Wiring Instructions

1. Unscrew the screws.
(Counterclockwise)
3. Tighten the screws.(Clockwise)
Note：
During the wiring process, the
attached terminal block can be used
for connection. After stripping the
wire, put it into the terminal block and
squeeze it with a crimping pliers.
1
3
2. Plug the cable into the correct
port.
4. Check the wiring condition
