- Page 1 Installer manual NIBE™ VVM 310 Indoor module IHB GB 1705-7 231175...
- Page 2 Quick guide Navigation Ok button (confirm/select) Back button (back/undo/exit) Control knob (move/increase/reduce) A detailed explanation of the button functions can be found on page 39. How to scroll through menus and make different settings is described on page 40. Set the indoor climate INDOOR CLIMATE HOT WATER MY INSTALLATION...
-
Page 3: Table Of Contents
6 Commissioning and adjusting Dimensions and setting-out coordinates Preparations Hot water capacity Filling and venting Technical specifications Start-up and inspection Electrical circuit diagram, 3 x 400V Setting the cooling/heating curve Setting hot water circulation Index Pool NIBE™ VVM 310 Table of Contents |... -
Page 4: Important Information
Marking VVM 310 is CE marked and fulfils IP21. The CE marking means that NIBE ensures that the product meets all regulations that are placed on it based on relevant EU directives. The CE mark is obligat- ory for most products sold in the EU, regardless where they are made. - Page 5 Safety valve Electricity (page 22) Connected communication Circuit fuses Fuses, indoor module Fuses property Outside sensor Room sensor Current sensor Safety breaker Earth circuit-breaker Setting of emergency mode thermostat Miscellaneous Docked to NIBE™ VVM 310 Chapter 1 | Important information...
- Page 6 NIBE Energy Systems France Sarl, Zone industrielle RD 28, Rue du Pou du Ciel, 01600 Reyrieux Tel : 04 74 00 92 92 Fax : 04 74 00 42 00 E-mail: info@nibe.fr www.nibe.fr NIBE Energy Systems Ltd, 3C Broom Business Park, Bridge Way, Chesterfield S41 9QG Tel: 0845 095 1200 Fax: 0845 095 1201 E-mail: info@nibe.co.uk www.nibe.co.uk...
-
Page 7: Delivery And Handling
All service on VVM 310 can be carried out from the front. 50 mm NOTE Leave 10 – 25 mm free space between the in- door module and the wall behind for routing of cables and pipes. NIBE™ VVM 310 Chapter 2 | Delivery and handling... -
Page 8: Removing The Covers
1. Remove the screws from the upper and lower edges. 2. Twist the cover slightly outward. 3. Move the hatch backwards and slightly to the side. 4. Pull the cover to one side. 5. Pull the hatch forwards. Chapter 2 | Delivery and handling NIBE™ VVM 310... -
Page 9: Indoor Module's Design
VVM 310 VVM 310 AA4-XJ4 AA3-X4 BF1* BT30 AA1-X3 AA1-S2 BT54 AA1-X7 AA1-X1 QN35 GP12 XL30 XL18 XL19 *Applies to VVM 310 EMK. Available as accessory EMK 310 for other markets. NIBE™ VVM 310 Chapter 3 | Indoor module's design... - Page 10 AA3-X4 Terminal block, current sensors Display unit AA4-XJ3 USB socket AA4-XJ4 Service socket Extra relay circuit board BF1* Energy meter Immersion heater *Applies to VVM 310 EMK. Available as accessory EMK 310 for other markets. Chapter 3 | Indoor module's design NIBE™ VVM 310...
-
Page 11: Pipe Connections
If the standard initial pressure in the pressure vessel is NIBE recommends installing VVM 310 as close to the not high enough it can be increased by filling via the heat pump as possible for optimum comfort. For further valve in the expansion vessel. - Page 12 Shunt / shuttle valve Safety valve Thermometer Temperature sensor Expansion vessel Pressure gauge Circulation pump Particle filter Particle filter Flow meter EMK 310 Compressor Heat exchanger Radiator system Domestic hot water Under floor heating systems Chapter 4 | Pipe connections NIBE™ VVM 310...
