FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbour's phone. Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency, or the supplier.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030
SAFETY INFORMATION
WARNING
!
Phone 1 (866) 820-8686 • www.napoleon.com • hearth@napoleon.com
OWNER'S MANUAL
ENGLISH
FRENCH PG. 25
Elevation™ Series
(E42 illustrated)
For indoor use only
W415-2950 / B-0 / 07.23.24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E42 and is the answer not in the manual?

Questions and answers

Related Manuals for Napoleon E42

Summary of Contents for Napoleon E42

  • Page 1 - Installation and service must be performed by a qualified installer, service agency, or the supplier. Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada / 103 Miller Drive, Crittenden, Kentucky, USA, 41030 Phone 1 (866) 820-8686 • www.napoleon.com • hearth@napoleon.com...

  • Page 2: Safety Information

    safety information WARNING • This appliance is hot when operated and can cause • Under no circumstances should this appliance be severe burns if contacted. modifi ed. • Any changes to this appliance or its control can be • This appliance must not be connected to a chimney dangerous and are prohibited.

  • Page 3: Table Of Contents

    Changes, other than editorial, are denoted by a vertical line in the margin. This appliance is suitable for use with Napoleon’s optional Universal Heat Management system. THIS MANUAL DOES NOT include detailed information relating the optional sytem. Framing and finishing are NOT the same. For further details, refer to UHM instructions provided with the kit before starting installation.
  • Page 4 Napoleon is proudly committed to your total home comfort. We are proud to say that our products continunously surpass industry standards and our inspiration is you! More than anything, we want you to feel confident in choosing Napoleon for your home. Our products are designed to provide that confidence and ensure that every Napoleon product is beyond compare.

  • Page 5: Getting To Know Your Appliance

    getting to know your appliance 1.0 getting to know your appliance The area above the appliance opening including the safety barrier, barrier frame and the surface of the wall can get very hot during operation and should never be touched until the appliance is off and completely cooled.

  • Page 6: Control Access

    Recessed depth X” Profondeur d’encastré une face X” L’appareil doit être ventilé à l’aide de l’ensemble d’évacuation propre à Napoleon. Référez au *** Mantel X” from appliance opening *** Tablette X” de l’ouverture de l’appareil manuel d’installation pour les spécifications d’évacuation. Il est nécessaire de bien réinstaller et *** Maximum horizontal extension: *** L’extension horizontale maximale: X”.

  • Page 7: Operating Your Appliance

    2.0 operating your appliance operating your appliance on/off components Wall Switch Battery Backup Reciever Remote Control (Not supplied) Housing / Wire (Optional) (Optional) (Supplied) using your appliance When operating your appliance for the first time, there is a required burn-in process that cures materials used to manufacture the appliance that may emit both vapors and an odor.

  • Page 8: Operating And Lighting Instructions (Millivolt)

    operating your appliance operating and lighting instructions (millivolt) WARNING • If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury, or loss of life. • If applicable, always light the pilot whether for the fi rst time or if the gas supply has run out with the glass door opened or removed.

  • Page 9: Operating And Lighting Instructions (Electronic)

    operating your appliance operating and lighting instructions (electronic) WARNING • If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury, or loss of life. • If applicable, always light the pilot whether for the fi rst time or if the gas supply has run out with the glass door opened or removed.

  • Page 10: Pilot-On-Demand (Electronic)

    In order to start your pilot, turning the main burner on with the switch, remote or thermostat and then turning it off will reactivate the continuous pilot mode and reset the seven day timer. For further information, refer to www.napoleon.com/pilotondemand (Fig. 2) (Fig.

  • Page 11: 2.5.1 Connecting Battery Backup

    operating your appliance 2.5.1 connecting battery backup WARNING • Ensure the gas and electrical power to the appliance is turned off. • Appliance may be hot, do not service until the appliance has cooled. note: In the event of a power failure, your appliance can be operated using the battery backup. Before beginning installation, turn off the gas and disconnect the electrical power supply from the appliance.

  • Page 12: Remote Control Layout

    remote control layout 3.0 remote control layout general transmitter layout note: The remote control is optional for the E36/42 models. The receiver switch must be in the REMOTE position for the transmitter to function. This remote system operates using radio frequency signals sent by the transmitter to the receiver. It is recommended that the distance between the transmitter and receiver never exceeds 20’...

