Other Features and Connections
Power
socket
USB
Parallel
Serial
port
port
port
(RS-232)
PF8d and PF8t Rear View Connections and Controls
PF8d/PF8t Printers User's Guide
The rear and underside of the printers contain USB, serial, and
parallel connections and additional features.
PF8d
Power
switch
Fan-fold
label slot
The bottom of the PF8d also has hanger holes that allow you to
wall-mount the printer.
Bottom
case
cover
PF8d Wall-Mount Holes
Chapter 1 — Using the PF8 Printers
Power
socket
USB
Parallel
port
port
PF8t
Fan-fold
label slot
Serial
port
Wall-mount
holes
5
