Figure 12: Examples of mounting with self-cutting thread inserts (left) and through holes (right)

3.3 Sound Pressure Level

The sound pressure level emitted by the BFS-i06 depends strongly on the installation, operating point, and
rotational speed. It is recommended that customers measure the sound pressure level after installation of the
fan in their setup during typical operation.
Figure 13 shows the sound pressure levels measured at Levitronix
2 m above ground into a closed duct system. Measurements were taken based on Semi S2 guidelines, i.e.
1 m traversed from the setup at a height of 1.2 m and 1.5 m above ground.
70
68
66
64
62
60
58
56
54
24 V Supply Voltage,
52
Released Performance
50
8000 8500
Figure 13: Sound pressure level vs rotational speed and measurement height
PL-3502-00, Rev00, DCO# 21-249
9000 9500 10000
Typical measured values of BFS-i06.1 installed in a closed duct system
® . The fan was installed at a height of about
10500 11000 11500
Rotational Speed / rpm
User Manual for BFS-i06
www.levitronix.com
1.5 m above
ground
1.2 m above
ground
48 V Supply Voltage,
Released Performance
12000 12500 13000