-
Page 13: Dimensions And Pipe Connections
Ø22 mm XL14 Connection, solar heating system return line Ø22 mm XL18 Connection, docking in high temp Ø22 mm XL19 Connection, docking out high temp Ø22 mm XL30 Connection, expansion tank G20 int. NIBE™ VVM 310 Chapter 4 | Pipe connections... -
Page 14: Installation Alternative
Extra hot water heaters Water heater with immersion heater If it is possible to use a water heater with an immersion heater, NIBE COMPACT or EMINENT type water heaters can be used. If the valve connector is to be installed externally, moved out or separated, it must be replaced with a separable connector Ø... - Page 15 Shut-off valve Safety valve, heating medium Pump, solar External heat source (Oil, gas, pellets or wood fired boiler with shunt valve) *Energy meter (BF1) included in VVM 310 EMK. AA25 Unit box with accessory card BT52 Temperature sensor, boiler GP15...
- Page 16 When connecting to a system with thermostats on all -CM1 radiators/underfloor heating coils, a relief valve must be fitted, or a thermostat must be removed to ensure sufficient flow. -XL8 -XL9 -EB15-FL2 -EB15 -EB15 -XL1 -CM1 -XL2 -EB15 Chapter 4 | Pipe connections NIBE™ VVM 310...
- Page 17 -QM41 -EB15 -XL2 -QM1 *Energy meter (BF1) included in VVM 310 EMK. Available as ac- cessory EMK 310 for other markets. Connecting EMK 300 Installing energy measurement kit EMK 300 (BF2) to VVM 310. This accessory is used if energy measurement of pool or 4-pipe cooling is required.
- Page 18 For connection to solar installation, the SCA 35 accessory is required, see "Accessories" on page 58. -EB15 -FL2 -CM1 -XL13 -XL14 -EP30 -BT53 -EB15 -EP8 -EB101 -AA5 -CM5 -GP30 -FL10 -RM4 -RM3 -QM40 -FL4 -GP4 -EP5 -XL1 -GP4 -HQ1 -QM41 -OM44 -XL2 -OM45 -OM43 -QM1 Chapter 4 | Pipe connections NIBE™ VVM 310...
- Page 19 The demand on F135 is controlled by the indoor module in the system. The pump and fan speed are also controlled from the menu in the indoor module. -AZ10 -AZ10 -HQ1 -GP10 -QM42 -QM43 -EB15-FL2 -EB15 -CM1 -RM1 -EB15 -EB101 -FL10 -EB101 -QM40 -XL1 -HQ1 -QM41 -XL2 -QM1 NIBE™ VVM 310 Chapter 4 | Pipe connections...
- Page 20 -HQ1 -GP10 -AA25 -QM42 -QM43 -CL11 -GP12 -EQ1 -EB15 -QM44 -FL2 -AA25 -GP13 -EB15 -CL11 -CM1 -QN19 -CP10 -RM1 -GP12 -BT64 -QN12 -EB15 -EB101 -FL10 -EB101 -QM40 -XL1 -HQ1 -QM41 -XL2 -QM1 Chapter 4 | Pipe connections NIBE™ VVM 310...
- Page 21 CO neutral at the time. -EM1 -AA25 -FL1 -EM1 -EB15 -RM1 -QM40 -FL2 -EM1 -QM43 -EB15 -EM1 -CM1 -EM1 -QM42 -RM1 -EB15 -EB101 -FL10 -EB101 -QM40 -XL1 -HQ1 -QM41 -XL2 -QM1 NIBE™ VVM 310 Chapter 4 | Pipe connections...
-
Page 22: Electrical Connections
NOTE Miniature circuit-breaker If the supply cable is damaged, only NIBE, its The indoor module and a large proportion of its intern- service representative or similar authorised al components are internally fused by a miniature cir- person may replace it to prevent any danger cuit breaker (FA1). - Page 23 1. Push the catch down. 1. Insert the screwdriver (A) and pry the catch care- fully downwards (B). 2. Angle out the cover and remove it. 2. Angle out the cover and remove it. NIBE™ VVM 310 Chapter 5 | Electrical connections...
- Page 24 Cable lock Use a suitable tool to release/lock cables in the indoor module terminal blocks. Chapter 5 | Electrical connections NIBE™ VVM 310...
