Clarion Co., Ltd. All Rights Reserved. Copyright © 2000: Clarion Co., Ltd. Printed in China / Imprimé en Chine / Impreso en Chine / 2000/2 (IT·K) QC-6700B 280-7362-30 Owner’s manual & Installation manual Mode d’emploi et manuel d’installation Manual de instrucciones y de instalación VRX6671z 6.5”... -
Page 2: Table Of Contents
Thank you for purchasing the Clarion VRX6671z. This owner’s manual is for the VRX6671z. Please read this owner’s manual in its entirety before operating this equipment. After reading this manual, be sure to keep it in a handy place (e.g., glove compartment). -
Page 3: Joystick Operation
COLOR LCD DISPLAY INFORMATION PANEL MAIN Clock Time display TITLE LIST mode display COLOR LCD DISPLAY INFORMATION PANEL VRX6671z Contents TV Operations...26 Output adjustment of auto loudness, TV functions...26 subwoofer and playback band...32 Watching TV...26 Selecting the easy mode or the Watching a video...26... -
Page 4: Mode Display
Note: Be sure to unfold this page and refer to the front diagrams as you read each chapter. Remarque: Veuillez déplier cette page et vous référer aux schémas quand vous lisez chaque chapitre. Nota: Cuando lea los capítulos, despliegue esta página y consulte los diagramas. VRX6671z NOMENCLATURE Names of Buttons Note: •... -
Page 5: Radio Mode Display
RADIO mode display COLOR LCD DISPLAY INFORMATION PANEL MAIN VRX6671z... -
Page 6: Cd/Md Changer Mode Display
CD/MD Changer mode display COLOR LCD DISPLAY INFORMATION PANEL MAIN VRX6671z... -
Page 7: Tv Mode Display
TV mode display COLOR LCD DISPLAY INFORMATION PANEL MAIN VRX6671z... -
Page 8: Remote Control
• When replacing batteries, replace both batteries with new ones. • Do not short-circuit, disassemble or heat batteries. • Do not dispose of batteries into fire or flames. • Dispose of spent batteries properly. VRX6671z When the panel is open WIDE... -
Page 9: Functions Of Remote Control Unit Buttons
1 second: Disc random play. Switches reception band. Moves preset channels up and down. No function. Preset scan. When pressed and held for 2 seconds: Auto store. Switches TV display size. Switches the VISUAL mode. Switches between TV and VTR. VRX6671z... -
Page 10: Dcp
VRX6671z 2. Lock the DCP/Operation Panel at the upper center until a click is heard. POWER button 3. -
Page 11: Cautions On Handling
• Cleaning the LCD panel The LCD panel tends to collect dust, so wipe it off occasionally with a soft cloth. The surface is easily scratched, so do not rub it with hard ob- jects. VRX6671z... -
Page 12: Operations
TV mode External equipment not connected with CeNET is not selected. VRX6671z Note: Be sure to read this chapter referring to the front diagrams of chapter “2. CONTROLS” on page 5 (unfold). Adjusting the volume Operate the VOLUME button 2 in the direction of the arrows w volume;... -
Page 13: Showing A Mode Display
• “Z-EHCR 2” (Z-Enhancer 2): Setting emphasizing treble. • “Z-EHCR 3” (Z-Enhancer 3): Setting emphasizing bass and treble. • “Z-EHCR OFF” (Z-Enhancer off): Neither bass nor treble are empha- sized by the Z-enhancer. Note: • Incapable of operation when connecting DSP (DPH7500z). VRX6671z... -
Page 14: Adjusting The Z-Enhancer
JOYSTICK ¡ rightward or leftward to move the cursor to “MENU”. Then press the ENT at the center of the JOYSTICK ¡ to return to the AUDIO-MODE display. VRX6671z Adjusting the bass and treble Notes: • This function is enabled only when the panel is open. -
Page 15: Turning On/Off The Loudness
(DPH7500z), a feature called auto loudness is selected. This function is different from the loudness effect. For further details on the auto loudness feature, refer to the subsection “Output adjustment of auto loudness, subwoofer and playback band”. Basic Operations VRX6671z... -
Page 16: Radio Operations
“MANU” in the display goes off (or when the panel is open the indicator “SRCH” lights)and seek tuning is now available. VRX6671z 2. Press the right or left side of SEARCH button 2 to automatically seek a station. ®... -
Page 17: Manual Memory
Recalling a station with ISR In any mode, press ISR button 0 to turn on the radio function and tune the selected radio sta- tion. “ISR” appears in the display. Press ISR but- ton 0 again to return to the previous mode. VRX6671z... -
Page 18: Cd Changer Operations
When a CD-text title is longer than 16 charac- ters (8 characters when the panel is closed), you can scroll the display as follows. VRX6671z When the panel is closed: 1. Display the CD-text title (disc or track). 2. Press and hold the BAND button % for 1 sec- ond or longer. -
Page 19: Fast-Forward/Fast-Backward
“D- RDM” lights in the display. 2. To cancel disc random play, press the RDM button 8 again. “D-RDM” goes off from the display and the unit returns to normal play from the track being played. VRX6671z... -
Page 20: Md Changer Operations
2. To scroll the track title, press for 1 second or longer the TITLE button ( within 30 seconds after scrolling the disc title. VRX6671z Notes: • When the disc title is within 16 characters, the title is scrolled immediately. -
Page 21: Scan Play
“D-RDM” lights in the display. 2. To cancel random play, press the RDM but- ton 8 again. “D-RDM” goes off from the dis- play and the unit returns to normal play from the track being played. VRX6671z... -
