Identification Of Parts
2
LCD Backlit Display Screen
1
Menu Button (switch menu/adjust parameters)
2
Switch Button (control USB/adjust parameters)
3
PV Positive Terminal
4
PV Negative Terminal
5
Battery Positive Terminal
6
Battery Negative Terminal
7
Installation Mounting Holes
8
USB Output Port
9
Heat Sink
10
1
4 5 6 7
9
10
4
3
8
