EVALUATION KIT OPTIONS
EtherCAT: EV-RPG2-ECZ
EtherNet/IP: EV-RPG2-ENZ
Profinet: EV-RPG2-PNZ
Powerlink: EV-RPG2-PLZ
Modbus: EV-RPG2-MBZ
EVALUATION KIT CONTENTS
Baseboard
RapID Generation 2 module installed and preloaded with
protocol specific software
Wall mount ac adapter, 90 V ac to 264 V ac to 12 V dc, 12 W, 1 A
4 power supply plug adapters (A, C, G, and I types)
1 USB A male to USB micro B male cable
Ethernet cable
ADDITIONAL HARDWARE NEEDED
PC with Windows® 10 operating system
DOCUMENTS NEEDED
Protocol specific user guides available for download from
the
ADI Chronous Developer Portal
EtherCAT Quick Start Guide
EtherNet/IP Quick Start Guide
PROFINET Quick Start Guide
POWERLINK Quick Start Guide
Modbus TCP Quick Start Guide
PLEASE SEE THE LAST PAGE FOR AN IMPORTANT
WARNING AND LEGAL TERMS AND CONDITIONS.
Arrow.com.
Downloaded from
RapID Platform Generation 2 User Guide
Rev. 0 | Page 1 of 5
EV-RPG2 User Guide
GENERAL DESCRIPTION
This user guide describes how to set up the provided hardware
of the evaluation kit and establish the link type specific host
connection and connect the evaluation board to an industrial
Ethernet network.
The operation of the EV-RPG2 boards vary by Industrial
Ethernet Protocol, and separate user guides are available for
each protocol on the
ADI Chronous Developer
The EV-RPG2 evaluation kits provide an end to end evaluation
of the communication path from the host processor to the pro-
grammable logic controller (PLC) or PC-based tool.
The EV-RPG2 evaluation kits can completely verify the
communication path between the host processor and a PLC
before integrating the network interface into the end field
device.
UG-1780
Portal.
Advertisement
Table of Contents
Related Manuals for Analog Devices EV-RPG2
Summary of Contents for Analog Devices EV-RPG2
-
Page 1: Evaluation Kit Options
ADI Chronous Developer Portal. Baseboard The EV-RPG2 evaluation kits provide an end to end evaluation RapID Generation 2 module installed and preloaded with of the communication path from the host processor to the pro- protocol specific software grammable logic controller (PLC) or PC-based tool. -
Page 2: Table Of Contents
UG-1780 EV-RPG2 User Guide TABLE OF CONTENTS Evaluation Kit Options ..............1 Electrostatic Sensitive Device (ESD) Warning ......4 Evaluation Kit Contents ..............1 Power Supply and Grounding .............4 Additional Hardware Needed ............1 Hardware Setup ................4 Documents Needed ................1 Connecting the Ethernet Host Interface ........5... -
Page 3: Evaluation Kit Photograph
EVALUATION KIT PHOTOGRAPH Figure 1 shows the contents of the evaluation kit. TYPE I TYPE C TYPE A TYPE G Figure 1. EV-RPG2 Evaluation Kit Example Rev. 0 | Page 3 of 5 Arrow.com. Arrow.com. Arrow.com. Downloaded from Downloaded from... -
Page 4: Evaluation Board Setup
UG-1780 EV-RPG2 User Guide EVALUATION BOARD SETUP Switch the Power Enable switch on the baseboard to the ELECTROSTATIC SENSITIVE DEVICE (ESD) ON position, as shown in Figure 3. The 3.3 V LED (V702) WARNING and the 5.0 V LED (V703) illuminate blue. -
Page 5: Connecting The Ethernet Host Interface
