FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do not use any phone in your building.
Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's instructions.
If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency, or the supplier.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030
SAFETY INFORMATION
WARNING
!
Phone 1 (866) 820-8686 • www.napoleon.com • hearth@napoleon.com
OWNER'S MANUAL
ENGLISH
FRENCH PG. 21
Elevation™ Series
(E42 illustrated)
For indoor use only
W415-2950 / A / 08.10.21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elevation E36NT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Napoleon Elevation E36NT

  • Page 1 - Installation and service must be performed by a qualified installer, service agency, or the supplier. Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030 Phone 1 (866) 820-8686 • www.napoleon.com • hearth@napoleon.com...
  • Page 2 safety information WARNING • This appliance is hot when operated and can cause • Under no circumstances should this appliance be severe burns if contacted. modifi ed. • Any changes to this appliance or its control can be • This appliance must not be connected to a chimney dangerous and are prohibited.
  • Page 3: Table Of Contents

    Changes, other than editorial, are denoted by a vertical line in the margin. This appliance is suitable for use with Napoleon’s optional Universal Heat Management system. THIS MANUAL DOES NOT include detailed information relating the optional sytem. Framing and finishing are NOT the same. For further details, refer to UHM instructions provided with the kit before starting installation.
  • Page 4 Napoleon is proudly committed to your total home comfort. We are proud to say that our products continunously surpass industry standards and our inspiration is you! More than anything, we want you to feel confident in choosing Napoleon for your home. Our products are designed to provide that confidence and ensure that every Napoleon product is beyond compare.
  • Page 5: Getting To Know Your Appliance

    getting to know your appliance 1.0 getting to know your appliance The area above the appliance opening including the safety barrier, barrier frame and the surface of the wall can get very hot during operation and should never be touched until the appliance is off and completely cooled.
  • Page 6: Control Access

    Recessed depth X” Profondeur d’encastré une face X” L’appareil doit être ventilé à l’aide de l’ensemble d’évacuation propre à Napoleon. Référez au *** Mantel X” from appliance opening *** Tablette X” de l’ouverture de l’appareil manuel d’installation pour les spécifications d’évacuation. Il est nécessaire de bien réinstaller et *** Maximum horizontal extension: *** L’extension horizontale maximale: X”.
  • Page 7: Operating And Lighting Instructions (Millivolt)

    getting to know your appliance operating and lighting instructions (millivolt) WARNING • If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury, or loss of life. • If applicable, always light the pilot whether for the fi rst time or if the gas supply has run out with the glass door opened or removed.
  • Page 8: Operating And Lighting Instructions (Electronic)

    operation operating and lighting instructions (electronic) WARNING • If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury, or loss of life. • If applicable, always light the pilot whether for the fi rst time or if the gas supply has run out with the glass door opened or removed.
  • Page 9: Pilot-On-Demand (Electronic)

    In order to start your pilot, turning the main burner on with the switch, remote or thermostat and then turning it off will reactivate the continuous pilot mode and reset the seven day timer. For further information, refer to www.napoleon.com/pilotondemand. 31.2A...
  • Page 10: Clearances Around Appliance

    2.0 clearances around appliance clearances around fireplace WARNING • Your appliance, gas/electrical connections, venting and various key components are hidden behind the wall. It is critical that no screws penetrate these components. Failure to follow instructions may cause improper operation, damage, personal injury or fire.
  • Page 11 clearances around fireplace Flush installation with Flush installation without Recessed installation with mantel mantel protrusion 6” min. 6” min. TV bracket The volume of TV bracket TV bracket air must be added to the enclosure to accomodate 2.5” min.* 2.5” min.* the recessed area.
  • Page 12: Maintenance

    3.0 maintenance maintenance WARNING • Turn off the gas and electrical power before servicing the appliance. • Appliance may be hot. Do not service until appliance has cooled. For qualified technicians only: • Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation.
  • Page 13: Care Of Plated Parts

    maintenance care of plated parts If the appliance is equipped with plated parts, you must clean fi ngerprints or other marks from the plated surfaces before operating the appliance for the fi rst time. Use an ammonia-free or vinegar-based cleaner and a towel to clean.
  • Page 14: Replacement Parts

