Summary of Contents for Stairville Show Bar Pro
- Page 1 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 29.07.2022, ID: 379792 (V4)
-
Page 3: Table Of Contents
7.3 Menu overview..........................29 7.4 Functions in 5-channel DMX mode................... 30 7.5 Functions in 7-channel DMX mode................... 30 7.6 Functions in 9-channel DMX mode................... 31 7.7 Functions in 80-channel DMX mode..................35 Technical specifications........................38 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 4 Table of contents Plug and connection assignments....................41 Troubleshooting............................42 Cleaning............................... 44 Protecting the environment......................45 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 5 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 6: General Information
Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... -
Page 7: Further Information
Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. 1.2 Notational conventions This manual uses the following notational conventions: Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... -
Page 8: Symbols And Signal Words
NOTICE! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 9 General information Warning signs Type of danger Warning – high-voltage. Warning – hot surface. Warning – dangerous optical radiation. Warning – suspended load. Warning – danger zone. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 10: Safety Instructions
Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 11 15 minutes. NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 12 Only connect so many identical devices that the maximum current consumption is not exceeded. Ensure the sufficient dimensioning (wire cross section) of the power cables used for all devices connected in series. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 13: Features
IP65, suitable for outdoor use Splashproof safety plug (IP44) Pressure compensation element (prevents condensation inside the device) with the optionally available filter (item no. 437012), the beam angle can be increased from 20° to 50° Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 14 For technological reasons, the light output of LEDs decreases over their lifetime. This effect increases with higher operating temperature. You can extend the service life of the illuminants by providing adequate ventilation and operating the LEDs with the lowest possible brightness. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 15: Installation
NOTICE! Risk of overheating Always ensure sufficient ventilation. The ambient temperature must not exceed the limits stated in the chapter Tech‐ nical Specifications of the User Manual. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 16 Possible damage due to moisture Moisture entering into open connectors (plugs and couplers) of DMX or power cords can cause short circuits. Close unused connectors with end caps intended for this purpose (www.thomann.de). Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 17 You can install the device on the wall, the ceiling or on the floor. Two mounting brackets and the necessary screws are included. Always work from a stable platform whenever installing, moving or servicing the unit. In doing so, the area underneath the unit must be cordoned off. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 18 The filter, optionally available as accessory (item no. 437012), can be fixed at the front of the unit with four undetachable thumb screws. Place the filter onto the front side and tighten the screws successively finger-tight. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 19: Starting Up
Such a chain may consist of up to 30 DMX devices. Make sure that the output of the last device in the chain is terminated by a resistor (110 Ω, ¼ W). Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 20 DMX output of the first slave unit to the DMX input of the second slave unit and so on (max‐ imum 30 slaves). Please note that this device must not be connected to a dimmer. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 21: Connections And Controls
2 Lockable input socket (Power Twist TR1 IP65) for power supply 3 DMX input 4 Locking screws for locking the mounting bracket in the desired orientation 5 Horizontally slidable mounting bracket which is adjustable in inclination 6 DMX output Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 22 12 [UP] | navigates upwards in a menu list. Increases the displayed value by one 13 [DOWN] | navigates downwards in a menu list. Decreases the displayed value by MODE SETUP DOWN Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 23: Operating
