For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7561D&M
DIFFICULT
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
Page 1 of 4
(Included)
Rev: 18-07-17
Advertisement
Related Manuals for Furniture of America CM7561D
Summary of Contents for Furniture of America CM7561D
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7561D&M ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being Allen Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 4...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 6pcs Bolt Ø1/4"x1-1/2" Dresser #2 x 1pc #B x 6pcs Spring washer Ø1/4" Mirror #C x 6pcs Flat washer Ø1/4"...
- Page 4 Align back support rails to the holes of the mirror (#2) and dresser (#1), then secure by using bolts (#A) with washers (#B,C). #A x 6pcs #B x 6pcs #C x 6pcs Page 4 of 4...
