LCD Display Interface Overview
Display Section
Charge And USB Status
Parameter
BAT Type
Indicate And Warning
Status Icon
Indication
Day Night
And Charge
Indication
Battery
Indication
USB
Indication
System Error
Indication
Voltage
Indication
Status
Daylight Detected
On
On
No Daylight Detected
On
Solar Charging Battery
Battery Voltage is Hight
Battery Voltage is Middle
Battery Voltage is Low
USB On
USB Off
System Error - Check Error Code
On
OFF
System Normally
12V
12V System
24V
24V System
5
Status
Description
Voltage
Voltage