  • Page 13: In The Event Of A Battery Failure

    °F child lock Napoleon’s eFIRE application will revolutionize the way you use your fireplace! We have cracked the code and present to you the first fireplace to be controlled by Bluetooth technology, using an intuitive app on your mobile ADD TITLE: Night Light Dimmer Control device.

  • Page 14: 4.0 Clearances Around Appliance

    4.0 clearances around appliance clearances around fireplace WARNING • Your appliance, gas/electrical connections, venting and various key components are hidden behind the wall. It is critical that no screws penetrate these components. Failure to follow instructions may cause improper operation, damage, personal injury or fire.

  • Page 15: Clearances Around Fireplace

    clearances around fireplace Flush installation with Flush installation without Recessed installation with mantel mantel protrusion 6” min. 6” min. TV bracket The volume of TV bracket TV bracket air must be added to the enclosure to accomodate 2.5” min.* 2.5” min.* the recessed area.

  • Page 16: Maintenance

    5.0 maintenance maintenance WARNING • Turn off the gas and electrical power before servicing the appliance. • Appliance may be hot. Do not service until appliance has cooled. For qualified technicians only: • Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation.

  • Page 17: Care Of Plated Parts

    maintenance care of plated parts If the appliance is equipped with plated parts, you must clean fi ngerprints or other marks from the plated surfaces before operating the appliance for the fi rst time. Use an ammonia-free or vinegar-based cleaner and a towel to clean.

  • Page 18: Replacement Parts

    6.0 replacement parts replacements WARNING • Failure to position the parts in accordance with this manual or failure to use only parts specifi cally approved with this appliance may result in property damage or personal injury. Contact your dealer for questions concerning prices and policies on replacement parts. Normally, all parts can be ordered through your Authorized dealer / distributor.

  • Page 19: E36 Accessories

    7.0 E36 accessories accessories Items may not appear exactly as illustrated. Ref. Part Number Description Stocked FTEX36BK Finishing Trim (Black) FTEX36CH Finishing Trim (Charcoal) BTEX36 Bevelled Trim ZEX36BK Zen Front (Black) ZEX36CH Zen Front (Charcoal) DBPEX36NS Decorative Brick Panels (Newport Standard) DBPEX36WS Decorative Brick Panels (Westminster Standard) DBPEX36OS...

  • Page 20: E42 Accessories

    8.0 E42 accessories accessories Items may not appear exactly as illustrated. Ref. Part Number Description Stocked FTEX42BK Finishing Trim (Black) FTEX42CH Finishing Trim (Charcoal) BTEX42 Bevelled Trim ZEX42BK Zen Front (Black) ZEX42CH Zen Front (Charcoal) DBPEX42NS Decorative Brick Panels (Newport Standard)

  • Page 21: Troubleshooting

    9.0 troubleshooting troubleshooting symptom problem test solution Flame is a blue, Blockage in vent. Remove blockage. In really cold conditions, ice buildup may lazy, transparent flame occur on the terminal and should be removed as required. White / grey film forms Sulphur from fuel is being Clean the glass with a recommended gas fireplace glass ited on glass, logs, or -...

  • Page 22: Warranty

    Napoleon neither assumes, nor authorizes any third party to assume, on its behalf, any other liabilities with respect to the sale of this product. Napoleon will not be responsible for: over- fi ring, downdrafts, spillage caused by environmental conditions such as rooftops, buildings, nearby trees, hills, mountains, inadequate vents or ventilation, excessive venting confi gurations, insuffi cient makeup air, or negative air pressures which may or may not be caused by mechanical systems such as exhaust fans, furnaces, clothes dryers, etc.

  • Page 23: Service History

    11.0 service history service history W415-2950 / B-0 / 07.23.24...
  • Page 24 NAPOLEON CELEBRATING OVER 40 YEARS OF HOME COMFORT PRODUCTS 7200, Route Transcanadienne, Montréal, Québec H4T 1A3 24 Napoleon Road, Barrie, Ontario, Canada L4M 0G8 214 Bayview Drive, Barrie, Ontario, Canada L4N 4Y8 103 Miller Drive, Crittenden, Kentucky, USA 41030 De Riemsdijk 22, 4004 LC Tiel, The Netherlands Phone: 1-866-820-8686 napoleon.com...
