Thank you for purchasing the Clarion VRX633R. ∗ This owner’s manual is for the VRX633R. ∗ Please read this owner’s manual in its entirety before operating this equipment. ∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment). -
Page 3: Precautions
Clock Time display TITLE LIST mode display COLOR LCD DISPLAY INFORMATION PANEL VRX633R 1. PRECAUTIONS WARNING For your safety, the driver should not watch the TV or operate the controls while driving. Please note that watching and operating the TV while driving are prohibited by law in some countries. - Page 4 Observera: Vik ut denna sida för att kunna se figurerna över bilstereons framsida medan du läser de olika kapitlen. Nota: Lembre-se de abrir esta página e consultar os diagramas frontais durante a leiture de cada capítulo. VRX633R 4. NOMENCLATURE Names of Buttons Note: •...
-
Page 5: Radio Mode Display
RADIO mode display COLOR LCD DISPLAY INFORMATION PANEL MAIN RDS mode display COLOR LCD DISPLAY INFORMATION PANEL VRX633R... -
Page 6: Cd/Md Changer Mode Display
CD/MD Changer mode display COLOR LCD DISPLAY INFORMATION PANEL MAIN TV mode display COLOR LCD DISPLAY INFORMATION PANEL MAIN VRX633R... -
Page 7: Dab Mode Display
DAB mode display COLOR LCD DISPLAY DVD Changer mode display COLOR LCD DISPLAY While the car is moving, the screen below is dis- played. AUDIO PROGRAM ONLY INFORMATION PANEL INFORMATION PANEL MAIN • No sub-indication VRX633R... -
Page 8: Remote Control
• When replacing batteries, replace both batteries with new ones. • Do not short-circuit, disassemble or heat batteries. • Do not dispose of batteries into fire or flames. • Dispose of spent batteries properly. VRX633R When the panel is open... -
Page 9: Functions Of Remote Control Unit Buttons
(Playback informa- tion is displayed.) When pressed and held with Superimpose on: Switches the screen sizes. Preset scan. When pressed and held for 2 seconds: Auto store. No function. Switches between TV and VTR. Switches the TV mode. VRX633R... -
Page 10: Dcp
VRX633R 2. Lock the DCP/Operation Panel at the upper center until a click is heard. -
Page 11: Operations
CD changer switches to that function’s display, then returns DVD changer back to the preferred display several seconds af- ter the adjustment. w (up) or z z (down) to adjust the CAUTION VRX633R... -
Page 12: Showing A Mode Display
When adjusting the angle of the display be careful no to let your fingers get caught by the panel or instrument panel of the vehicle. VRX633R 3. To store the Color LCD display ¥ in the source unit, turn it to the horizontal position until a click is heard. - Page 13 Adjusting range of the fader: front 12 / rear 12 5. When the adjustment is finished, operate the JOYSTICK § rightward or leftward to move the cursor to “MENU”. Then press the ENT at the center of the JOYSTICK § to return to the AUDIO-MODE display. Basic Operations VRX633R...
-
Page 14: Radio Operations
• CT data is not transmitted in some countries and by some broadcast stations. Also, in some areas, the CT may not be displayed accurately. VRX633R Radio Operations Listening to the radio 1. Press the FNC button 1 and select the RA- DIO mode. -
Page 15: Auto Store
This function is useful when searching for desired station in memory. 1. Press the PS/AS button 5. 2. When the desired station is tuned in, press the PS/AS button 5 again to continue receiv- ing that station. VRX633R... -
Page 16: Rds Operations
This function only operates when the DAH9500z DAB unit, sold separately, is connected. VRX633R 1. Press the ADJ button £ to show the adjust- ment selection display. 2. Operate the JOYSTICK § upward or down- ward to select “LINKACT”. -
Page 17: Selecting Pty
3. Press the right or left side of the SEARCH button 2. If you press the right side, the unit seeks a PTY broadcast moving up the fre- quencies; if you press the left side, it seeks moving down the frequencies. VRX633R... - Page 18 OLDIES Oldies FOLK M Folk music DOCUMENT Documentaries VRX633R Operating the PTY SELECT display when the panel is open 1. Press the PTY button 8 to select the PTY SELECT display. 2. In the PTY SELECT display, PTY is selected and PTY memory can be adjusted.
-
Page 19: Cd Changer Operations
“----------” appears in the dis- play. Scrolling a CD-text title When a CD-text title is longer than 16 charac- ters (8 characters when the panel is closed), you can scroll the display as follows. CD-text VRX633R... -
Page 20: Top Function
2. Press the left side of the SEARCH button 2 twice to move to the beginning of the previ- ous track. VRX633R Fast-forward/Fast-backward Fast-forward Press and hold the right side of the SEARCH button 2 for 1 second or longer. -
Page 21: Md Changer Operations
1. Press the TITLE button ¢ for 1 second or longer to scroll through the disc title. 2. To scroll the track title, press for 1 second or longer the TITLE button ¢ within 30 seconds after scrolling the disc title. VRX633R... -
Page 22: Selecting An Md
If an MD is not loaded in a slot of the MD changer, pressing the DIRECT button # corresponding to its disc number is invalid. VRX633R Scan play The scan play locates and plays the first 10 sec- onds of each track on a disc automatically. This function continues on the disc until it is cancelled or the mode is changed. -
Page 23: Dvd Changer Operation
In addition, audio cannot be reproduced during slow playback. Selecting a disc 1. Each of the DIRECT buttons # corresponds to a disc loaded into the magazine. 2. Press the corresponding DIRECT buttons # (1 to 6) to select the desired disc. VRX633R... - Page 24 1. Press the right or left side of the SEARCH button 2 during playback. Chapters are skipped, as many as the times the button is pressed, and playback starts. VRX633R • Press the d button 2, and playback starts from the beginning of the next chap- ter.
