Installation Manual
P/N 0-360049-02
ScanPlus 1800
Hand-held Scanner

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ScanPlus 1800 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Intermec ScanPlus 1800

Summary of Contents for Intermec ScanPlus 1800

  • Page 1 Installation Manual P/N 0-360049-02 ScanPlus 1800 Hand-held Scanner...
  • Page 2 ScanPlus 1800 - Installation Manual - Edition 1.5 - compatible with EasySet System sp1800en.cmd - 99/07/26 The ScanPlus 1800 ST is a Class 2 Laser Scanner. Fix the laser warning labels onto the product if they are not already present.

  • Page 3: Table Of Contents

    14 predefined terminal selections ... 19 custom interface number ... 28 4. Data transmission settings... 29 keyboard wedge... 30 ScanPlus 1800 - Installation Manual keyboard wedge ... 14 RS-232 ... 15 laser emulation ... 16 wand emulation ... 17 IBM 46xx cash registers...
  • Page 4 64 inter-message delay ... 64 transmitted symbology type ... 66 margin size ... 66 logical signal state during transmission ... 67 logical signal state outside transmission... 67 pulse duration ... 68 ScanPlus 1800 - Installation Manual...
  • Page 5 Code 128 / EAN 128 ... 92 Interleaved 2 of 5 ... 95 Matrix 2 of 5 ... 98 MSI Code... 100 ScanPlus 1800 - Installation Manual inter-message delay ... 69 inter-message delay ... 71 inter-character delay ... 73 inter-message delay ... 74 start/stop ...
  • Page 6 ...123 standard mode with aiming beam...124 energy saver mode...124 trigger read duration ...125 predefined security levels ...129 consecutive same read data validation...130 timeout between identical consecutive codes ...130 timeout between different consecutive codes...131 ScanPlus 1800 - Installation Manual...
  • Page 7 B. Additional preamble / postamble characters—Keyboard wedge... 157 C. Number codes ... 163 D. Test codes... 165 Index ... 167 ScanPlus 1800 - Installation Manual volume ... 132 note (tone frequency)... 132 power-up beeps / power-up LED... 133 good read beeps... 133 good read LED ...
  • Page 8 Contents ScanPlus 1800 - Installation Manual...

  • Page 9: Using Easyset

    1. Using EasySet - offline setup 1. select your Intermec product in EasySet ("Select reader" icon over the product image) 2. double-click the setup commands in EasySet to send them to the setup sheet 3. print out the setup sheet and read the configuration codes...

  • Page 10: Online Setup With Rs-232 Cable 0-364032-00

    3. connect the power supply to the RS-232 cable and provide electrical power 4. select your Intermec product in EasySet ("Select reader" icon over the product image) 5. read the "start EasySet online setup" code (double-click to send it to the setup sheet and print it out, or read it from the Getting Started Guide or Installation Manual) 6.

  • Page 11: Reset All Parameters

    - after a global reset, you must select the terminal / cash register used in your application (>> next section) and customize your setup parameters if required ScanPlus 1800 - Installation Manual reset factory defaults \46\42\60 2. Reset all parameters...
  • Page 12 2. Reset all parameters ScanPlus 1800 - Installation Manual...

  • Page 13: Terminal / Cash Register Used In Your Application

    - energy saver trigger models : if the trigger is activated, you will have to press the trigger to see the power-up flashes - database of all supported terminals (look for your system configuration in the list) ScanPlus 1800 - Installation Manual 3. Terminal / cash register used in your application terminal selector (all terminals): this option only available...

  • Page 14: Connections

    3. Terminal / cash register used in your application connections connections keyboard wedge DIN/mini-DIN adaptor cable (standard wedge) standard wedge cable 0-364037-00 DEC VT 220/320/420 cable 0-364037-02 Wyse cable 0-365036-00 CMM-compatible wedge cable 0-364037-03 "short" MicroBar cables 0-601xxx-xx ScanPlus 1800 - Installation Manual...

  • Page 15: Rs-232

    RS-232 RS-232 direct cable 0-364032-00 dual RS-232 cable 0-364032-01 ScanPlus 1800 - Installation Manual 3. Terminal / cash register used in your application connections...

  • Page 16: Laser Emulation

    3. Terminal / cash register used in your application connections laser emulation laser emulation cable 0-366030-00 ScanPlus 1800 - Installation Manual...

  • Page 17: Wand Emulation

    0-364031-00 (not energy saver) wand emulation cable 0-366031-00 (Intermec Interface / energy saver) ScanPlus 1800 - Installation Manual 3. Terminal / cash register used in your application connections...

  • Page 18: Ibm 46Xx Cash Registers

    3. Terminal / cash register used in your application connections IBM 46xx cash registers IBM 46xx 9x cable 0-365033-00 OCIA cash registers OCIA NCR 7052/7053 cable 0-365035-00 ScanPlus 1800 - Installation Manual...

  • Page 19: Predefined Terminal Selections

    PC - look in the terminal selector if you cannot find your system configuration in this section QWERTY English \41\4A\03\08\60 QWERTZ German \41\4A\03\0C\60 QWERTY Italian \41\4A\03\0E\60 ScanPlus 1800 - Installation Manual AZERTY French \41\4A\03\09\60 QWERTY Swedish / Finnish \41\4A\03\0D\60...
  • Page 20 - look in the terminal selector if you cannot find your system configuration in this section QWERTY PC type \41\4A\06\1A\60 QWERTZ PC type \41\4A\06\1E\60 QWERTY Norwegian \41\4A\03\0F\60 QWERTY Spanish \41\4A\03\11\60 AZERTY PC type \41\4A\06\1B\60 QWERTY PC type Swedish / Finnish \41\4A\06\1F\60 ScanPlus 1800 - Installation Manual...

  • Page 21: Rs-232

    - customize individual RS-232 settings to suit your system after reading this parameter PC Term (19200, 8, none, 2) \41\4A\01\26\60 ScanPlus 1800 - Installation Manual standard RS-232 C (9600, 7, E, 2) \41\4A\01\24\60 TTL logical 0 = 5V (9600, 7, E, 2)
  • Page 22 \41\4A\01\29\60 - for RS-232 C and RS-232 TTL with logical 0 = 0V - allows the ScanPlus 1800 to be configured or controlled directly by the host system via the RS-232 serial port - optimized high-security Code 128 transmission (start/stop, hexadecimal characters, checksum) 1.
  • Page 23 - the ScanPlus 1800 goes into "temporary configuration mode" (see section 7 "Configuration modes and utilities") 4. send the commands from the host terminal to the ScanPlus 1800 (individually or as a list in a batch file) - the values displayed in "display data string mode" are hexadecimal values, make sure...

