Examine if NTC is damaged
( short circuit or cut off )
Code
Error message: The Pump fails.
Examine if the tank is full with
water
N
Examine if the float pole to its
original place
N
Examine if the drainage pipe is
blocked
N
The pump fails
Trouble The heater does not work or works abnormally
Examine if the thermostat near
the heater works ( It is closed )
Y
Examine if the connection lines into
heater correctly
Y
Examine if the heater is damaged
( short circuit or cut off )
Condenser Tumber Dryer
Float pole
drainage
Pump
the sequence of
insert lines
Heater
Page 20
SLC 116PEW
Y
Repalce the NTC
Empty the tank and restart
Y
the dryer
Move the float pole to its
Y
original place by your
hand
Y
Empty the drainage pipe
Y
Replace the old pump
with a new one
Open the back plate and
N
slightly press the red button
on the thermostat to make it
reset
Make sure the connection
N
lines are inserted correcting
Repalce the old heater with
Y
a new one