    4.0 replacement parts replacements WARNING • Failure to position the parts in accordance with this manual or failure to use only parts specifi cally approved with this appliance may result in property damage or personal injury. Contact your dealer for questions concerning prices and policies on replacement parts. Normally, all parts can be ordered through your Authorized dealer / distributor.
  • Page 15: E36 Accessories

    5.0 E36 accessories accessories Items may not appear exactly as illustrated. Ref. Part Number Description Stocked FTEX36BK Finishing Trim (Black) FTEX36CH Finishing Trim (Charcoal) BTEX36 Bevelled Trim ZEX36BK Zen Front (Black) ZEX36CH Zen Front (Charcoal) DBPEX36NS Decorative Brick Panels (Newport Standard) DBPEX36WS Decorative Brick Panels (Westminster Standard) DBPEX36OS...
  • Page 16: E42 Accessories

    6.0 E42 accessories accessories Items may not appear exactly as illustrated. Ref. Part Number Description Stocked FTEX42BK Finishing Trim (Black) FTEX42CH Finishing Trim (Charcoal) BTEX42 Bevelled Trim ZEX42BK Zen Front (Black) ZEX42CH Zen Front (Charcoal) DBPEX42NS Decorative Brick Panels (Newport Standard) DBPEX42WS Decorative Brick Panels (Westminster Standard) DBPEX42OS...
  • Page 17: Troubleshooting

    7.0 troubleshooting troubleshooting symptom problem test solution Flame is a blue, Blockage in vent. Remove blockage. In really cold conditions, ice buildup may lazy, transparent flame occur on the terminal and should be removed as required. White / grey film forms Sulphur from fuel is being Clean the glass with a recommended gas fireplace glass ited on glass, logs, or -...
  • Page 18: Warranty

    Napoleon neither assumes, nor authorizes any third party to assume, on its behalf, any other liabilities with respect to the sale of this product. Napoleon will not be responsible for: over- fi ring, downdrafts, spillage caused by environmental conditions such as rooftops, buildings, nearby trees, hills, mountains, inadequate vents or ventilation, excessive venting confi gurations, insuffi cient makeup air, or negative air pressures which may or may not be caused by mechanical systems such as exhaust fans, furnaces, clothes dryers, etc.
  • Page 19: Service History

    9.0 service history service history W415-2950 / A / 08.10.21...
  • Page 20 NAPOLEON CELEBRATING OVER 40 YEARS OF HOME COMFORT PRODUCTS 7200, Route Transcanadienne, Montréal, Québec H4T 1A3 24 Napoleon Road, Barrie, Ontario, Canada L4M 0G8 214 Bayview Drive, Barrie, Ontario, Canada L4N 4Y8 103 Miller Drive, Crittenden, Kentucky, USA 41030 De Riemsdijk 22, 4004 LC Tiel, The Netherlands Phone: 1-866-820-8686 napoleon.com...
  • Page 21 - L’installation et l’entretien doivent être faits par un installateur qualifié, une agence d’entretien ou le fournisseur. Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030 Phone 1 (866) 820-8686 • www.napoleon.com • hearth@napoleon.com SERIENNUMMER VOM KARTON AUFBRINGEN W415-2950 / A / 08.10.21...
  • Page 22 consignes de sécurité AVERTISSEMENT • Cet appareil est chaud lorsqu’il fonctionne et peut • N’utilisez pas cet appareil si une partie quelconque causer de grave brûlures en cas de contact. a été submergée. Contactez immdiatement un • Toute modifi cation apportée à cet appareil ou aux technicien de service qualifi é...
  • Page 23 table de matières apprendre à connaître votre appareil accès aux contrôles information à propos de la plaque d’homologation instructions d’opération et d’allumage (millivolt) instructions d’opération et d’allumage (électronique) veilleuse sur demande (électronique) dégagements autour de l’appareil entretien soins de la vitre soins des pièces plaquées enlèvement de la barrière de protection enlèvement de la porte vitrée...
  • Page 24 félicitations! félicitations! Napoléon tient fièrement à votre confort domestique. Nous sommes fiers de dire que nos produits continuellement surpassent les normes de l’industrie et notre source d’inspiration c’est vous! Plus que tout, nous voulons vous faire sentir confiant dans le choix de Napoléon pour votre maison. Nos produits sont conçus pour fournir cette confiance et s’assurer que chaque produit de Napoléon est incomparable.
  • Page 25: Apprendre À Connaître Votre Appareil

