1
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
INSTALLATION AND
OPERATING INSTRUCTIONS
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA C22.2 No-46 / UL 1278 CSA STANDARD
EF39HD
ELECTRIC FIREPLACE
WARNING
!
HOT GLASS WILL CAUSE
BURNS.
DO NOT TOUCH GLASS UNTIL
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI/CSA METHODS.
COOLED.
SAFETY INFORMATION
NEVER ALLOW CHILDREN TO
WARNING
TOUCH GLASS.
!
If the information in these instructions are
not followed exactly, a fi re or explosion
may result causing property damage,
personal injury or loss of life.
- Do not store or use gasoline or other fl ammable
vapors and liquids in the vicinity of this or any
other appliance.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
Phone (705)721-1212 • Fax (705)722-6031 • www.napoleonfi replaces.com • ask@napoleonproducts.com
$10.00
1.16B
W415-0752 / D / 02.03.12
Advertisement
Table of Contents
Related Manuals for Napoleon EF39HD
Summary of Contents for Napoleon EF39HD
-
Page 1: Safety Information
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE. INSTALLATION AND OPERATING INSTRUCTIONS CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA C22.2 No-46 / UL 1278 CSA STANDARD EF39HD ELECTRIC FIREPLACE WARNING HOT GLASS WILL CAUSE BURNS. -
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION DIMENSIONS LISTING APPROVALS GENERAL INSTRUCTIONS LOCATING APPLIANCE UNPACKING AND TESTING APPLIANCE GROUNDING APPLIANCE INSTALLATION WALL MOUNT INSTALLATION 3.1.1 MINIMUM CLEARANCE TO COMBUSTIBLES 3.1.2 MINIMUM MANTEL CLEARANCES 3.1.3 INSTALLING THE APPLIANCE FINISHING GLASS EMBER INSTALLATION GLASS FRONT INSTALLATION OPERATING INSTRUCTIONS MAIN POWER SWITCH OPERATING BY REMOTE CONTROL... -
Page 3: Introduction
1.0 INTRODUCTION WARNING • THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED. • Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fi re or injury. •... -
Page 4: Dimensions
This appliance has been tested in accordance with the CSA Standards for fi xed and location-dedicated electric room appliances in the United States and Canada. If you need assistance during installation, please contact your local dealer. Model Number EF39HD NOTE: This appliance must be electrically wired and Description Wall-Mount Appliance... -
Page 5: General Instructions
GENERAL INSTRUCTIONS WARNING READ THESE INSTRUCTIONS COMPLETELY BEFORE BEGINNING INSTALLATION. FAILURE TO FOLLOW THEM COULD CAUSE AN APPLIANCE MALFUNCTION RESULTING IN SERIOUS INJURY AND/OR PROPERTY DAMAGE. ALL ELECTRIC APPLIANCES HAVE HOT AND ARCING OR SPARKING PARTS INSIDE. DO NOT USE IT IN AREAS WHERE GASOLINE, PAINT OR FLAMMABLE LIQUIDS ARE PRESENT. -
Page 6: Locating Appliance
2.0 LOCATING APPLIANCE WARNING DUE TO HIGH TEMPERATURES, THIS ELECTRIC APPLIANCE SHOULD BE LOCATED OUT OF TRAFFIC. KEEP COMBUSTIBLE MATERIALS SUCH AS FURNITURE, PILLOWS, BEDDING, PAPERS, CLOTHES AND CURTAINS AT LEAST 36" FROM THE FRONT OF THE APPLIANCE. NEVER LOCATE THIS ELECTRIC APPLIANCE WHERE IT MAY FALL INTO A BATHTUB OR OTHER WATER CONTAINER. -
Page 7: Installation
3.0 INSTALLATION WARNING RISK OF FIRE! THE POWER CORD MUST NOT BE PINCHED AGAINST A SHARP EDGE. SECURE CORD TO AVOID TRIPPING OR SNAGGING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL INJURY. DO NOT RUN CORD UNDER CARPETING. DO NOT COVER CORD WITH THROW RUGS, RUNNERS OR THE LIKE. ARRANGE CORD AWAY FROM TRAFFIC AREAS AND WHERE IT WILL NOT BE TRIPPED OVER. -
Page 8: Wall Mount Installation
WALL MOUNT INSTALLATION 3.1.1 MINIMUM CLEARANCE TO COMBUSTIBLES Measurements are taken from the glass front. Bottom " " to mantel Sides 4" " to ceiling Back 0" 3.1.2 MINIMUM MANTEL CLEARANCES WARNING WHEN USING PAINT OR LACQUER TO FINISH THE MANTEL, THE PAINT OR LACQUER MUST BE HEAT RESISTANT TO PREVENT DISCOLOURATION. -
