    TPD Series Interface Scale Operation Manual CONTENTS 1. INTRODUCTION----------------------------------------------------------------------------- - 1 - 2. INSTALLATION------------------------------------------------------------------------------- - 1 - 2.1 Installation------------------------------------------------------------------------------ - 1 - 2.2 Leveling--------------------------------------------------------------------------------- - 1 - 2.3 Power Connection-------------------------------------------------------------------- - 1 - 2.4 Rechargeable battery operation-------------------------------------------------- - 1 - 2.4.1 Charging the battery---------------------------------------------------------- 2 -...
  • Page 3: Introduction

    TPD Series Interface Scale Operation Manual 1. INTRODUCTION The TPD series interface scale that amplifies signals from a load cell, converts it to  digital data and displays it as a mass value It is suitable for general weighing applications ...
  • Page 4: Charging The Battery

    TPD Series Interface Scale Operation Manual  Please use the supplied battery charger for charging the battery immediately,or scale cannot be used. 2.4.1 Charging the battery Before the first use, the battery should be charged by connecting it to the mains ...
  • Page 5: Operation

    TPD Series Interface Scale Operation Manual 5. OPERATION 5.1 Switching on/off Switch on the scale by pressing key,Display will be show the scale version  and then come to normal weighing mode.  To switched off the scale, press key again.
  • Page 6: Back Light Setting

    TPD Series Interface Scale Operation Manual 5.5 Back light Setting It allows choosing the back light operation. Press key during that start up ,display will be show “F0 BL” Press key to enter. Press key to change the settings back light display mode to Auto/Off/On.
  • Page 7: Bluetooth Operation (Optional)

    TPD Series Interface Scale Operation Manual 5.7 Bluetooth Operation (Optional) 5.7.1 Bluetooth Testing Tool Installation Note: The following steps used for testing communication (only BLE Utility available for testing ) ▪ Turn on the BLE Utility software in your phone, it can be download from AppGallery ▪...
  • Page 8 TPD Series Interface Scale Operation Manual ② ① ④ ③ - 6 -...
  • Page 9: Con2 Communication Protocol Testing

    TPD Series Interface Scale Operation Manual 5.7.3 CON2 Communication Protocol Testing Turn on the scale. Press key during that start up ,display will be show “F0 BL” Press key until display show “F2 COM” Press key to confirm,display will be show “BT”...
  • Page 10 TPD Series Interface Scale Operation Manual ② ① ④ ③ - 8 -...
  • Page 11: Ask Command Testing

    TPD Series Interface Scale Operation Manual 5.7.4 ASK Command Testing Turn on the scale. Press key during that start up ,display will be show “F0 BL”. Press key until display show “F2 COM”. Press key to confirm,display will be show “BT”...
  • Page 12 TPD Series Interface Scale Operation Manual ② ① ④ ③ - 10 -...
  • Page 13: Pos/Ecr Protocol Selection

    TPD Series Interface Scale Operation Manual 5.8 POS/ECR protocol selection Turn on the scale. Press key during that start up ,display will be show “F0 BL” Press key until display show “F2 COM” Press key to confirm,display will be show “BT”...
  • Page 14: Parameter Setting

    TPD Series Interface Scale Operation Manual 6 PARAMETER SETTING Enter into the Menu key during that start up ,display will be shown “F0 BL”  Press Enter to Selected Menu  Press , it can confirm which will be shown displayed.
  • Page 15: Menu Block

    TPD Series Interface Scale Operation Manual 6.1 MENU BLOCK Menu Sub-Menu Description To set backlight function F0 BL AUTO Auto off function disable F1 OFF Scale will be auto off three minutes later Scale will be auto off 10 minutes later...
  • Page 16: Diagram: Serial Interface

    TPD Series Interface Scale Operation Manual NTEP approval NTEP None approval NONE SLSI approval SLSI Calibration CAL KG P1 CAL CAL LB Set external resolution 3000\3000R\ P2 RES 3000I/6000 6kg (12 lb) Set Scale Capacity 12kg(30 lb) P3 CAP 30kg(60 lb)
  • Page 17: Specification

    TPD Series Interface Scale Operation Manual 8. SPECIFICATION MODEL TPD-12 TPD-30 TPD-60 Maximum 12 lb / 6 kg / 192 oz 30 lb / 12 kg /480 oz 60 lb / 30 kg / 960 oz Capacity Minimum 0.04 lb / 20 g / 1 oz 0.1 lb / 40 g / 2 oz...
  • Page 18: Dimmensions(Inch/Mm)

    TPD Series Interface Scale Operation Manual 9. DIMMENSIONS(inch/mm) - 16 -...
  • Page 19: Error Message

    TPD Series Interface Scale Operation Manual 10.ERROR MESSAGE Error Message Description Solution Zero setting error Zero setting range exceeded due to Err 4 switching on.(4%max) Make sure platform empty. A/D value out of range Make sure platform empty and check the Err 6 pan is installed proper.
