General Environmental Conditions - Levitronix BFS-i06 User Manual

Pos. Component Article Name
Bearingless Fan
1 BFS-i06.1
(ATEX / IECEx)
Pos. Component Article Name
Set of ICP-5.1-03
2 Cable Adapter Set
and ICS-5.1-03
Cable Adapter Power,
2a Open Wires with ICP-5.1-03
TE Connector
Cable Adapter Signals,
2b Open Wires with ICS-5.1-03
TE Connector
3 AC/DC Power Supply
RS485 to USB
4 YN-485I-TR
Adaptor-TR Isolated
ATEX Cable ACS-A.1
5
Sealing System (Roxtec)

2.2 General Environmental Conditions

Condition
Usage
Altitude
Operating ambient temperature
Storage ambient temperature
(Extremes for Transportation)
Operating humidity range (relative humidity)
Storage humidity range (relative humidity)
(Extremes for Transportation)
Normal storage conditions
DC supply fluctuations
Transient over-voltages typically present on
the mains supply
Pollution degree
PL-3502-00, Rev00, DCO# 21-249
Article # Characteristics
Voltage, Power Input
Max. Pressure, Max. Flow
Point of Max. Power
ATEX / IECEx Marking
IP Rating
Electrical Interfaces
100-10184
Standard Firmware
Mechanical Interface
Cable Length
Materials
Weight
Table 1: Specification of standard configuration
Article # Characteristics
100-91510
Connector
190-10463
Wires
Connector
190-10464
Wires
Structure/Design
100-30392
Purpose
Materials
100-90292
Note
Table 2: Specification of standard accessories
Table 3: Environmental conditions for bearingless fan
Value / Feature
48 V DC ±10%, 240 W
(Option: 24 V DC ±5%, 65 W, with reduced max. speed of 8000 rpm.)
915 Pa (3.68 inH O), 8.4 m
2
3
850 Pa, 7.3 m /min, 13000 rpm
(optional 24 V supply voltage: 320 Pa, 4.4 m
II 2G Ex h mb IIC T6 Gd
1258 II 2D Ex h mb IIIC T85 °C Db
Ambient and gas temperature range 0 to 40°C
IP67
PLC 2 analog inputs
with 1 analog output
2 digital inputs
2 digital outputs
RS485 interface, Modbus protocol (extended control or service through
®
fieldbus or Levitronix
V3.48 (with maximum rotational speed 13000 rpm).
Flange on both motor sides with mounting holes 4 x Ø 12 mm on
diameter 138 mm. Flange inside Ø 100 mm, outside 120 mm x 120 mm.
5 m + 0.2 m wires with TE connectors for power and PLC signals.
Polypropylene, electrically conductive, flame retardant.
Cable: PVC jacket, PVDF bushing.
1.4 kg, 3.1 lb
Value / Feature
See 2a and 2b
TE Connectivity D 3200 1-179553-3
2
0.3 m, 3 x 1.5 mm , with wire end sleeves, PVC insulated
TE Connectivity D 1200 1-1903131-6
2
0.3 m, 12 x 0.14 mm , wire end sleeves on 3 RS485 bus relevant wires,
PVC insulated
See section 3.1.2 for a list of compatible and tested power supplies.
USB connector (A) with termination resistor and cable (2m) with
connector pair (B and C) for external RS485 wire connection.
Magnetically isolated. Included is a USB space saver cable (D).
Control or service of the fan via USB port of a PC.
Sleeve (A) and Gasket (B): Stainless Steel, EPDM
Frame(C) and 2x Cable Module (D): Roxylon (EPDM Rubber)
Lubricant (E) and measurement plates (F) are included.
Limits
Indoor
Up to 2000 m
0 to 40°C
-20 to 80°C
15 – 95% (non-condensing)
15 – 95% (non-condensing)
Ambient temp.: 20 to 30°C
Relative humidity: 50% (non-condensing)

10% of nominal voltage
Surge immunity according to EN 61000-4-5
(tested together with certified AC/DC power supply)
2
