Chapter 1 — Introduction

EasyCoder PX6i, General View

Callout Description
1 Transfer ribbon mechanism
2 Various types of interface boards (options)
3 Fan fold guides kit (option)
4 Media supply with accessories
5 Liner/batch takeup unit (option)
6 Label slack absorber
7 Chassis
8 Cutter kit (option)
9 Print unit
10 Label taken sensor kit (option)
11 Keyboard and console board
4
Clo sed
Remarks
See pages 11-13
See pages 26-30
See page 35
See pages 15, 16-18
See page 22
See page 20
See pages 7-8
See page 33
See page 10
See page 22
See page 6
EasyCoder PX4i and PX6i Printers Spare Parts Catalog
