- Page 1 ASSEMBLY RATING VERSION # 20-06-22...
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 1 0...
- Page 5 HARDWARE...
- Page 7 Align HB legs (#2R/L) to the headboard (#1), then secure by using bolts (#A) with washers (#B,C).
- Page 8 Attach FB legs (#4) to the footboard (#3), then attach support leg (#5) to footboard (#3). Align and hook the side rails (#5) to the headboard (#1) and footboard (#3). Make sure it is firmly in place.
- Page 9 Attach support legs (#9,10) to the center support rail (#8), then adjust leveler of the support legs (#10) according to ground level. Align slats (#7) to side rails, then secure by using screws (#H). Align center slat (#8) to the slats (#7), then secure by using bolts (#D) with washers (#E,F).
- Page 10 Align top side rails (#11) to the side rails (#5), then secure by using bolts (#J).