    NEVER ALLOW CHILDREN TO DO NOT TOUCH GLASS. getting to know your appliance 1.0 apprendre à connaître votre appareil NEVER A A barrier designed to reduce the risk of burns from La zone située au-dessus de l’ouverture de la cheminée incluant la barrière de protection, the hot viewing glass is provided with this appliance le cadre de la barrière, et la surface du mur pouvoir devenir très chaud durant l’opération and shall be installed for the protection of children...
  • Page 26: Accès Aux Contrôles

    Recessed depth X” Profondeur d’encastré une face X” L’appareil doit être ventilé à l’aide de l’ensemble d’évacuation propre à Napoleon. Référez au *** Mantel X” from appliance opening *** Tablette X” de l’ouverture de l’appareil manuel d’installation pour les spécifications d’évacuation. Il est nécessaire de bien réinstaller et *** Maximum horizontal extension: *** L’extension horizontale maximale: X”.
  • Page 27: Instructions D'opération Et D'allumage (Millivolt)

    apprendre à connaître votre appareil instructions d’opération et d’allumage (millivolt) AVERTISSEMENT • Coupez l’alimentation électrique à l’appareil et laissez-le refroidir avant d’effectuer un entretien. Seulement un • Si ces instructions ne sont pas suivies à la lettre, un incendie ou une explosion pourraient s’ensuivre, causant technicien de service qualifi é...
  • Page 28: Instructions D'opération Et D'allumage (Électronique)

    operation instructions d’opération et d’allumage (électronique) AVERTISSEMENT • Si ces instructions ne sont pas suivies à la lettre, un incendie ou une explosion pourraient s’ensuivre, causant des dommages matériels, des blessures corporelles ou des pertes de vie. • Si applicable, allumez toujours la veilleuse, que ce soit pour la première fois ou lorsque l’approvisionnement en gaz est épuisé, avec la porte vitrée ouverte ou retirée.
  • Page 29: Veilleuse Sur Demande (Électronique)

    Pour démarrer la veilleuse, en allumant le brûleur principal à l’aide de l’interrupteur, de la télécommande ou du thermostat, et ensuite en l’éteignant, réactivera le mode veilleuse permanente et réinitialisera la minuterie de sept jours. Pour plus d’informations, consultez le site www.napoleon.com/pilotondemand. 31.2A Interrupteur d’ACS Interrupteur ON/OFF W415-2950 / A / 08.10.21...
  • Page 30: Dégagements Autour De L'appareil

    2.0 dégagements autour de l’appareil clearances around fireplace AVERTISSEMENT • Votre appareil, raccordement gaz/électrique, ventilation et divers composants clés sont cachés derrière le mur. Il est essentiel qu’aucune vis pénètrent ces composants. Non-respect des instructions peut provoquer un fonctionnement incorrect, dommages, blessures, ou feu. Utilisez toujours un localisateur de montants et seulement visser dans les montants.
  • Page 31 dégagements autour de l'appareil Installation affleurant sans Installation affleurant Installation encastré avec une avec un manteau un manteau saillie 6” min. 6” min. Support du Téléviseur Le volume d’air Support du Support du doit être ajouté Téléviseur Téléviseur à l’enceinte pour accueillir l’espace 2.5”...
  • Page 32: Entretien