  • Page 24: Laser Emulation

    4. send "update current configuration" ( \ 4 6 \ 4 1 \ 0 2 \ 6 0 ) if you want to save the new configuration you have sent to the ScanPlus 1800 (see section 7 "Configuration modes and utilities")
  • Page 25 3. Terminal / cash register used in your application predefined terminal selections ScanPlus 1800 product ScanPlus 1800 SR + wand emulation cable ScanPlus 1800 ST + wand emulation cable wand emulation cable digital wand emulation (black high) \41\4A\02\02\60 - bar = 1, space = 0, margin = 0, quiet zone = 0 - good read beeps after transmission, pulse duration = 0.85 ms, intermessage delay = 750...

  • Page 26: Ibm 46Xx Cash Registers

    Port 5x as required by the host) Port 9x \41\4A\01\2E\60 - you cannot send this parameter online to the ScanPlus 1800 through RS-232 cable 0- 364032-00 !!! (send it to the setup sheet and read the configuration code with your normal IBM product cable connected)

  • Page 27: Ocia Cash Registers

    OCIA type TEC 1st type \41\4A\01\38\60 - you cannot send this parameter online to the ScanPlus 1800 through RS-232 cable 0- 364032-00 !!! (send it to the setup sheet and read the configuration code with your normal OCIA product cable connected)

  • Page 28: Custom Interface Number

    3. Terminal / cash register used in your application custom interface number custom interface number - enter a number string and scan End Selection (Appendix C) - for special host system configurations compose: [range: 100-30000] \41\4A\60 ScanPlus 1800 - Installation Manual...

  • Page 29: Data Transmission Settings

    4. Data transmission settings - interface-specific communication parameters - modify data transmission settings to optimize performance ScanPlus 1800 - Installation Manual 4. Data transmission settings...

  • Page 30: Keyboard Wedge

    - default values (*) are for IBM PC AT and compatible - QWERTY English preamble [preamble] [symbology id] none (*) \45\53\3E\00\60 <data> [postamble] - enter an ASCII / Special Wedge Characters string and scan End Selection (Appendix A and B) - maximum = 20 characters compose: \45\53\60 ScanPlus 1800 - Installation Manual...

  • Page 31: Symbology Identifier

    (1) UPC/EAN "standard" lengths = 8, 13, 15 (add-on 2), 18 (add-on 5) characters (2) UPC/EAN other lengths (no check digit, . . .) not transmitted (*) \47\59\60 ScanPlus 1800 - Installation Manual 4. Data transmission settings keyboard wedge <data> [postamble] <data>...
  • Page 32 - enter an ASCII character and scan End Selection (Appendix A) - default = D - activates AIM symbology identifier transmission for all symbologies <data> [postamble] - activates transmission for all symbologies transmitted \47\58\60 transmitted \45\55\60 custom symbology identifier ScanPlus 1800 - Installation Manual...
  • Page 33 \45\59\07\60 - enter an ASCII character and scan End Selection (Appendix A) - default = FF ScanPlus 1800 - Installation Manual 4. Data transmission settings keyboard wedge Code 39: [range: 1] - enter an ASCII character and scan End Selection...
  • Page 34 - enter an ASCII character and scan End Selection (Appendix A) - default = D PDF417: [range: 1] - enter an ASCII character and scan End Selection (Appendix A) - default = * ScanPlus 1800 - Installation Manual \45\59\0E\60 \45\59\13\60...
  • Page 35 - enter an ASCII character and scan End Selection (Appendix A) - default = E ScanPlus 1800 - Installation Manual 4. Data transmission settings keyboard wedge Standard 2 of 5: [range: 1] - enter an ASCII character and scan End Selection...

  • Page 36: Postamble

    4. Data transmission settings keyboard wedge postamble [preamble] [symbology id] none \45\54\3E\00\60 Carriage Return \45\54\04\02\02\60 Field Advance \45\54\04\02\04\60 Down Arrow \45\54\04\02\0F\60 <data> [postamble] Enter (*) \45\54\04\02\01\60 \45\54\04\02\08\60 Field Exit \45\54\04\02\05\60 ScanPlus 1800 - Installation Manual...
  • Page 37 4. Data transmission settings keyboard wedge compose: \45\54\60 - enter an ASCII / Special Wedge Characters string and scan End Selection (Appendix A and B) - maximum = 20 characters ScanPlus 1800 - Installation Manual...

  • Page 38: Special Keys Interpretation (Code 39)

    CLEAR FIELD - LINE FEED RESET CTRL SPECIAL characters emulated key PF10 PF11 PF12 PF13 PF14 PF15 PF16 PF17 PF18 PF19 PF20 PF21 PF22 PF23 PF24 characters ScanPlus 1800 - Installation Manual...
  • Page 39 Example ( . I dual-character combination = <Tab> ) original Code 39 code: msg . Ixx msg - . Ixx ScanPlus 1800 - Installation Manual 4. Data transmission settings keyboard wedge combinations interpreted and transmitted as: x - . I interpreted and transmitted as: msg<Tab>xx...
  • Page 40 - . I interpreted and transmitted as: x - . I msg<Tab>xx msg . Ixx <Tab> x - . I msg - . Ixx msg . Ixx <Tab> x <Tab> ScanPlus 1800 - Installation Manual...

  • Page 41: Special Keys Transmission

    ASCII character: - useful to avoid confusion for applications that already use control sequences as commands ScanPlus 1800 - Installation Manual 4. Data transmission settings keyboard wedge transmitted as: <Backspace> (not <Ctrl> H ) <Tab> (not <Ctrl> I ) (not transmitted) <Enter>...

  • Page 42: Alt Mode

    - transmits ASCII characters for decimal numbers 1 to 27 with the corresponding [<Ctrl> + character] sequence - use only if necessary as transmission is slower !!! (all characters transmitted sequences) <Alt> + <6> + <6> ScanPlus 1800 - Installation Manual \47\4E\60 \41\46\60 <Alt>...

  • Page 43: Inter-Character Delay

    \52\14\60 40 ms \52\28\60 compose (ms): [range: 1-999 ms] \52\60 - enter a number string and scan End Selection (Appendix C) ScanPlus 1800 - Installation Manual 4. Data transmission settings keyboard wedge 10 ms \52\0A\60 30 ms \52\1E\60 50 ms...

