In - Dash Mounting
The iScan V90 comes with mounting hardware to mount
the display in-dash. Four mounting screws and a cutout
diagram are included.
For in-dash mounting, the mounting base portion of the
Quick Disconnect Mount is removed. To remove the
mounting base loosen the thumb screw until it seperates
from the upper portion of the Quick Disconnect Mount.
While the cutout is included, dimensions of the cutout and
pilot holes has been included in the drawing below.
8.7" [220mm]
8.3" [211mm]
Loosen to remove