-
Page 25: Connections
If a conduit is used it must be sealed to prevent con- give a noticeable difference in room temperat- densation in the sensor capsule. ure. External VVM 310 VVM 310 VVM 310 AA3-X6 AA3-X6 NIBE™ VVM 310 Chapter 5 | Electrical connections... - Page 26 (AA3). F20XX VVM500 F2030/F2040 VVM 310 VVM 310 AA3-X4 AA3-X4 F2026 VVM 310 F2026 VVM500 AA3-X4 F20XX VVM500 F2020/F2025 VVM 310 AA3-X4 F2120 Inomhusmodul F2120 VVM 310 AA3-X4 AA3-X4 Chapter 5 | Electrical connections NIBE™ VVM 310...
-
Page 27: Settings
In the event of overload of the set fuse size, where the installed heat pump is frequency controlled, the immer- sion heater's power stage is first stepped out, then the compressor is restricted. För frånluftsvärme! NIBE™ VVM 310 Chapter 5 | Electrical connections... - Page 28 This means that the maximum power output (maxim- um installed electrical output for heating) can be locked in menu 5.1.13. To then change the maximum power output, parts of the product must be replaced. Chapter 5 | Electrical connections NIBE™ VVM 310...
-
Page 29: Optional Connections
This means that when an climate system. external switch function or sensor is connected to one Use a 2 core cable of at least 0.5 mm2 cable area. NIBE™ VVM 310 Chapter 5 | Electrical connections... - Page 30 Normal mode (A: Open, B: Open) ■ "SG Ready" is not active. No effect on the system. Low price mode (A: Open, B: Closed) ■ Chapter 5 | Electrical connections NIBE™ VVM 310...
- Page 31 F1X45 VVM 310 NOTE External Externt In systems with both under floor heating and radiators, NIBE ECS 40/41 should be used for optimum operation. AA3-X7 Possible selection for AUX output (potential free variable relay) Circulation pump It is possible to have an external connection through the relay function via a potential-free variable relay (max 2 A) on the input board (AA3), terminal block X7.
-
Page 32: Connecting Accessories
Refer to the accessory manual for further instructions. EB15 VVM320 VVM 310 AA3-X4 VVM 310 VVM 320 VVM325 VVM325 VVM 500 AA3-X4 VVM 325 VVM 500 Accessory card 1 AA5-X4 AA5-X4 -X10 Accessory card 2 AA5-X4 AA5-X4 -X10 Chapter 5 | Electrical connections NIBE™ VVM 310... -
Page 33: Commissioning And Adjusting
". 2. Check that the drain valve is fully closed and that the temperature limiter (FD1) has not deployed. 3. Compatible NIBE air/water heat pumps must be equipped with a control card with display that has VVM 310 at least the software version given in the list on page 14. -
Page 34: Start-Up And Inspection
1. Use the control knob to select the help symbol. 2. Press the OK button. The help text often consists of several windows that you can scroll between using the control knob. Chapter 6 | Commissioning and adjusting NIBE™ VVM 310... - Page 35 If gurgling sounds can be heard from the climate system, the entire system will require addi- tional venting. Vent the installation through the vent valves (QM20). When venting, VVM 310 must be off. NIBE™ VVM 310 Chapter 6 | Commissioning and adjusting...