  • Page 44: Inter-Message Delay

    (*) \53\00\60 30 ms \53\1E\60 80 ms \53\01\10\60 compose (ms): [range: 1-999 ms] \53\60 - enter a number string and scan End Selection (Appendix C) 10 ms \53\0A\60 50 ms \53\32\60 100 ms \53\01\24\60 ScanPlus 1800 - Installation Manual...

  • Page 45: End-Of-Transmission Keyboard Character Status

    - sets keyboard to lower case or upper case at end of transmission - Code 39 is transmitted in upper case - Code 128 is transmitted in lower case / upper case (full ASCII) lower case (*) \41\44\60 ScanPlus 1800 - Installation Manual 4. Data transmission settings keyboard wedge upper case \41\45\60...

  • Page 46: Baud Rate

    4. Data transmission settings RS-232 RS-232 - default values (*) are for standard RS-232 C (9600, 7, E, 2) baud rate \41\00\60 \41\02\60 1200 \41\04\60 4800 \41\06\60 \41\01\60 \41\03\60 2400 \41\05\60 ScanPlus 1800 - Installation Manual...

  • Page 47: Data Bits

    19200 \41\08\60 data bits 7 (*) \42\60 parity even (*) \46\01\60 none \46\00\60 ScanPlus 1800 - Installation Manual 4. Data transmission settings RS-232 9600 (*) \41\07\60 38400 \41\09\60 \43\60 \46\02\60...

  • Page 48: Stop Bits

    - the same timeout applies to all RS-232 protocols supported 1000 ms (*) \51\0F\28\60 compose (ms): [range: 0-2500 ms] \51\60 - enter a number string and scan End Selection (Appendix C) 2 (*) \45\60 unlimited \51\00\60 ScanPlus 1800 - Installation Manual...

  • Page 49: Enq

    - before reading a new bar code after transmission, the product waits for an ACK (positive acknowledge) from the host system or until the end of the hardware/software protocols time-out not used (*) \48\3E\00\60 ScanPlus 1800 - Installation Manual 4. Data transmission settings RS-232 used (ENQ 05h) \47\3E\05\60...

  • Page 50: Nak

    - a NAK (negative acknowledge) indicates an unsuccessful transmission attempt - after 3 unsuccessful transmission attempts, message is aborted not used (*) \49\3E\00\60 compose: \49\60 - enter an ASCII character and scan End Selection (Appendix A) used (NAK 15h) \49\3E\15\60 ScanPlus 1800 - Installation Manual...

  • Page 51: Xon / Xoff Software Protocol

    - XOFF (ASCII character DC3) from the host at the end of the hardware/software protocols time- out interrupts transmission - XON (ASCII character DC1) restarts the data flow not active (*) \4B\60 ScanPlus 1800 - Installation Manual 4. Data transmission settings RS-232 ScanPlus host terminal ScanPlus...

  • Page 52: Rts / Cts Hardware Protocol

    RTS pulse which can be emitted when each character is transmitted not active (*) \47\5F\00\60 active, RTS idle after whole message \47\5F\03\60 active, RTS idle after each character \47\5F\01\60 active, RTS pulse on each character \47\5F\02\60 ScanPlus 1800 - Installation Manual active \4A\60...

  • Page 53: Preamble

    [preamble] [symbology id] none (*) \45\53\3E\00\60 preamble / postamble [preamble] [symbology id] ScanPlus 1800 - Installation Manual 4. Data transmission settings RS-232 <data> [postamble] - enter an ASCII string and scan End Selection (Appendix A) - maximum = 20 characters <data>...

  • Page 54: Symbology Identifier

    (2) UPC/EAN other lengths (no check digit, . . .) not transmitted (*) \47\59\60 <data> [postamble] <data> [postamble] <symbology_id> <processing_option> 0, 2, 4 0, 1, 2, 4 0, 1 0, 1, 2 0, 1, 2 0, 1 0, 1 0, 3, 4 ScanPlus 1800 - Installation Manual...

  • Page 55: [Preamble] [Symbology Id] [Postamble]

    Codabar: [range: 1] \45\59\04\60 - enter an ASCII character and scan End Selection (Appendix A) - default = D ScanPlus 1800 - Installation Manual 4. Data transmission settings RS-232 - activates AIM symbology identifier transmission for all symbologies <data> [postamble]...

  • Page 56: Code 39 ] A

    - enter an ASCII character and scan End Selection (Appendix A) - default = D EAN-13: [range: 1] - enter an ASCII character and scan End Selection (Appendix A) - default = F ScanPlus 1800 - Installation Manual \45\59\01\60 \45\59\0B\60 \45\59\06\60...

  • Page 57: Interleaved 2 Of

    - enter an ASCII character and scan End Selection (Appendix A) - default = D ScanPlus 1800 - Installation Manual 4. Data transmission settings RS-232 Matrix 2 of 5: [range: 1] - enter an ASCII character and scan End Selection...

  • Page 58: Telepen ] B

    - enter an ASCII character and scan End Selection (Appendix A) - default = D UPC-A: [range: 1] - enter an ASCII character and scan End Selection (Appendix A) - default = A ScanPlus 1800 - Installation Manual \45\59\03\60 \45\59\08\60...

  • Page 59: Postamble

    - enter an ASCII string and scan End Selection (Appendix A) - maximum = 20 characters LRC (longitudinal redundancy check) not active (*) \4F\60 ScanPlus 1800 - Installation Manual 4. Data transmission settings RS-232 <data> [postamble] Carriage Return + Line Feed (*) \45\54\3E\0D\3E\0A\60...

  • Page 60: Inter-Character Delay

    - avoids dropping characters if transmitting decoded data too fast for the host system - do not use for IBM 46xx cash registers or laser/wand emulation !!! none (*) \52\00\60 20 ms \52\14\60 40 ms \52\28\60 active \4E\60 10 ms \52\0A\60 30 ms \52\1E\60 50 ms \52\32\60 ScanPlus 1800 - Installation Manual...

  • Page 61: Inter-Message Delay

    - avoids dropping characters if transmitting decoded data too fast for the host system none (*) \53\00\60 30 ms \53\1E\60 80 ms \53\01\10\60 ScanPlus 1800 - Installation Manual 4. Data transmission settings RS-232 10 ms \53\0A\60 50 ms \53\32\60 100 ms...
  • Page 62 4. Data transmission settings RS-232 compose (ms): [range: 1-999 ms] \53\60 - enter a number string and scan End Selection (Appendix C) ScanPlus 1800 - Installation Manual...

