VAG VIBRATION DAMPER ASSEMBLY TOOL CT5467

GENERAL

Specially designed to fix the timing chain
drive sprockets while installing and
removing the vibration damper on
VAG 1.8/2.0 TFSi/TSi EA888 engine.
Applications: Audi, Seat, Skoda,
Volkswagen
OEM number: T10531
Contents:
A - T10531/1
Vibration damper holding tool
B - T10531/3
Crankshaft sprocket holding tool adapter
C- T10531/2
Crankshaft sprocket holding tool
D - T10531/4
Crankshaft sprocket holding tool nut

SAFETY ADVICE

Be careful when working on hot engines - risk of burn!
Be careful when working on running engines. Loose clothes,tools and other things can be caught
up in revolving parts which may lead to serious injuries.
Remove the ignition key before repair so that the engine will not start unintentionally.
This manual is just brief information and will not replace a garage handbook. Always consult
specific service literature for information about torques, assemblies and disassemblies etc.
Keep all threads clean and well lubricated with Molybdenum Disulphide Grease.
Damage to threads due to incorrect use or overload cannot be warranted.
CANNON TOOLS LTD
Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K.
B
C
D
A
A
A
www.cannontools.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VAG CT5467 and is the answer not in the manual?

Questions and answers

Related Manuals for Neilsen VAG CT5467

Summary of Contents for Neilsen VAG CT5467

  • Page 1 VAG VIBRATION DAMPER ASSEMBLY TOOL CT5467 GENERAL Specially designed to fix the timing chain drive sprockets while installing and removing the vibration damper on VAG 1.8/2.0 TFSi/TSi EA888 engine. Applications: Audi, Seat, Skoda, Volkswagen OEM number: T10531 Contents: A - T10531/1 Vibration damper holding tool B - T10531/3 Crankshaft sprocket holding tool adapter...
  • Page 2 Instructions Preparation Turn the engine to TDC on No1 cylinder Holding the crankshaft pulley with a suitable holding tool loosen the vibration damper fixing bolt by 180° (1/2 a turn). Remove the 2 engine front cover fixing bolts as identified in the instructions for Vibration damper holding tool( A).
  • Page 3 D - Crankshaft sprocket holding tool nut Fit the holding tool nut D and tighten. If required the crankshaft is now safe to turn by turning the larger Hex of D. Only turn the engine over with the spark plugs removed. Applications CANNON TOOLS LTD www.cannontools.co.uk...
  • Page 4 Applications CANNON TOOLS LTD www.cannontools.co.uk Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K.