-
Page 36: Setting The Cooling/Heating Curve
If you only have one climate system, the num- ber of the curve is already marked when the menu window opens. 1. Select the climate system (if more than one) for which the curve is to be changed. Chapter 6 | Commissioning and adjusting NIBE™ VVM 310... -
Page 37: Setting Hot Water Circulation
2 °C. "operating time" decide how long the hot water circu- lation pump must run per operating instance. NIBE™ VVM 310 Chapter 6 | Commissioning and adjusting... -
Page 38: Nibe™ Vvm
With overcapacity mode on "SG Ready", the desired pool temperature (start and stop temperature) is in- creased by 2 °C. NOTE The function must be connected to two AUX inputs and activated in menu 5.4. Chapter 6 | Commissioning and adjusting NIBE™ VVM 310... -
Page 39: Control - Introduction
The control knob can be turned to the right or left. You can: ■ scroll in menus and between options. ■ increase and decrease the values. ■ change page in multiple page instructions (for example help text and service info). NIBE™ VVM 310 Chapter 7 | Control - Introduction... -
Page 40: Menu System
Menu 3 - INFO This symbol indicates whether VVM 310 Display of temperature and other operating informa- has contact with NIBE NIBE Uplink. tion and access to the alarm log. See information in the help menu or user manual. This symbol indicates the actual speed of... - Page 41 To change and return to the original value, press the Back button. If the start guide is left on this page it closes automatically in 60 min NIBE™ VVM 310 Chapter 7 | Control - Introduction...
- Page 42 1. Use the control knob to select the help symbol. 2. Press the OK button. The help text often consists of several windows that you can scroll between using the control knob. Chapter 7 | Control - Introduction NIBE™ VVM 310...
-
Page 43: Control - Menus
1.9.5 - cooling settings * 1.9.6 - fan return time * 1.9.7 - own curve 1.9.7.1 - heating 1.9.7.2 - cooling * 1.9.8 - point offset 1.9.11 - +Adjust * Accessories are needed. NIBE™ VVM 310 Chapter 8 | Control - Menus... -
Page 44: Menu 2 - Hot Water
Menu 3 - INFO 3 - INFO 3.1 - service info 3.2 - compressor info 3.3 - add. heat info 3.4 - alarm log 3.5 - indoor temp. log * Accessories are needed. Chapter 8 | Control - Menus NIBE™ VVM 310... -
Page 45: Menu 4 - My System
Menu 4 - MY SYSTEM 4 - MY SYSTEM 4.1 - plus functions 4.1.1 - pool * 4.1.3 - internet 4.1.3.1 - NIBE Uplink 4.1.3.8 - tcp/ip settings 4.1.3.9 - proxy settings 4.1.4 - sms * 4.1.5 - SG Ready 4.1.6 - smart price adaption™... -
Page 46: Menu 5 - Service
(AA3). on the display to the right of the menus. factory setting service Total reset of all settings (includ- ing settings available to the user ) to default values. Chapter 8 | Control - Menus NIBE™ VVM 310... - Page 47 Factory setting speed 2: 30 % Factory setting speed 3: 80 % Factory setting speed 4: 100 % Set the speed for the four different selectable modes for the fan here. NIBE™ VVM 310 Chapter 8 | Control - Menus...
- Page 48 Menu 5.1.13 - max inst. el.pwr (BBR) This menu contains several sub-menus, one for each max installed el.pwr (only this machine) standard. Setting range: 0.000 - 30.000 kW Default values: 15.000 kW Chapter 8 | Control - Menus NIBE™ VVM 310...
- Page 49 Mark “search installed acc." and press the OK button to automatically find connected accessories for VVM 310. Menu 5.3 - accessory settings The operating settings for accessories that are installed and activated are made in the sub-menus for this. NIBE™ VVM 310 Chapter 8 | Control - Menus...
- Page 50 Here you can set the temper- ature in the solar panel at which the circulation pump is to start to prevent freezing. Chapter 8 | Control - Menus NIBE™ VVM 310...
- Page 51 If less than seven periods NOTE are to be used, set the remaining period times to 0 days. When resetting, the start guide is displayed the next time the indoor module is restarted. NIBE™ VVM 310 Chapter 8 | Control - Menus...
- Page 52 Language settings can be made regardless of this selec- tion. NOTE This option locks after 24 hours, restart of dis- play or program updating. Chapter 8 | Control - Menus NIBE™ VVM 310...
-
Page 53: Service
351.0 3.256 with the necessary expertise. 251.6 3.240 When replacing components on VVM 310 only 182.5 3.218 replacement parts from NIBE may be used. 133.8 3.189 99.22 3.150 Emergency mode 74.32 3.105 Emergency mode is used in event of operational inter- 56.20... - Page 54 VVM 310. VVM 310 from NIBE. INDOOR CLIMATE HOT WATER The fact box at the top of the display shows information...