  • Page 63: Laser Emulation

    - defined in increments of narrow bar width (50 µs) 10 x narrow bar width (*) \5A\0A\60 ScanPlus 1800 - Installation Manual 4. Data transmission settings laser emulation transmission in Code 39 - original code must not contain characters not...

  • Page 64: Logical Signal State During Transmission

    (*) \53\00\60 compose (x narrow bar width): - enter a number string and scan End Selection (Appendix C) bar = 0, space = 1, margin = 1 quiet zone = 0 ScanPlus 1800 - Installation Manual \5A\60 \55\60 \56\60...
  • Page 65 \53\1E\60 80 ms \53\01\10\60 compose (ms): [range: 1-999 ms] \53\60 - enter a number string and scan End Selection (Appendix C) ScanPlus 1800 - Installation Manual 4. Data transmission settings laser emulation 10 ms \53\0A\60 50 ms \53\32\60 100 ms...

  • Page 66: Wand Emulation

    - defined in increments of narrow bar width (50 µs) 10 x narrow bar width (*) \5A\0A\60 transmission in Code 39 - original code must not contain characters not supported by Code 39 ScanPlus 1800 - Installation Manual \5E\01\60...

  • Page 67: Logical Signal State During Transmission

    = 0, space = 1, margin = 1 (*) \55\60 logical signal state outside transmission quiet zone = 1 (*) \57\60 ScanPlus 1800 - Installation Manual 4. Data transmission settings wand emulation compose (x narrow bar width): - enter a number string and scan End Selection (Appendix C)

  • Page 68: Pulse Duration

    0.66 ms (50 cm/s EAN 100%) \58\01\02\60 1.32 ms (25 cm/s EAN 100%) \58\02\04\60 0.19 ms (175 cm/s EAN 100%) \58\13\60 0.44 ms (75 cm/s EAN 100%) \58\2C\60 0.88 ms (37.5 cm/s EAN 100%) \58\01\18\60 ScanPlus 1800 - Installation Manual...

  • Page 69: Inter-Message Delay

    - avoids dropping characters if transmitting decoded data too fast for the host system none (*) \53\00\60 30 ms \53\1E\60 ScanPlus 1800 - Installation Manual 4. Data transmission settings wand emulation 2.64 ms (12.5 cm/s EAN 100%) compose (x 10 µs): - enter a number string and scan End Selection...
  • Page 70 4. Data transmission settings wand emulation 80 ms \53\01\10\60 compose (ms): [range: 1-999 ms] \53\60 - enter a number string and scan End Selection (Appendix C) 100 ms \53\01\24\60 ScanPlus 1800 - Installation Manual...

  • Page 71: Ibm 46Xx Cash Registers

    - avoids dropping characters if transmitting decoded data too fast for the host system - do not send this parameter online to the ScanPlus 1800 through RS-232 cable 0-364032-00 !!! (send it to the setup sheet and read the configuration code with your normal IBM product cable...
  • Page 72 4. Data transmission settings IBM 46xx cash registers compose (ms): [range: 1-999 ms] \53\60 - enter a number string and scan End Selection (Appendix C) ScanPlus 1800 - Installation Manual...

  • Page 73: Ocia Cash Registers

    - do not use for IBM 46xx cash registers or laser/wand emulation !!! - do not send this parameter online to the ScanPlus 1800 through RS-232 cable 0-364032-00 !!! (send it to the setup sheet and read the configuration code with your normal OCIA product cable...

  • Page 74: Inter-Message Delay

    - avoids dropping characters if transmitting decoded data too fast for the host system - do not send this parameter online to the ScanPlus 1800 through RS-232 cable 0-364032-00 !!! (send it to the setup sheet and read the configuration code with your normal OCIA product cable...
  • Page 75 (ms): [range: 1-999 ms] \53\60 - enter a number string and scan End Selection (Appendix C) ScanPlus 1800 - Installation Manual 4. Data transmission settings OCIA cash registers...
  • Page 76 4. Data transmission settings OCIA cash registers ScanPlus 1800 - Installation Manual...

  • Page 77: Symbologies

    - use reset factory defaults to reset all the symbology parameters to their factory default settings) ScanPlus 1800 - Installation Manual disable all symbologies \41\4B\60 5. Symbologies...

  • Page 78: Codabar

    (*) \41\53\60 start/stop not transmitted (*) \43\4D\60 A, B, C, D \43\4F\60 DC1, DC2, DC3, DC4 \43\51\60 active \41\52\60 a, b, c, d \43\4E\60 a, b, c, d t, n, *, e \43\50\60 ScanPlus 1800 - Installation Manual...

  • Page 79: Clsi Library System

    - the values are added and the check is calculated: check = [(next multiple of 16) - (sum of assigned AIM values)] Example AIM values = 16 + 0 + 1 + 2 + 3 + 4 + 17: ScanPlus 1800 - Installation Manual 9990 4 = 4 5 = 5...

  • Page 80: Barcode Length

    - minimum length possible = 3 characters checked and transmitted [check digit] <stop> - cancels any fixed length / minimum length settings and accepts any valid length (3 or more characters) ScanPlus 1800 - Installation Manual \46\54\60 any length \43\55\00\60...
  • Page 81 - to optimize decoding performance and increase security, select the same length as the minimum length in your application (do not select a shorter length !!) ScanPlus 1800 - Installation Manual 5. Symbologies Codabar minimum length = 6 (*) \43\55\06\60...

  • Page 82: Code 39

    - default format = Standard 43 Characters active (*) \41\4C\60 format standard 43 characters (*) \42\4A\60 - extra characters encoded using 1 of 4 control characters ($, %, /, +) combined with a letter: ScanPlus 1800 - Installation Manual not active \41\4D\60 full ASCII \42\4B\60...
  • Page 83 ScanPlus 1800 - Installation Manual Code 39 ASCII Space 5. Symbologies Code 39...
  • Page 84 5. Symbologies Code 39 Code 39 ASCII " & < > ScanPlus 1800 - Installation Manual...
  • Page 85 ScanPlus 1800 - Installation Manual Code 39 ASCII 5. Symbologies Code 39...

