1470/1471 Imager User's Manual
Serial Triggering (continued)
Trigger Defaults
Note: A one to three digit decimal number and Save are required after reading this
programming bar code. See "Decimal to Hex to ASCII Conversion Chart" later in this
chapter and the "General Programming Chart" in Appendix B.

Trigger Timeout

Use this selection to set a timeout (in quarter seconds) of the imager's trigger. Once the
imager has timed out, it must be triggered again either serially or manually. For help
with serial triggering, see "Serial Triggering" earlier in this chapter. Set the Trigger
Timeout to 00 if you don't want a Trigger Timeout. The default setting is 120 seconds.
In the Communication tab of Visual Menu, enter a number from 0 to 120 in the Trigger
Timeout (250 ms increments) field. Click the Write Settings to Device button (
send the new setting to the imager.
Or scan the following bar code and then scan one to three number bar codes from the
"General Programming Chart" in Appendix B.
Set Timeout
3-22
*
) to
