Hay CONNECT BED Instruction Manual
Hide thumbs Also See for CONNECT BED:

Advertisement

Quick Links

– INSTRUCTION MANUAL –
CONNECT BED
DESIGN BY LEIF JØRGENSEN

Advertisement

loading
Need help?

Need help?

Do you have a question about the CONNECT BED and is the answer not in the manual?

Questions and answers

Summary of Contents for Hay CONNECT BED

  • Page 1 – INSTRUCTION MANUAL – CONNECT BED DESIGN BY LEIF JØRGENSEN...
  • Page 3 – PARTS –   Frame profile x2 Frame profile x2    Screw* Slats* Middle leg x1    Support bar x2 Feet x4 Allen key x1 Screw x15 (Only with 140x200, 160x200 and 180x200) *Sold separately in some markets...
  • Page 4   Place the corner of profile on top of the corner of profile...
  • Page 5   Insert the leg of profile into the hole in the leg of profile...
  • Page 6  Push down on profile until the two are flush with each other. Repeat steps 2 and 3 for all four corners.
  • Page 7  Screw in the screws with the supplied Allen key. Do not fully tighten each screw until all parts are assembled in the right position.  Attach feet and make sure that the profiles reach all the way down to the bottom.
  • Page 8 Done!
  • Page 9 For the 140 x 200, 160 x 200 and the 180 x 200 version of the Connect Bed,   2 x support bars are included. Start with connecting them using the screw D. . Depending on your mattress, you have two options for placing the ...
  • Page 10   Align the support bars with the holes in the profiles  Line up the middle leg underneath.
  • Page 11  Secure them with the screws , using the supplied Allen key.
  • Page 12   Mount the slats* using the screws . Fasten with the Allen key. Mount all the screws loosely before tightening them completely. *Sold separately in some markets...
  • Page 13: Care And Maintenance

    – CARE & MAINTENANCE – Our Care & Maintenance offers guidance for optimal maintenance of your HAY product. It includes advice and instructions on cleaning and caring for specific materials to prolong the life of your furniture. Please find our Care & Maintenance...
  • Page 16 Havnen 1 8700 Horsens Denmark +45 4282 0282 / hay@hay.com www.hay.com 18/03/2022...
