Chapter 1 — Using the PF8 Printers

Media Compartment

Label roll
holder
Platen
cover
PF8d Media Compartment
Ribbon rewind
wheel
Rewind shaft
and empty
ribbon take
up core
PF8t Media Compartment
4
The PF8t is a thermal transfer or direct thermal capable printer.
The media compartment accommodates the media supply and
the transfer ribbon supply. In direct thermal printers like the
PF8d, the top cover and the print mechanism are combined into
a single unit.
Print
mechanism
Spindle
Label guide
(2 places)
Cover open
button
Label roll
core
Print
mechanism
Locking
mechanism
(2 places)
Label guide
(2 places)
Black mark
sensor
Platen
roller
Platen
cover
Platen
roller
Black mark
sensor
PF8d/PF8t Printers User's Guide
Print line
adjustment
gear
