Getting Started Guide
P/N 3-420049-01
MaxiScan 2210
Presentation Scanner
Guía de Iniciación
Guida Introduttiva
Guide de Démarrage
Guia de Iniciação
Anleitung für Einsteiger

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MaxiScan 2210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Intermec MaxiScan 2210

  • Page 1 Getting Started Guide P/N 3-420049-01 MaxiScan 2210 Presentation Scanner Guía de Iniciación Guida Introduttiva Guide de Démarrage Guia de Iniciação Anleitung für Einsteiger...
  • Page 2 Introduction Use this Getting Started Guide to set up the MaxiScan 2210 for most terminal connections and symbologies. If necessary, use the EasySet setup software for additional configura- tion possibilities and terminal connections. Basic setup Configuración básica Configuration de base...
  • Page 3 Keyboard wedge (for PC) System power OFF Connect cables Din/mini-Din adaptor cable power supply (normally not required) System power ON Select keyboard QWERTY English QWERTZ German PC wedge cable P/N 3-414037-01 AZERTY French QWERTZ Swiss / French QWERTY Swedish / Finnish QWERTY Norwegian QWERTY Spanish Customize parameters (optional)
  • Page 4 RS-232 C System power OFF Connect cables Standard RS-232 C cable P/N 3-414032-00 Scanner power ON System power ON Read this code (standard RS-232 C PC serial port compatible) 9600 baud, 7 data bits, even parity, 2 stop bits postamble = carriage return + line feed...
  • Page 5: Reading Distance

    Symbology Disable all symbologies Select symbology Code 39 Code 128 / EAN 128 Test End basic setup Reading distance UPC-A, UPC-E, EAN-8, EAN-13 (UPC-A -> EAN-13) UPC-A, UPC-E, EAN-8, EAN-13 (UPC-A -> UPC-A) Default setup Multi-scan pattern for normal operation...
  • Page 6 Full setup with EasySet System power OFF Connect RS-232 C cable (P/N 3-414032-00) Scanner power ON System power ON EasySet setup Read this code Start EasySet software Laser warnings English USA DHHS Standard 21CFR 1040.10 and 1040.11: Class IIa Laser Product IEC 825-1 (1993) EN 60825-1 (1997): Class 1 Laser Product Avoid long term viewing of direct laser light.
  • Page 7: Regulatory Statements

    Regulatory statements Intermec hereby declares that the MaxiScan 2210 has been tested and found compliant with the below listed standards as required by the EMC Directive 89/336/EEC as amended by 92/31/EEC and by the Low Voltage Directive 73/23/EEC as amended by 93/68/EEC:...