- Page 25 • Press the a button 2, and playback starts from the beginning of the current track. When this button is pressed again within about 2 seconds, playback starts from the beginning of the previous track. VRX633R...
-
Page 26: Random Playback
• Press the d button 2, and playback starts from the beginning of the next track. VRX633R • Press the a button 2, and playback starts from the beginning of the current track. -
Page 27: Tv Operations
Watching TV Notes: • For your safety, the VRX633R has a safety func- tion which turns off the picture when the car is moving, so only the audio can be heard. The pic- ture can only be watched when the car is stopped and the parking break is applied. -
Page 28: Seek Tuning
2. To recall a stored TV station, press the de- sired PRESET button # to select that sta- tion. VRX633R Press and hold one of the PRESET buttons # for 2 seconds or longer to store the current sta- tion into the preset memory. - Page 29 6. When the adjustment is made, operate the JOYSTICK § rightward or leftward to move the cursor to “MENU”. Then press the ENT at the center of the JOYSTICK § to return to the adjustment selection display. VRX633R...
-
Page 30: Digital Radio/Dab Operations
In this case, change the monitor display size to a mode other than the CINEMA mode. VRX633R Digital Radio/DAB Operations About DAB programmes The Digital Audio Broadcasting (hereinafter re- ferred to as “DAB”) system transmits several... - Page 31 Traffic programme (TP) automatic tuning is also possible. RDS interrupt does not function during AM radio reception or in TV mode. VRX633R...
- Page 32 Note: • Only in case of DAB connection, this can be oper- ated even in the RDS tuner mode. VRX633R Information select This function allows selecting a type of INFOR- MATION on INFORMATION interrupt mode. You can set any of the 6 types of INFO below: TRAFFIC, WARNING, NEWS INFO, WEATHER, EVENTS, SP.
- Page 33 1. Press the PTY button 8 to select the PTY SELECT display. 2. In the PTY SELECT display, PTY is selected and PTY memory can be adjusted. Operate the JOYSTICK § rightward or left- ward to select “PTY ITEM” or “PRESET” (by moving the cursor). VRX633R...
-
Page 34: Dynamic Label Function
When the TA, ALARM, information or PTY inter- rupt ends, the volume returns to the level it had before the interrupt. VRX633R Dynamic Label Function A dynamic label (hereinafter referred to as “DLS”) is a text data associated with each DAB service. -
Page 35: Navi Operations
2. Operate the JOYSTICK § upward or down- ward to select “INPUT”. A menu bar is shown to the right to select the following items: “NAVI”: Setting when Clarion NAVI is con- nected; “CCD”: Setting when Clarion CCD cam- era is connected to this unit;... -
Page 36: Ccd Camera
2. Operate the JOYSTICK § upward or down- ward to select “INPUT”. A menu bar is shown to the right to select the following items: “NAVI”: Setting when Clarion NAVI is con- nected; “CCD”: Setting when Clarion CCD camera is connected to this unit;... -
Page 37: Other Functions
In case of 12-CD changer, move the cursor to disc 6 and then operate the JOYSTICK § downward to change over to a list display of discs 7 to 12. 3. Press the TITLE button ¢ again to return to the STANDARD display. Space Backspace Centering VRX633R... - Page 38 RIGHT: Telephone calls can be heard on the right speaker connected to this unit. VRX633R 3. Operate the JOYSTICK § rightward or left- ward to select a desired mode, and then press the ENT at the center of the JOYSTICK § to set it.
-
Page 39: In Case Of Difficulty
The display is made dark at night to prevent the glare (When the headlight of the vehicle is lit in the daytime, the display gets dark). Check that COL and HUE are adjusted properly. Set the NTSC/PAL properly according to the VTR. VRX633R... - Page 40 There are red, green, and blue points in the display. VRX633R Cause A radio wave may not reach sufficiently due to obstruction of mountains or buildings. Check it again at a place where a radio wave can be received properly.
-
Page 41: Error Displays
MD changer. This is a failure of MD changer’s mecha- nism and consult your store of purchase. Replace with a non-scratched, non-warped- disc. Eject the disc then reload it properly. Load a pre-recorded MD in the MD changer. Measure VRX633R... -
Page 42: Specifications
Display method: Transmission type TN liquid crystal display Drive method: TFT (thin-film transistor) active matrix driving Pixels: 280,800 (1200 234) VRX633R General Power source voltage: 14.4 V DC (10.8 to 15.6 V allowable) Ground: Negative Current consumption: 4.0 A (1 W)
