ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
DIFFICULT
CM7561Q
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
Wrench
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Not Included)
(Included)
Rev: 18-07-17

Advertisement

loading
Need help?

Need help?

Do you have a question about the CM7561Q and is the answer not in the manual?

Questions and answers

Related Manuals for Furniture of America CM7561Q

Summary of Contents for Furniture of America CM7561Q

  • Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7561Q ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being Phillips Screwdriver easy and 5 being difficult).
  • Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
  • Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 14pcs #1 x 1pc Bolt Ø5/16"x1-3/4" Headboard panel #B x 14pcs #2 x 2pcs Lock washer Ø5/16"...
  • Page 4 Exploded View #A x 14pcs #B x 14pcs #C x 14pcs Align HB legs (#2R/L) to the holes of the headboard (#1) and HB support (#7), then secure by using bolts (#A) with washers (#B,C). Page 4 of 6...
  • Page 5 Attach threaded pins (#E) to the headboard (#1) and footboard (#3), then align the side rails (#4) to the threaded pins (#E). Secure by using hex nut (#F) with washer (#G). #E x 8pcs #F x 8pcs #G x 8pcs Attach support legs (#6) to the bed slats (#5).
  • Page 6 Align slats (#5) to the side rails (#4), then secure by using screws (#I). #I x 6pcs ASSEMBLY IS COMPLETED Page 6 of 6...