    maintenance 3.0 entretien AVERTISSEMENT • Coupez l’alimentation en gaz et l’alimentation électrique avant de procéder à l’entretien de l’appareil. • L’appareil peut être chaud. Attendez qu’il soit refroidi avant d’en faire l’entretien. Pour les techniciens qualifié seulement: • Lors de l’entretien des contrôles, assurez-vous d’identifier chacun des fils avant des débrancher. Une réinstallation incorrecte des fils peut occasionner un mauvais fonctionnement et être dangereuse.
  • Page 33: Soins Des Pièces Plaquées

    entretien soins des pièces plaquées Si l’appareil est muni de pièces plaquées, vous devez enlever toutes traces de doigts ou autres marques des surfaces plaquées avant d’allumer l’appareil pour la première fois. Utilisez les nettoyants sans ammoniaque ou à base de vinaigre. Si la surface plaquée n’est pas bien nettoyée avant le premier allumage de l’appareil, elle risque de rester marquée en permanence.
  • Page 34: Pièces De Rechange

    4.0 pièces de rechange replacements AVERTISSEMENT • Omettre de positionner les pièces conformément à ce manuel ou d’utiliser uniquement des pièces spécifi quement approuvées pour cet appareil peut causer des dommages matériels ou des blessures corporelles. Contactez votre détaillant pour les questions concernant les prix et la disponibilité des pièces de remplace- ment.
  • Page 35: Accessoires E36

    5.0 accessoires E36 accessories Ces articles peuvent différer de ceux illustrés. Réf. No. de Pièce Description En Stock FTEX36BK Garniture de Finition (Noire) FTEX36CH Garniture de Finition (Charbon) BTEX36 Garniture Biseautée ZEX36BK Façade Zen (Noire) ZEX36CH Façade Zen (Charbon) DBPEX36NS Panneaux Décoratives en Brique (Newport Classique) DBPEX36WS Panneaux Décoratives en Brique (Westminster Classique)
  • Page 36: Accessoires E42

    6.0 accessoires E42 accessories Ces articles peuvent différer de ceux illustrés. Réf. No. de Pièce Description En Stock FTEX42BK Garniture de Finition (Noire) FTEX42CH Garniture de Finition (Charbon) BTEX42 Garniture Biseautée ZEX42BK Façade Zen (Noire) ZEX42CH Façade Zen (Charbon) DBPEX42NS Panneaux Décoratives en Brique (Newport Classique) DBPEX42WS Panneaux Décoratives en Brique (Westminster Classique)
  • Page 37: Guide De Dépannage

    7.0 guide de dépannage troubleshooting symptôme problème solution La flamme du brûleur Système d’évacuation bloqué. Enlever ce qui obstrue. Dans des conditions de froid extrême, est bleue, parasseuse une accumulation de glace peut se former sur la terminaison et et transparente. devrait être enlevé...
  • Page 38: Garantie

    warranty 8.0 garantie Les produtits Napoléon sont fabriqués conformément aux normes strictes du Système de Gestion de la Qualité mondialement reconnu ISO 9001 : 2015. Les produits Napoléon sont conçus avec des composants et des matériaux de qualité supérieure, assemblés par des artisans qualifi és qui sont fi ers de leur travail.
  • Page 39: Historique D'entretien

    9.0 historique d’entretien historique d'entretien W415-2950 / A / 08.10.21...
  • Page 40 NAPOLÉON CÉLÈBRE PLUS DE 40 ANS D’EXISTENCE CONSACRÉS À LA CONCEPTION DE PRODUITS DE CONFORT 7200, Route Transcanadienne, Montréal, Québec H4T 1A3 24 Napoleon Road, Barrie, Ontario, Canada L4M 0G8 214 Bayview Drive, Barrie, Ontario, Canada L4N 4Y8 103 Miller Drive, Crittenden, Kentucky, USA 41030 De Riemsdijk 22, 4004 LC Tiel, Pays-Bas Téléphone: 1-866-820-8686...
