Installation

Dimensions
a = 855 mm
b = 620 mm
c = 595 mm
Weight = 43 Kg
Packing accessories
Checklist of the accessories and materials provided with the machine:
User
Name
manual
Quantity
To ensure the dryer operating normally, attention must be paid to
the following in placement:
The dryer must be horizontally installed. Its bottom is equipped
with adjustable base angles. Adjust these 4 angles to level before
operation;
Check whether there is any damage to the dryer during
transportation. Any damaged dryer must not be electrified. In case
of any damage, contact your dryer supplier;
The dryer must be kept away from flammable or detonable substances
The surrounding environment must be dry and ventilated;
Do not install the dryer on any hairy carpet because the normal
ventilation of the vent hole may be blocked
To allow the dryer to perform better, the ambient temperature shall
not be lower than 10
Condenser Tumber Dryer
Certificate of
Conformity
nor higher than 35
b
c
Drainpipe
SLC 116PEW
6