- Page 55 2. Tick “activated". 3. The present values from VVM 310 are saved in a file in the USB memory at the set interval until “activated" is unticked. NOTE Untick "activated" before removing the USB memory. NIBE™ VVM 310 Chapter 9 | Service...
-
Page 56: Disturbances In Comfort
Check any external switches. ■ Air in the climate system. ■ Vent the climate system (see page 33) ■ (QM20), (QM32) to the climate system. ■ Closed valves to the climate system. Chapter 10 | Disturbances in comfort NIBE™ VVM 310... - Page 57 ■ set. Minimum time between compressor starts has not ■ been reached. Wait 30 minutes and check if the compressor has ■ started. Alarm tripped. ■ Follow the display instructions. ■ NIBE™ VVM 310 Chapter 10 | Disturbances in comfort...
-
Page 58: Accessories
When there is no internet connection, you can use the accessory SMS 40 to control VVM 310 via SMS. OPT 10 is used to enable connection and control of gas boiler NIBE GBM 10-15. Part no. 067 073 Part no. 067513... - Page 59 PV3031 3 kW Part no. 057 116 Top cabinet Top cabinet to conceal any pipes. 245 mm 345 mm Part no. 089 756 Part no. 089 757 395-645 mm Part no. 089 758 NIBE™ VVM 310 Chapter 11 | Accessories...
-
Page 60: Technical Data
12 Technical data Dimensions and setting-out coordinates Chapter 12 | Technical data NIBE™ VVM 310... -
Page 61: Hot Water Capacity
Hot water capacity Tap flow Varmvattenkapacitet VVM310 (litres/minute) Tappflöde (l/m) Economy Ekonomi Normal Normal Economy Ekonomi Normal Normal Volym varmvatten (liter) Volume hot water (litres) NIBE™ VVM 310 Chapter 12 | Technical data... -
Page 62: Technical Specifications
IP 21 3x400V 3x400V Maximum heat pump output NIBE F2020 with program version 118 or later Maximum heat pump output NIBE F2025 with program version 55 or later Maximum heat pump output NIBE F2026 with program version 55 or later... - Page 63 Height (with base) 1,830 – 1,850 Required ceiling height 1,910 Weight (excl. packaging and without water) Part number, EMK 310 included (only for Germany, Switzerland and Austria) 069 084 Part no. 069 430 NIBE™ VVM 310 Chapter 12 | Technical data...
-
Page 64: Electrical Circuit Diagram, 3 X 400V
Electrical circuit diagram, 3 x 400V Chapter 12 | Technical data NIBE™ VVM 310... - Page 65 NIBE™ VVM 310 Chapter 12 | Technical data...
- Page 66 Chapter 12 | Technical data NIBE™ VVM 310...
- Page 67 NIBE™ VVM 310 Chapter 12 | Technical data...
- Page 68 Chapter 12 | Technical data NIBE™ VVM 310...
-
Page 69: Index
Display, 39 Connecting EMK 310, 17 OK button, 39 Connecting hot water circulation, 18 Status lamp, 39 Connecting pool, 19–21 Switch, 39 Connecting the climate system, 16 Connecting to heat pump, 16 NIBE™ VVM 310 Chapter 13 | Item register... - Page 70 Draining the climate system, 53 Draining the hot water heater, 53 Standby mode, 53 Temperature sensor data, 53 USB service outlet, 54 Setting a value, 41 Setting hot water circulation, 37 Settings, 27 Emergency mode, 27 Chapter 13 | Item register NIBE™ VVM 310...
- Page 72 WS name: -Gemensamt WS version: a172 (working edition) Publish date: 2016-04-05 15:15 NIBE AB Sweden Hannabadsvägen 5 Box 14 SE-285 21 Markaryd info@nibe.se www.nibe.eu 231175...