  • Page 86: Start/Stop

    5. Symbologies Code 39 start/stop not transmitted (*) \42\4D\60 Code 39 ASCII ScanPlus 1800 - Installation Manual...

  • Page 87: Check Digit

    " $ " and " * " accepted \42\4E\03\60 check digit modulo 43 - provides extra validation of data checked and transmitted \42\50\60 ScanPlus 1800 - Installation Manual not used (*) \42\4F\60 checked but not transmitted 5. Symbologies Code 39 transmitted \42\4C\60 "...
  • Page 88 - only used for codes with 7 characters checked and transmitted \42\52\60 Italian CPI - Italian pharmaceutical industry - transmitted as standard Code 39 if checksum not validated checked and transmitted \42\54\60 checked but not transmitted \42\53\60 checked but not transmitted \42\55\60 ScanPlus 1800 - Installation Manual...

  • Page 89: Barcode Length

    - cancels the last minimum length selection and accepts any valid length (3 or more characters) minimum length = 6 \42\5C\06\60 ScanPlus 1800 - Installation Manual [check digit] <stop> compose minimum length: [range: 3-50] - enter a number string and scan End Selection...

  • Page 90: Code 93

    - enter a number string and scan End Selection (Appendix C) - to optimize decoding performance and increase security, select the same length as the minimum length in your application (do not select a shorter length !!) ScanPlus 1800 - Installation Manual active \41\5E\60 \45\42\60...
  • Page 91 5. Symbologies Code 93 minimum length = 6 \45\42\06\60 ScanPlus 1800 - Installation Manual...

  • Page 92: Code 128 / Ean 128

    \41\5B\60 EAN 128 identifier - the ]C1 AIM identifier for EAN 128 is automatically added by default in front of EAN 128 bar codes include ]C1 identifier (*) \47\5A\01\60 active \41\5A\60 remove ]C1 identifier \47\5A\00\60 ScanPlus 1800 - Installation Manual...

  • Page 93: Cip 128 French Pharmaceutical Codes

    - used as separator when multiple identifiers and their fields are concatenated - Example: useful for keyboard wedge interfaces where the GS character can not be transmitted - enter an ASCII character and scan End Selection (Appendix A) ScanPlus 1800 - Installation Manual 5. Symbologies Code 128 / EAN 128 compose:...

  • Page 94: Barcode Length

    - enter a number string and scan End Selection (Appendix C) - to optimize decoding performance and increase security, select the same length as the minimum length in your application (do not select a shorter length !!) ScanPlus 1800 - Installation Manual \44\55\60...

  • Page 95: Interleaved 2 Of 5

    - especially recommended for variable length Interleaved 2 of 5 and if "consecutive same read data validation" (data decoding security parameters) is not activated mod 10 checked and transmitted \42\5F\60 ScanPlus 1800 - Installation Manual 5. Symbologies Interleaved 2 of 5 not used (*) \43\43\60 checked but not transmitted...

  • Page 96: Barcode Length

    - compose 1 or 2 or 3 fixed lengths provides the best performance and security if the codes in your application have fixed lengths - minimum length possible = 2 characters [check digit] checked but not transmitted \43\42\60 ScanPlus 1800 - Installation Manual...
  • Page 97 (do not select a shorter length !!) ScanPlus 1800 - Installation Manual 5. Symbologies Interleaved 2 of 5 - cancels any fixed length / minimum length settings and accepts any valid length (2 or more...

  • Page 98: Matrix 2 Of 5

    - enter a number string and scan End Selection (Appendix C) - to optimize decoding performance and increase security, select the same length as the minimum length in your application (do not select a shorter length !!) ScanPlus 1800 - Installation Manual active \42\40\60 \46\59\60...
  • Page 99 5. Symbologies Matrix 2 of 5 minimum length = 6 (*) \46\59\06\60 ScanPlus 1800 - Installation Manual...

  • Page 100: Msi Code

    - numerical symbology not active (*) \41\59\60 check digit mod 10 checked and transmitted (*) \44\5A\60 double mod 10 checked and transmitted \44\5B\60 active \41\58\60 checked but not transmitted \44\5C\60 checked but not transmitted \44\5D\60 ScanPlus 1800 - Installation Manual...

  • Page 101: Barcode Length

    - cancels the last minimum length selection and accepts any valid length (2 or more characters) minimum length = 6 (*) \44\5F\06\60 ScanPlus 1800 - Installation Manual <check digit> compose minimum length: [range: 2-50] - enter a number string and scan End Selection...

  • Page 102: Pdf417

    5. Symbologies PDF417 PDF417 - two-dimensonal symbology only available with ScanPlus 1800 PDF - alphanumeric full ASCII symbology - letter case defined active (*) \48\4D\60 - only available with ScanPlus 1800 PDF macro PDF - macro PDF is used when : - a long message requires more than one PDF417 label - "optional fields"...
  • Page 103 - only present in macro PDF codes - always transmitted with "unbuffered" option not transmitted (*) \48\50\00\60 ScanPlus 1800 - Installation Manual 5. Symbologies PDF417 - for multi-label PDF417 messages that are too long for the ScanPlus buffer (memory overflow)
  • Page 104 - transmit additional information if present in the label - one or more fields possible in the same label file name not transmitted (*) \48\51\00\60 segment count not transmitted (*) \48\52\00\60 time stamp not transmitted (*) \48\53\00\60 transmitted \48\51\01\60 transmitted \48\52\01\60 transmitted \48\53\01\60 ScanPlus 1800 - Installation Manual...
  • Page 105 (*) \48\54\00\60 addressee not transmitted (*) \48\57\00\60 file size not transmitted (*) \48\58\00\60 checksum not transmitted (*) \48\59\00\60 ScanPlus 1800 - Installation Manual 5. Symbologies PDF417 transmitted \48\54\01\60 transmitted \48\57\01\60 transmitted \48\58\01\60...
  • Page 106 5. Symbologies PDF417 transmitted \48\59\01\60 ScanPlus 1800 - Installation Manual...

  • Page 107: Plessey Code

    Plessey Code - numerical symbology not active (*) \41\5D\60 check digit not transmitted (*) \44\57\60 ScanPlus 1800 - Installation Manual 5. Symbologies Plessey Code active \41\5C\60 transmitted \44\56\60...

  • Page 108: Barcode Length

    - enter a number string and scan End Selection (Appendix C) - to optimize decoding performance and increase security, select the same length as the minimum length in your application (do not select a shorter length !!) ScanPlus 1800 - Installation Manual <stop> \44\59\60...

