVERALL WIDTH 28.5" (0.72m)
UNIT SIZE:
Part No. 430316
T h a n k Y o u f o r S e l e c t i n g
The Powerful QUIET BLOW
Patent No. 6253416
QB554HC, QB884H, QB994S, QB1004, QB1304H

Specifications

QB554HC
QB884H
HONDA OHV
6.4 qt. (6.1 L)
1.16 qt. (1.1 L)
136 # (61.7 Kg)
155 # (70.3 Kq)
BLOWER
®
For Models:
QB994S
9.0 HP (6.7 kW)
SUBARU OHV
6.4 qt. (6.1 L)
1.05 qt. (1.0 L)
134 # (60.9 Kg)
145 # (65.9 Kq)
Page 1 of 12
QB1004
10.0HP (7.45kW) 13.0HP (9.69kW)
B & S INTEK I/C
4.0 qt. (3.8 L)
0.875 qt.(0.8L)
136 # (61.7 Kg)
152 # (68.9 Kg)
154 # (70.0 Kq)
OVERALL HEIGHT
39" (0.99m)
Form No. F012004A
1
QB1304H
HONDA OHV
7.4 qt. ( 7.0 L)
1.2 qt.(1.13L)
170 # (77.3 Kg)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QB554HC and is the answer not in the manual?

Questions and answers

Related Manuals for Billy Goat QB554HC

Summary of Contents for Billy Goat QB554HC

  • Page 1: Specifications

    For use on truck or trailer to provide quick hold down for your QB. (not available for QB554HC) T h a n k Y o u f o r S e l e c t i n g The Powerful QUIET BLOW BLOWER ®...

  • Page 2: Table Of Contents

    IN THE INTEREST OF SAFETY BEFORE STARTING ENGINE, READ AND UNDERSTAND THE “ENTIRE OPERATOR'S MANUAL & ENGINE MANUAL.” THIS SYMBOL MEANS WARNING OR CAUTION. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR UNLESS INSTRUCTIONS ARE FOLLOWED CAREFULLY. The engine exhaust from this product contains chemicals known to the State of California to cause WARNING! cancer, birth defects or other reproductive harm.

  • Page 3: General Safety

    Install rear of handle brace (item 30) to upper handle vibration mounts using two lock nuts (item 32) also located in the hardware Your Billy Goat is shipped from the factory in one carton, bag. Hand tighten only. NOTE: 13 hp Honda models will have an offset completely assembled except for the upper handle assembly, bracket (item 65) installed at the front of the housing.

  • Page 4: Labels

    PARTS BAG & LITERATURE ASSY CONTROLS PARTS BAG ASSEMBLY CHECKLIST Throttle Control / Screw Cap Literature Checklist Gust Control 5/16-18 x 1 1/4 8041029 Qty. 1 Check Owner's Manual Washer 1/2 SAE 430316 8172011 Qty. 1 Start Stop STOP Quiet Blow fi START Series Blowers Screw Cap 3/8-16 x 3 3/4...

  • Page 5: Operation

    Secure in place during transport. BLOWING OPERATION 16.3 Your Billy Goat blower is equipped with a remote exhaust director to allow the operator to direct the air stream up or down as required to assist in moving debris. This feature is extremely useful when debris has piled up to the point that it cannot be blown any farther.
  • Page 6 OPERATION continued Side Discharge Down Position ADJUSTING AIR DIRECTOR 16.4 This position directs the air stream down at the ground to allow the operator to deliver the maximum power to debris When you lock the lever, the default position of air director is in the that is stuck or difficult to remove.

  • Page 7: Maintenance

    MAINTENANCE 17.3 IMPELLER REMOVAL Use only a qualified mechanic for any adjustments, disassembly or any 1. Wait for engine to cool and disconnect spark plug. kind of repair . 2. Remove front wheel (item 23),and front wheel bracket (item 27). WARNING: TO AVOID PERSONAL INJURY, ALWAYS 3.
  • Page 8 MAINTENANCE continued AIR FILTER COVER REMOVAL INSTRUCTION (BRIGGS AND STRATTON) Removing the air filter cover (for air filter change and throttle control installation) 1. Disconnect spark plug wire. 2. Remove the locknut and the screwcap holding the front part of the handle brace. 3.
  • Page 9 MAINTENANCE continued AIR FILTER COVER REMOVAL INSTRUCTION (HONDA 8 and 13 H.P.) Removing the air filter cover (for air filter change and throttle control installation) 1. Disconnect spark plug wire. 2. Remove the wingnut on the top of the air cleaner cover (fig. 1). 3.

  • Page 10: Parts Drawing & List

    PARTS DRAWING QB554HC, QB884H, QB994S, QB1004, QB1304H Part No. 430316 Form No. F012004A Page 10 of 12...
  • Page 11 QB554HC QB884H QB994S QB1004 QB1304H ITEM DESCRIPTION PART NO PART NO PART NO PART NO PART NO ENGINE - 13HP HONDA 430366 PARTS ENGINE - 10 HP BRIGGS & STRATTON INTEK 430352 LIST ENGINE - 8 HP HONDA 400937 ENGINE - 5.0 HP HONDA 430272 ENGINE - 9.0 HP SUBARU OHV...

  • Page 12: Troubleshooting

    Engine Service and Warranty WARRANTY PROCEDURE 22.1 Should a Billy Goat Machine fail due to a defect in material and / or Contact your nearest engine manufacturer's authorized servicing dealer. workmanship, the owner should make a warranty claim as follows:...
