- Page 1 ® ™ JBL BALBOA BALBOA SUB10 (120V) OWNER’S GUIDE...
-
Page 2: Read First
READ FIRST! Important Safety Precautions! 1. Read these instructions. 2. Keep these instructions. 3. Heed all warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. - Page 3 With the JBL Balboa Series, innovative technologies such as titanium-laminate-dome tweeters, EOS waveguides and high- performance transducers are available to you. Enjoy!
-
Page 4: Controls And Connections
CONTROLS AND CONNECTIONS Rear Panel A Harman International Company ® ¡ ™ £ ¢ ∞ § ¶ FUSE 120V T 2.5A L 250V 60HZ TYPE 200 Watts Subwoofer-Level Control Crossover Adjustment Phase Switch LFE Input Line-Level Inputs Power Indicator LED Power Switch... -
Page 5: Subwoofer Connections
If your receiver/processor does not contain a Dolby Digital or DTS processor but has a subwoofer output: NOTE: Some receivers have one subwoofer output. In that case, it is recommended that you use a Y connector (not included) to maximize performance. -
Page 6: Operation
OPERATION Power On Plug your subwoofer’s AC cord into a wall outlet. Do not use the outlets on the back of the receiver. Initially set the Subwoofer-Level Control ¡ to the “min” position. Turn on your sub by pressing the Power Switch ¶ on the rear panel. -
Page 7: Maintenance And Service
If the problem appears in the opposite speaker, the cause is in another component or cable. In the event that your subwoofer ever needs service, contact your local JBL dealer or distributor or www.jbl.com for a service center near you. -
Page 8: Specifications
All features and specifications are subject to change without notice. All dimensions include grilles and feet. JBL and Harman International are registered trademarks, and Balboa Series and Pro Sound Comes Home are trademarks, of Harman International Industries, Incorporated. Dolby is a registered trademark of Dolby Laboratories.
