Proline SLC 116PEW Service Manual page 25

Condenser Tumber Dryer
No. in
exploded Spare parts number
view
0020102847
00213500007700
0020102821
0020202696
0020202695
00213500013900
0020202675R
0020102810
0020202669
0020202671
0020202668R
0020202672
0020202673
0020202674
0020102801
0020202711
0020202712
0020202710
0020202670
0020202677
0020102799
0020202718
0020202846
0020202698
0024000238
0020102811
0020202666
0020800038
0020400185
0020400628A
0020102797
0020102798
0020102831
0020202667
0020202694
0020202678
0020202692
0020202693
0020202732
00214900014600
00213500007800
Spare parts description in
english
Back plate
Right side panel assembly
Back cover board
Storage tank assembly
Tank
Iron top panel
Handle of tank
Front panel
Computer board box
Knob
Main control panel
Clear cover
Knob dial of program control
Connecting shaft of programm
Front horizontal beam
Bracket of brush
fastening board of brush
Gather the of water
Button
Lower plaque
Cover board of Condenser
The card button up
Right shaft
Left shaft
Brush
Lower ventilation board
Outer frame of door
Rear footplate
Power supply wires
Control cable assembly
Door hinge
Hinge Cover (top)
Hinge Cover (bottom)
Door liner
Hinge hole cover
Displayer cover
Door hook
Touch the slice
Door hook cover
Foot
Bottom panel
SLC 116PEW
Model: SLC 116PEW
Qty Remark
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
2
2
2
1
1
1
1
1
4
4
1
24