  • Page 109: Standard 2 Of 5

    (*) \41\51\60 format Identicon (6 start/stop bars) (*) \43\47\60 check digit mod 10 not used (*) \43\4A\60 ScanPlus 1800 - Installation Manual 5. Symbologies Standard 2 of 5 \41\50\60 Computer Identics (4 start/stop bars) \43\46\60 checked and transmitted \43\48\60 active...

  • Page 110: Barcode Length

    - minimum length possible = 3 characters [check digit] - cancels any fixed length / minimum length settings and accepts any valid length (3 or more characters) any length \43\4C\00\60 ScanPlus 1800 - Installation Manual...
  • Page 111 - to optimize decoding performance and increase security, select the same length as the minimum length in your application (do not select a shorter length !!) ScanPlus 1800 - Installation Manual 5. Symbologies Standard 2 of 5 minimum length = 6 (*) \43\4C\06\60...

  • Page 112: Telepen

    5. Symbologies Telepen Telepen - alphanumeric full ASCII symbology - letter case defined - default format = ASCII not active (*) \42\43\60 format ASCII (*) \47\4C\60 active \42\42\60 numeric \47\4B\60 ScanPlus 1800 - Installation Manual...

  • Page 113: Upc / Ean

    - activates the UPC/EAN families currently selected (deactivated reactivated, use "reactivate all" to select all UPC/EAN) UPC-A deactivated \43\5D\60 EAN-8 deactivated \43\5F\60 ScanPlus 1800 - Installation Manual families 5. Symbologies UPC / EAN not active \41\57\60 UPC-E deactivated \43\5E\60 EAN-13 deactivated \44\40\60...

  • Page 114: Add-On Digits

    - reactivates all deactivated UPC/EAN families add-on digits not required but transmitted if read (*) \44\43\60 add-on 2 not active (*) \44\41\60 add-on 5 not active (*) \46\46\60 required and transmitted \44\42\60 active \46\44\60 active \46\45\60 ScanPlus 1800 - Installation Manual...

  • Page 115: Check Digit

    <leading character> <number system> UPC-A transmitted (*) \44\46\60 UPC-E transmitted (*) \44\4A\60 EAN-8 transmitted (*) \46\49\60 ScanPlus 1800 - Installation Manual 5. Symbologies UPC / EAN <data> <check digit> not transmitted not transmitted not transmitted \44\47\60 \44\4B\60 \46\4A\60...

  • Page 116: Upc Number System

    - regular UPC-A has a transmitted number system equal to 0 - to transmit the additional leading character (country code), select the "UPC-A transmitted as EAN-13" option transmitted (*) \44\44\60 not transmitted <data> <check digit> not transmitted ScanPlus 1800 - Installation Manual \46\48\60 \44\45\60...

  • Page 117: Re-Encoding Upc-A, Upc-E, Ean-8

    - to transmit the additional leading character (country code), select the "UPC-A transmitted as EAN-13" option UPC-A transmitted as EAN-13 (*) \44\4F\60 UPC-E transmitted as UPC-E (*) \44\4C\60 ScanPlus 1800 - Installation Manual 5. Symbologies UPC / EAN not transmitted <data> <check digit> UPC-A transmitted as UPC-A...
  • Page 118 5. Symbologies UPC / EAN EAN-8 transmitted as EAN 8 (*) \44\50\60 UPC-E transmitted as UPC-A \44\4D\60 EAN-8 transmitted as EAN-13 \44\51\60 ScanPlus 1800 - Installation Manual...

  • Page 119: Operating Settings

    6. Operating settings 6. Operating settings - settings that affect the way your product operates (trigger settings, flashing mode, data decoding security settings, beep characteristics) ScanPlus 1800 - Installation Manual...

  • Page 120: Trigger Activation

    6. Operating settings trigger activation trigger activation - LASER SAFETY: the ScanPlus 1800 ST is a Class 2 Laser product - CAUTION - LASER LIGHT WHEN OPEN. DO NOT STARE INTO BEAM. - for laser and ccd trigger models standard mode laser - "trigger not active"...

  • Page 121: Trigger Operating Scenarios

    (2 s)—repeat read duration after good read - read a number of bar codes after a single press of the trigger press trigger good read ScanPlus 1800 - Installation Manual 6. Operating settings trigger activation good read standby...
  • Page 122 - avoids double reading—when bar codes are close together for example press trigger active while trigger pressed—standby after good read - selective reading of single bar codes press trigger good read standby good read standby ScanPlus 1800 - Installation Manual...

  • Page 123: Standard Mode

    - no current peaks during reading - LASER SAFETY: the ScanPlus 1800 ST is a Class 2 Laser product - CAUTION - LASER LIGHT WHEN OPEN. DO NOT STARE INTO BEAM. active for read duration (2 s), repeat read duration after good read...

  • Page 124: Standard Mode With Aiming Beam

    2. keep the trigger pressed (if applicable) and connect the ScanPlus over a "reset factory defaults" configuration code (read from setup sheet, Getting Started Guide or Installation active for read duration (2 s), standby after good read \46\5C\45\5D\02\46\4D\60 ScanPlus 1800 - Installation Manual...

  • Page 125: Trigger Read Duration

    Manual) - LASER SAFETY: the ScanPlus 1800 ST is a Class 2 Laser product - CAUTION - LASER LIGHT WHEN OPEN. DO NOT STARE INTO BEAM. active for read duration (2 s), repeat read duration after good read \46\5B\45\5D\02\46\4C\60 active while trigger pressed, standby after good read...

  • Page 126: Flashing Mode

    6. Operating settings flashing mode flashing mode - LASER SAFETY: the ScanPlus 1800 ST is a Class 2 Laser product - CAUTION - LASER LIGHT WHEN OPEN. DO NOT STARE INTO BEAM. - for laser and ccd models - activating flashing mode deactivates trigger options and autostand mode...

  • Page 127: Autostand Mode

    (default = 10 sec) - each good read within the activation cycle duration starts a new activation cycle - if there is no good read before the end of the activation cycle duration, the ScanPlus 1800 returns to automatic standby...
  • Page 128 6. Operating settings autostand mode compose activation cycle duration (sec): [range: 1-63 sec] \4C\40\01\47\50\46\4D\47\51\60 - enter a number string and scan End Selection (Appendix C) ScanPlus 1800 - Installation Manual...

  • Page 129: Data Decoding Security

    - 4 consecutive same reads before transmission - 350 ms between identical consecutive codes - 30 ms between different consecutive codes ScanPlus 1800 - Installation Manual 6. Operating settings data decoding security - 2 consecutive same reads before transmission - 300 ms between identical consecutive codes...

