Table 5: General Specifications - Tektronix PSPL2600C User Manual

Specifications
Table 5: General specifications
Parameter
Accessories included
Front panel controls
Power supply (mains)
Power consumption
Operating environment
Temperature
Humidity
Elevation
Dimensions
Weight
Connectors
Warranty
14
Description
Power cord, front handles, rack mount kit, instruction manual
Power, repetition rate range, rep. rate vernier, delay, duration,
polarity, and attenuation
100, 115, or 230 VAC, ±10% switch selectable, 50 or 60 Hz
42 VA (60 Hz), 65 VA (50 Hz)
Indoors, 0 to 50 °C, <80% rh
40 °C (104 °F); low limit of 0 °C (32 °F)
80% for temperatures up to 31 °C (88 °F), decreasing linearly to
50% at 40 °C (104 °F)
2000 m (6562 ft.)
17 x 13 x 3.25 in. (43.2 x 33.0 x 8.3 cm)
15 lbs (6.8 kg)
SMA output, BNC for trigger in and trigger output
One year
Tektronix PSPL2600C Pulse Generator User Manual
