Page 3
– PARTS – Modules may vary from the ones shown in the instructions. Left armrest x1 Right armrest x1 Middle x2 Right corner x1 Hook x1 Screw Allen key x1...
Page 4
Protect the sofa from scratches and other damage while assembling.
Page 5
Turn the left armrest on its side (2 persons recommended).
Page 6
Align part with the holes on part Insert part in the holes. Use the Allen key to tighten the parts completely.
Page 7
Stand the left armrest upright again (2 persons recommended).
Page 8
Repeat steps 1, 2, 3, 4 and 5 on parts NOTICE Make sure that part is mounted onto the correct side of parts Place the sofa modules in their positions ready to be connected (2 persons recommended).
Page 9
Lower part onto part , which is mounted on part (2 persons recommended).
Page 10
Repeat step 8 on parts until the sofa is completed (2 persons recommended).
– MAINTENANCE – Over time, your sofa will need some attention to ensure that the cushions remain plump and the seat cushion keeps its shape. To ensure that the cushions’ filling is spread evenly, follow these steps to plump the cushions. Repeat regularly when needed. More information on your specific fabric can be found under care and maintenance.
Page 12
STRAIGHTEN FABRIC REMOVING CREASES Straighten fabric on all modules.. Press the fabric down between each module.
– CARE & MAINTENANCE – Our Care & Maintenance offers guidance for optimal maintenance of your HAY product. It includes advice and instructions on cleaning and caring for specific materials to prolong the life of your furniture. Please find our Care & Maintenance...