If you do not press any key for about 30 seconds, the display turns off. It will be reactivated to display the previously shown menu by pressing any button. The set values are retained even when the device is disconnected from the mains power supply. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 24 (fast) or ‘SP.FL’ . To adjust the flash frequency, press [SETUP] repeatedly until the display shows ‘FS.xx’ . Now use [UP] and [DOWN] to select a value between ‘FS.00’ (slow) and ‘FS.99’ (fast). Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 25 DMX address for the various DMX modes. Mode Highest possible DMX address 5-channel 7-channel 9-channel 80-channel Press [SETUP]. Now use [UP] and [DOWN] to select one of the following DMX operating modes: ‘5.-CH’ (five channels) ‘7.-CH’ (seven channels) Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 26 ‘A.000’ … ‘A.255’ Amber To adjust the flash frequency, press [SETUP] repeatedly until the display shows ‘FS.xx’ . Now use [UP] and [DOWN] to select a value between ‘FS.00’ (slow) and ‘FS.99’ (fast). Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 27 The below figure schematically shows the adjustable dimmer curves. Depending on the selected DMX value (1) the device lights with a brightness (2) between 0 % and 100 %. Confirm the selection with [SETUP]. Press [MODE]. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 28 ‘Temp’ and confirm with [SETUP]. The display shows ‘t-ok’ when the device termperature is within the permissible range and shows ‘t-NG’ when the device is over‐ heated. If it is so, switch the device off and let it cool down. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 29: Menu Overview
1.xxx r.255 Temp d.512 g.000 CuSe Cu-1 19.on 5.-CH g.255 -OFF Cu-4 7.-CH FS.00 b.000 9.-CH b.255 FS.99 80.CH u.000 u.255 Pr.02 SP.01 A.000 Pr.25 SP.99 A.255 SP.FL FS.00 FS.00 FS.99 FS.99 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... -
Page 30: Functions In 5-Channel Dmx Mode
Intensity green (0 % to 100 %), for all LEDs together 0…255 Intensity blue (0 % to 100 %), for all LEDs together 0…255 Intensity white (0 % to 100 %), for all LEDs Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... -
Page 31: Functions In 9-Channel Dmx Mode
Intensity blue (0 % to 100 %) 0…255 Intensity white (0 % to 100 %) 0…255 Intensity amber (0 % to 100 %), for all LEDs No function 1…9 Preprogrammed automatic show 01 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 32 Preprogrammed automatic show 11 110…119 Preprogrammed automatic show 12 120…129 Preprogrammed automatic show 13 130…139 Preprogrammed automatic show 14 140…149 Preprogrammed automatic show 15 150…159 Preprogrammed automatic show 16 160…169 Preprogrammed automatic show 17 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 33 R: 0; G: 0; B: 255; W: 0; A: 0 52…64 R: 0; G: 0; B: 0; W: 255; A: 0 65…77 R: 0; G: 0; B: 0; W: 0; A: 255 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 34 R: 0; G: 0; B: 0; W: 255; A: 255 234…246 R: 255; G: 155; B: 0; W: 70; A: 255 247…255 R: 255; G: 255; B: 255; W: 255; A: 255 Channel 7 = 10…255 0…255 Programme running speed Pr.02…Pr.25 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 35: Functions In 80-Channel Dmx Mode
Blue, LED 3 White, LED 3 Amber, LED 3 Channel 16 Channel 17 Channel 18 Channel 19 Channel 20 Red, LED 4 Green, LED 4 Blue, LED 4 White, LED 4 Amber, LED 4 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 36 Channel 57 Channel 58 Channel 59 Channel 60 Red, LED 12 Green, LED 12 Blue, LED 12 White, LED 12 Amber, LED 12 Channel 61 Channel 62 Channel 63 Channel 64 Channel 65 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 37 Blue, LED 15 White, LED 15 Amber, LED 15 Channel 76 Channel 77 Channel 78 Channel 79 Channel 80 Red, LED 16 Green, LED 16 Blue, LED 16 White, LED 16 Amber, LED 16 Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 38: Technical Specifications
DMX control XLR chassis socket, 3-pin Power consumption 190 W Supply voltage 100 - 240 V 50/60 Hz Degree of protection IP65 Mounting options In hanging position, in standing position, wall mounting Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 39 Dimensions (W × H × D) 1027 mm × 170 mm × 221 mm Weight 7.6 kg Ambient conditions Temperature range –20 °C…45 °C Relative humidity 20 %…80 % (non-condensing) 1027 mm 170 mm Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 40 Technical specifications Further information Suitable for outdoor use fanless Remote control Not possible Wireless DMX Housing colour black Separately controllable LEDs Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 41: Plug And Connection Assignments
The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please refer to the drawing and table below for the pin assignment of a suitable XLR plug. Configuration Ground, shielding Signal inverted (DMX–, ‘cold signal’) Signal (DMX+, ‘hot signal’) Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... -
Page 42: Troubleshooting
Never connect the DMX input or output to audio devices such as mixers or ampli‐ fiers. In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 43 DMX interface circuits. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
-
Page 44: Cleaning
Before cleaning, switch off the device and disconnect mains-operated devices from the mains. Only use pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit with a slightly damp lint-free cloth. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... -
Page 45: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. Show Bar Pro 16x10W RGBAW IP65 LED Floodlight... - Page 46 Notes Show Bar Pro 16x10W RGBAW IP65 LED Floodlight...
- Page 48 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