  • Page 130: Consecutive Same Read Data Validation

    300 ms (*) \45\4C\04\2C\60 compose number of same reads: [range: 0-10] - enter a number string and scan End Selection (Appendix C) - enter a number string and scan End Selection (Appendix C) ScanPlus 1800 - Installation Manual \45\4B\60 compose (ms): \45\4C\60...

  • Page 131: Timeout Between Different Consecutive Codes

    - prevents unwanted reading of other bar codes on the same label none (*) \45\4D\0A\60 ScanPlus 1800 - Installation Manual 6. Operating settings data decoding security compose (ms): - enter a number string and scan End Selection...

  • Page 132: Beeps / Green Indicator Led

    (tone frequency) high (2093.04 Hz) (*) \4B\46\07\1E\60 medium (1760 Hz) \4B\46\08\38\60 compose frequency (Hz): [range: 100-4000 Hz] - enter a number string and scan End Selection (Appendix C) ScanPlus 1800 - Installation Manual \4B\47\00\60 low (1318.52 Hz) \4B\46\0B\36\60 \4B\46\60...

  • Page 133: Power-Up Beeps / Power-Up Led

    / power-up LED - 2 beeps = successful power-up - 3 long beeps = EEPROM integrity error (contact your Intermec representative !) on (*) \45\5B\60 good read beeps number - "normal" bar codes: 1 beep (default) = good read...
  • Page 134 (Appendix C) timing - IBM and OCIA cash registers : do not send this parameter online to the ScanPlus 1800 through RS-232 cable 0-364032-00 !!! (send it to the setup sheet and read the configuration code with your normal IBM / OCIA product cable connected)

  • Page 135: Good Read Led

    \45\4F\01\10\60 PDF417 codes - only available with the ScanPlus 1800 PDF - if you remove the ScanPlus from the PDF417 code for more than 10 seconds before you finish reading (before you hear a success beep), the data you have read so far will be lost and you will...
  • Page 136 6. Operating settings beeps / green indicator LED LED flicker - green LED flicker = reading new PDF417 data - the more intensive the flicker, the better the reading performance on (*) \48\4B\01\60 \48\4A\00\60 \48\4B\00\60 ScanPlus 1800 - Installation Manual...

  • Page 137: Configuration Modes And Utilities

    (setup transmitted to the other product but do not affect your reader) - remains active until you switch off the product ScanPlus 1800 - Installation Manual configuration inhibit after 1 mn - protects configuration - configuration only possible before end of 1...
  • Page 138 < 1 flash > N + 1 < 1 long > N + 1 < 2 short > N + 1 < 1 long > < 4 short > N + 1 N + 1 ScanPlus 1800 - Installation Manual...
  • Page 139 - you will need the checksum if you want to send commands directly from the host terminal to the ScanPlus 1800 in "slave mode" (see "predefined terminal selections - RS-232 - special RS-232 configurations" in section 3, "Terminal / cash register used in your application")

  • Page 140: Temporary Configuration Mode

    "update current configuration" is selected update current configuration \46\41\02\60 - permanently saves any temporary configuration actions and quits temporary configuration mode restore current configuration - ignores any temporary configuration actions and quits temporary configuration mode ScanPlus 1800 - Installation Manual \46\41\01\60...

  • Page 141: Ascii Character Codes

    A. ASCII character codes NUL (00h) \3E\00\60 STX (02h) \3E\02\60 EOT (04h) \3E\04\60 ACK (06h) \3E\06\60 ScanPlus 1800 - Installation Manual A. ASCII character codes end selection \64\60 SOH (01h) \3E\01\60 ETX (03h) \3E\03\60 ENQ (05h) \3E\05\60 BEL (07h) \3E\07\60...
  • Page 142 A. ASCII character codes BS (08h) \3E\08\60 LF (0Ah) \3E\0A\60 FF (0Ch) \3E\0C\60 SO (0Eh) \3E\0E\60 HT or TAB (09h) end selection \64\60 ScanPlus 1800 - Installation Manual \3E\09\60 VT (0Bh) \3E\0B\60 CR (0Dh) \3E\0D\60 SI (0Fh) \3E\0F\60...
  • Page 143 DLE (10h) \3E\10\60 DC2 (12h) \3E\12\60 DC4 (14h) \3E\14\60 SYN (16h) \3E\16\60 ScanPlus 1800 - Installation Manual end selection \64\60 A. ASCII character codes DC1 (11h) \3E\11\60 DC3 (13h) \3E\13\60 NAK (15h) \3E\15\60 ETB (17h) \3E\17\60...
  • Page 144 A. ASCII character codes CAN (18h) \3E\18\60 SUB (1Ah) \3E\1A\60 FS (1Ch) \3E\1C\60 RS (1Eh) \3E\1E\60 end selection \64\60 ScanPlus 1800 - Installation Manual EM (19h) \3E\19\60 ESC (1Bh) \3E\1B\60 GS (1Dh) \3E\1D\60 US (1Fh) \3E\1F\60...
  • Page 145 SP (20h) \00\60 " (22h) \02\60 $ (24h) \04\04\60 & (26h) \06\60 ScanPlus 1800 - Installation Manual end selection \64\60 A. ASCII character codes ! (21h) \01\60 # (23h) \03\60 % (25h) \05\60 ' (27h) \07\60...
  • Page 146 A. ASCII character codes ( (28h) \08\60 * (2Ah) \0A\60 , (2Ch) \0C\60 . (2Eh) \0E\60 end selection \64\60 ScanPlus 1800 - Installation Manual ) (29h) \09\60 + (2Bh) \0B\60 - (2Dh) \0D\60 / (2Fh) \0F\0F\60...
  • Page 147 0 (30h) \10\60 2 (32h) \12\60 4 (34h) \14\60 6 (36h) \16\60 ScanPlus 1800 - Installation Manual end selection \64\60 A. ASCII character codes 1 (31h) \11\60 3 (33h) \13\60 5 (35h) \15\60 7 (37h) \17\60...
  • Page 148 A. ASCII character codes 8 (38h) \18\60 : (3Ah) \1A\60 < (3Ch) \1C\60 > (3Eh) \1E\60 end selection \64\60 ScanPlus 1800 - Installation Manual 9 (39h) \19\60 ; (3Bh) \1B\60 = (3Dh) \1D\60 ? (3Fh) \1F\60...
  • Page 149 @ (40h) \20\20\60 B (42h) \22\60 D (44h) \24\60 F (46h) \26\60 ScanPlus 1800 - Installation Manual end selection \64\60 A. ASCII character codes A (41h) \21\60 C (43h) \23\60 E (45h) \25\60 G (47h) \27\60...
  • Page 150 A. ASCII character codes H (48h) \28\60 J (4Ah) \2A\60 L (4Ch) \2C\60 N (4Eh) \2E\60 end selection \64\60 ScanPlus 1800 - Installation Manual I (49h) \29\60 K (4Bh) \2B\60 M (4Dh) \2D\60 O (4Fh) \2F\60...
  • Page 151 P (50h) \30\60 R (52h) \32\60 T (54h) \34\60 V (56h) \36\60 ScanPlus 1800 - Installation Manual end selection \64\60 A. ASCII character codes Q (51h) \31\60 S (53h) \33\60 U (55h) \35\60 W (57h) \37\60...
  • Page 152 A. ASCII character codes X (58h) \38\60 Z (5Ah) \3A\60 \ (5Ch) \3C\60 ^ (5Eh) \3E\3E\60 end selection \64\60 ScanPlus 1800 - Installation Manual Y (59h) \39\60 [ (5Bh) \3B\60 ] (5Dh) \3D\60 _ (5Fh) \3F\60...
  • Page 153 ` (60h) this character not available b (62h) \20\22\60 d (64h) \20\24\60 f (66h) \20\26\60 ScanPlus 1800 - Installation Manual end selection \64\60 A. ASCII character codes a (61h) \20\21\60 c (63h) \20\23\60 e (65h) \20\25\60 g (67h) \20\27\60...
  • Page 154 A. ASCII character codes h (68h) \20\28\60 j (6Ah) \20\2A\60 l (6Ch) \20\2C\60 n (6Eh) \20\2E\60 end selection \64\60 ScanPlus 1800 - Installation Manual i (69h) \20\29\60 k (6Bh) \20\2B\60 m (6Dh) \20\2D\60 o (6Fh) \20\2F\60...
  • Page 155 (70h) \20\30\60 r (72h) \20\32\60 t (74h) \20\34\60 v (76h) \20\36\60 ScanPlus 1800 - Installation Manual end selection \64\60 A. ASCII character codes q (71h) \20\31\60 s (73h) \20\33\60 u (75h) \20\35\60 w (77h) \20\37\60...
  • Page 156 A. ASCII character codes x (78h) \20\38\60 z (7Ah) \20\3A\60 | (7Ch) \20\3C\60 ~ (7Eh) \20\3E\60 end selection \64\60 ScanPlus 1800 - Installation Manual y (79h) \20\39\60 { (7Bh) \20\3B\60 } (7Dh) \20\3D\60 DEL (7Fh) \20\3F\60...

