Figure 12: Adjustable Delay Trigger, Jitter Measures 12.8 Ps; Figure 13: Fixed 115 Ns Delay Trigger, Jitter Measures 6.8 Ps - Tektronix PSPL2600C User Manual

Pulse waveform examples
10
The following figures show typical histogram measurements of the timing jitter.
The displays are set to 10 V/div and 50 ps/div.

Figure 12: Adjustable delay trigger, jitter measures 12.8 ps

Figure 13: Fixed 115 ns delay trigger, jitter measures 6.8 ps

Tektronix PSPL2600C Pulse Generator User Manual
rms
rms