Page 9: Installing The Appliance
3.1.3 INSTALLING THE APPLIANCE Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance on the wall. Body Glass Front Select a location that is not prone to moisture and is located at least 36"... -
Page 10: Finishing
4.0 FINISHING WARNING POWER SUPPLY SERVICE MUST BE COMPLETED PRIOR TO FINISHING TO AVOID RECONSTRUCTION. HEAT VENTS AND AIR OPENINGS CANNOT BE COVERED IN ANY CIRCUMSTANCES. GLASS EMBER INSTALLATION Glass front must be removed and the appliance must be mounted in its fi... -
Page 11: Operating Instructions
5.0 OPERATING INSTRUCTIONS Once the appliance has been plugged into a grounded electrical outlet, it is ready to operate. NOTE: Ensure the house circuit breakers for the power supply are turned on. In the event of a power failure, when the main power switch is in the "I" ON position and the hand held remote control is in the OFF position, the fl... -
Page 12: Maintenance
6.0 MAINTENANCE WARNING PREPARATION FOR MAINTENANCE ALWAYS DISCONNECT THE POWER AND ALLOW THE ELECTRIC APPLIANCE TO COOL BEFORE PERFORMING ANY CLEANING, MAINTENANCE OR RELOCATION OF THIS ELECTRIC APPLIANCE. TURN CONTROLS TO OFF AND REMOVE PLUG FROM OUTLET OR TURN OFF THE HOUSE CIRCUIT BREAKER TO ELECTRIC APPLIANCE RECEPTACLE. -
Page 13: Replacing The Flame Generation Light Bulbs
REPLACING THE FLAME GENERATION LIGHT BULBS WARNING REMOVE THE APPLIANCE FROM THE WALL AND TURN OFF ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE. Remove the 6 screws on the back plate of the Flame Generation Bulb Location appliance near the bottom. Open back plate from the top. -
Page 14: Replacing The Ember Bed Light Bulbs
REPLACING THE EMBER BED LIGHT BULBS Ember Bed Bulb Replacement Ember Bed Bulb Replacement 2 screws Right Left Back View Screw Screw Screws Switch wires Remove the 2 screws on the bottom left and right corner of the appliance behind the front panel. Remove the 2 screws holding the main power switch and pull switch down carefully. -
Page 15: Wiring Diagram
7.0 WIRING DIAGRAM WARNING ENSURE ALL POWER IS TURNED OFF BEFORE HARD WIRING THIS APPLIANCE. W415-0752 / D / 02.03.12... -
Page 16: Replacement Parts
8.0 REPLACEMENT PARTS Contact your dealer or the factory for questions concerning prices and policies on replacement parts. Normally all parts can be ordered through your Authorized dealer / distributor. FOR WARRANTY REPLACEMENT PARTS, A PHOTOCOPY OF THE ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR THE CLAIM. -
Page 17: Troubleshooting
9.0 TROUBLESHOOTING WARNING TURN OFF THE APPLIANCE COMPLETELY AND LET COOL BEFORE SERVICING. ONLY A QUALIFIED SERVICE PERSON SHOULD SERVICE AND REPAIR THIS ELECTRIC APPLIANCE. SYMPTOM PROBLEM TEST SOLUTION Dim or no fl ame Bulb(s) are burnt out Inspect the bulbs inside the fl ame generation cylinder drum and replace them if necessary Ember bed is not Bulb(s) are burnt out... -
Page 18: Warranty
10.0 WARRANTY NAPOLEON® electric appliances are manufactured under the strict Standard of the world recognized ISO 9001 : 2008 Quality Assurance Certifi cate. NAPOLEON® products are designed with superior components and materials, assembled by trained craftsmen who take great pride in their work. Once assembled the complete appliance is thoroughly inspected by a qualifi ed technician before packing to ensure that you , the customer, receive the quality product that you expect from NAPOLEON®. -
Page 19: Service History
11.0 SERVICE HISTORY 43.1 W415-0752 / D / 02.03.12... - Page 20 12.0 NOTES 44.1 W415-0752 / D / 02.03.12...