  • Page 157: Additional Preamble / Postamble Characters-Keyboard Wedge

    B. Additional preamble / postamble characters—Keyboard wedge PF 1 \04\02\18\60 PF 3 \04\02\1A\60 PF 5 \04\02\1C\60 PF 7 \04\02\1E\60 ScanPlus 1800 - Installation Manual B. Additional preamble / postamble characters—Keyboard wedge end selection \64\60 PF 2 \04\02\19\60 PF 4 \04\02\1B\60 PF 6 \04\02\1D\60...
  • Page 158 B. Additional preamble / postamble characters—Keyboard wedge PF 9 \04\02\20\60 PF 11 \04\02\22\60 PF 13 \04\02\24\60 PF 15 \04\02\26\60 end selection \64\60 ScanPlus 1800 - Installation Manual PF 8 \04\02\1F\60 PF 10 \04\02\21\60 PF 12 \04\02\23\60 PF 14 \04\02\25\60...
  • Page 159 PF 17 \04\02\28\60 PF 19 \04\02\2A\60 PF 21 \04\02\2C\60 PF 23 \04\02\2E\60 ScanPlus 1800 - Installation Manual B. Additional preamble / postamble characters—Keyboard wedge end selection \64\60 PF 16 \04\02\27\60 PF 18 \04\02\29\60 PF 20 \04\02\2B\60 PF 22 \04\02\2D\60...
  • Page 160 B. Additional preamble / postamble characters—Keyboard wedge \04\02\00\60 RETURN \04\02\02\60 FIELD + \04\02\04\60 HOME \04\02\06\60 end selection \64\60 ScanPlus 1800 - Installation Manual PF 24 \04\02\2F\60 ENTER \04\02\01\60 SEND \04\02\03\60 FIELD EXIT \04\02\05\60...
  • Page 161 TAB = Ctrl i \04\02\08\60 BACK TAB \04\02\0A\60 ARROW RIGHT \04\02\0C\60 ARROW UP \04\02\0E\60 ScanPlus 1800 - Installation Manual B. Additional preamble / postamble characters—Keyboard wedge end selection \64\60 \04\02\07\60 \04\02\09\60 BACK SPACE \04\02\0B\60 ARROW LEFT \04\02\0D\60...
  • Page 162 B. Additional preamble / postamble characters—Keyboard wedge CLEAR \04\02\10\60 \04\02\12\60 LINE FEED \04\02\14\60 end selection \64\60 ScanPlus 1800 - Installation Manual ARROW DOWN \04\02\0F\60 FIELD - \04\02\11\60 \04\02\13\60 RESET \04\02\15\60...

  • Page 163: Number Codes

    C. Number codes \10\60 \12\60 \14\60 \16\60 ScanPlus 1800 - Installation Manual end selection \64\60 C. Number codes \11\60 \13\60 \15\60 \17\60...
  • Page 164 C. Number codes \18\60 end selection \64\60 ScanPlus 1800 - Installation Manual \19\60...

  • Page 165: Test Codes

    D. Test codes Codabar 123456 Code 93 CODE-93 EAN 128 ]C1EAN 128 Standard 2 of 5 123456 ScanPlus 1800 - Installation Manual D. Test codes Code 39 CODE-39 Code 128 CODE-128 Interleaved 2 of 5 12345678901234 Matrix 2 of 5...
  • Page 166 0 1 2 3 4 5 0 0 0 0 Codablock F UBI ScanPlus XP and XP PDF CCD Bar Code Scanners Plessey Code 80001495050 EAN-13 1234567890128 UPC-E 0 1 2 3 4 5 PDF417 Intermec Technologies Corporation PDF417 ScanPlus 1800 - Installation Manual...
