Proline SLC 116PEW Service Manual page 19

Code
Error Message: Prompting the door not closed tightly.
Pushing the door to check whether
door is properly shut or not .
Y
Check whether the touching
slice is fixed properly.
Y
Check whether the terminals are
installed correctly.
Code
Error message: The temperature tested by NTC does not change.
Check whether the heater short
circuit or cut off
N
Chek whether the lint screen is
blocked
N
Check whether the NTC is
short circuit or cut off ( the
resistance number of NTC
is nearby 10K )
Condenser Tumber Dryer
Touching slice
Terminals
SLC 116PEW
shut the door properly
N
Install the terminals
N
properly
Fix up the terminals
N
proerly
Replace the heater which
Y
can not work
Y
clear the lint screen
Y
Replace the NTC
18
