Lcd Display Interface - BougeRV PWM NEGATIVE GROUND User Manual

LCD Display Interface

Main Menu Interface
Battery charging voltage
Menu 1：Battery type setting
Setting method
A:
B:
The displayed value is the
actual voltage of the battery.
Automatic loop
playback every 3s
① b01=Sealed Lead Acid battery (SEL)
② b02=Absorbed Glass Mat battery（AGM）
③ b03=GEL battery（GEL）
④ b04=Flooded Lead Acid battery (FLD)
⑤ b05=LiFePO4 (LFP)
⑥ b06=Ternary lithium battery (LI)
⑦ b07=Lithium-Titanium-Oxide (LTO)
In the view mode, short press A to jump to the
menu interface, long press A for more than 2s until
the parameter flashes, short press A , B to adjust,
after finishing the adjustment, long press B for
more than 2s to confirm the parameter.
Short press A to jump to other interface or wait for
15s without operation it would automatically jump to
the main menu interface.
Battery charging current
9
