For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7562D&M
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 4
(Included)
(Not Included)
Rev: 18-08-03
Advertisement
Related Manuals for Furniture of America CM7562M
Summary of Contents for Furniture of America CM7562M
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7562D&M ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 4...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Dresser Bolt Ø1/4" x 1-1/2" #2 x 1pc Φ1/4" #B x 8pcs Lock Washer Ø1/4"...
- Page 4 Align mirror supports (#4) to the holes of the mirrors (#3) and dresser (#1). Secure by using bolts (#A) with washers (#B,C). #A x 8pcs #B x 8pcs #C x 8pcs Attach support leg (#2) to the bottom of the dresser (#1). Adjust the leveler on the support leg (#2) according to ground level.