Page 22: Tv Operations
If “MANU” is lit in the display (or when the panel is closed, if the indicator “SRCH” is not lit), VRX6671z press and hold the BAND button % for 1 sec- ond or longer. “MANU” in the display goes off (or when the panel is closed, the indicator “SRCH”... -
Page 23: Manual Memory
“ON” or “OFF” and press the ENT at the center of the JOYSTICK ¡ to set the selected reception setting. Sets reception emphasizing the visual. OFF: Sets the diver setting to OFF. 4. Press the ADJ button * return to the previ- ous mode. VRX6671z... -
Page 24: Adjusting The Brightness And Tone Of
JOYSTICK ¡ rightward or leftward to move the cursor to “MENU”. Then press the ENT at the center of the JOYSTICK ¡ to return to the adjustment selection display. VRX6671z Changing over TV display size This function is available only when the panel is open. -
Page 25: Rear Vision Camera
TV. Please refer to the TV explanation. In VISUAL mode, the picture quality can be ad- justed. The setting method is the same as for the TV. Please refer to the TV explanation. VRX6671z... -
Page 26: Other Functions
3. If you press and hold the TITLE button ( for 1 second or longer, the display switches to the title input mode display. VRX6671z 4. Operate the JOYSTICK ¡ upward or down- ward, rightward or leftward and move the cur- sor to the character to be entered. -
Page 27: Clock Adjustment
This unit requires special wiring to mute the au- dio signal automatically when a cellular telephone rings in the car. This function is not compatible wiht all cellular telepones Contact your local authorized Clarion dealer for information on proper installation and compatibility. Other Functions... -
Page 28: Dsp Operations
Hereafter the graphic equalizer is referred to as a G.EQ, the space equalizer referred to as S.EQ and the parametric equalizer referred to as P.EQ. VRX6671z Operations common to each mode Output adjustment of auto loudness, subwoofer and playback band 1. -
Page 29: Selecting The Easy Mode Or The Professional Mode
5. Operate the JOYSTICK ¡ upward or down- ward to make an adjustment. 6. Operate the JOYSTICK ¡ rightward or left- ward to move the cursor to “MENU”, and press the ENT at the center of the JOYSTICK ¡ to return to the AUDIO-MODE display. VRX6671z... -
Page 30: Easy Mode/G.eq Operations
JOYSTICK ¡ to show G.EQ adjust- ing display, in which the properties of currently selected pattern can be adjusted. VRX6671z By pressing the BAND button % in BASIC pat- tern selecting display or USER pattern selec- tion/memory display you can switch between the two patterns, BASIC and USER. -
Page 31: Easy Mode/Dsp Operations
DSP pattern to the USER memory. By pressing the PRESET buttons # 1 to 6 for 2 seconds or longer in the DSP adjusting display, the DSP pattern can be stored in the USER memory. VRX6671z... -
Page 32: Professional Mode/S.eq Operations
4. In the pattern selecting display, operate the JOYSTICK ¡ rightward or leftward to select P1 to P6, and press the ENT at the center of VRX6671z the JOYSTICK ¡ to call corresponding S.EQ pattern. In this display, pressing the No. but- ton in correspondence to the PRESET buttons # can also call the S.EQ pattern. -
Page 33: Professional Mode/P.eq Operations
USER memory P1 to P6 to be stored, and press the ENT at the center of the JOYSTICK ¡ for 2 seconds or longer to store the adjusted P .EQ pattern to the USER memory. VRX6671z... - Page 34 For title inputting method, refer to the section “Entering titles”. 8. Operate the JOYSTICK ¡ rightward or left- ward to select “MENU” and press the ENT at the center of the JOYSTICK ¡ to change into the AUDIO-MODE display. VRX6671z...
-
Page 35: In Case Of Difficulty
The display is made dark at night to prevent the glare (When the headlight of the vehicle is lit in the daytime, the display gets dark). Check that COL and HUE are adjusted properly. Set the NTSC/PAL properly according to the VTR. Measure VRX6671z... - Page 36 There are red, green, and blue points in the display. VRX6671z Cause A radio wave may not reach sufficiently due to obstruction of mountains or buildings. Check it again at a place where a radio wave can be received properly.
-
Page 37: 10. Error Displays
MD changer. This is a failure of MD changer’s mecha- nism and consult your store of purchase. Replace with a non-scratched, non-warped- disc. Eject the disc then reload it properly. Load a pre-recorded MD in the MD changer. Measure VRX6671z... -
Page 38: 11. Specifications
Video input: Mini DIN 8P LCD Monitor Screen Size: 6.5-inch wide type (142 mm Width Height) Display method: Transmission type TN liquid crystal display VRX6671z Drive method: TFT (thin-film transistor) active matrix driving Pixels: 280,800 (1200 General Power source voltage: 14.4 V DC (10.8 to 15.6 V allowable) -
Page 39: Package Contents
4 Bag for accessories of the main unit (No. 1) Flat head screw (M5 8)...4 Sems hexagonal bolt (M5 5 Bag for accessories of the main unit (No. 2) Hook plate...2 VRX6671z Installation and Wire connection manual Contents BEFORE STARTING...43 PACKAGE CONTENTS...43 GENERAL CAUTIONS...44 CAUTIONS ON INSTALLATION...44...
